MPEG4 – 4/8/16 CH DVR
INSTALLATION/OPERATION
DIGITAL VIDEO RECORDER
(MPEG4 - 4/8/16 CHANNEL)
EVD-xx-100AxRN
-1-
www.eurovideo-cctv.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPEG-4CH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Euro Video MPEG-4CH

Summary of Contents for Euro Video MPEG-4CH

  • Page 1 MPEG4 – 4/8/16 CH DVR INSTALLATION/OPERATION DIGITAL VIDEO RECORDER (MPEG4 - 4/8/16 CHANNEL) EVD-xx-100AxRN www.eurovideo-cctv.com...
  • Page 2 MPEG4 – 4/8/16 CH DVR WARNING: To prevent a risk of fire of electric shock, do not expose this product to rain or moisture. • This installation should be made by a qualified service person and should conform to all local codes. •...

  • Page 3: Table Of Contents

    MPEG4 – 4/8/16 CH DVR Contents FOR THE SAFETY OF CUSTOMERS…………………...………………………….…………………………4 DESCRIPTION OF PARTS AND FUNCTION…………...…………………………………………………..7 COMPOSITION OF UNIT…………………………………...……………………………………………………7 FEATURES …………………………………………………..……………………………….………………..8 DESCRIPTION OF PARTS AND FUNCTION ………………..…………….…………..……..……………….. 9 Front Panel……………………………………………………..………………………………..…………..9 Rear Panel………………………………………………………..………………………………………… …11 Connection diagram………………………………………………………………………………………….13 OSD Description..............................15 MENU………………………………………………………………...………………………………………..16 MENU TREE…………………………………………………………..…………………………………………16 Main Menu.…………………………………………………………..………………………………………..18 Display………………………………………………………………..………………………………………..18 Camera Control…..…………………………….…………...

  • Page 4: For The Safety Of Customers

    MPEG4 – 4/8/16 CH DVR 1. FOR THE SAFETY OF CUSTOMERS Caution before use Please read this manual for proper use. The caution described in this manual contains very important information for the safe use, so, please follow the instruction. Please keep it whether you could reach after read.
  • Page 5 MPEG4 – 4/8/16 CH DVR support. If you use it continually, it could be a reason for a fire or electric shock. If smoke comes out of the device or when you smell something burning. If a alien substance is split into the device. If the device is dropped or the case is damaged.

  • Page 6: Description Of Parts And Function

    MPEG4 – 4/8/16 CH DVR It could damage the cable and cause the fire. Please pull out holding the plug. When you move, please remove plug If you move the device while the plug is in the socket, it could cause a fire by damaging the cable. Don’t block the ventilation window.

  • Page 7: Features

    MPEG4 – 4/8/16 CH DVR Remote Controller Battery When you have received a product “without HDD” , the accessories 1) stand for HDD installing 2) fixing screws will be supplied. Accessories are subject to change without notice. 2-2 FEATURES ● Convenience - User-friendly UI( Text Based User Interface) - Easy-to-use menu composition - Easy-to-use recorded data search (Time, Date, Motion, Alarm)

  • Page 8: Description Of Parts And Function

    MPEG4 – 4/8/16 CH DVR ● Technology -Embedded LINUX OS -Totally maximum recording rate 120 fps -High-resolution & high-quality MPEG-4 algorithm -Using Water marking & scrambling technologies, -Strong protection recorded data -MPEG-4 : 1 ~ 2 Kbytes per image with resolution 360x240 ●...
  • Page 9 MPEG4 – 4/8/16 CH DVR (2) USB 2.0 PORT - USB2.0 connector (3) POWER BUTTON - System Power On/Off (4) NUMERIC & CHARACTER - Input for numeric & character (5) MENU - Displays on the menu on the screen (6) SEARCH - Entering search mode directly (7) PLAY ( ) - Playback on the recorded data...

  • Page 10: Rear Panel

    MPEG4 – 4/8/16 CH DVR (13) AUDIO (8/16CH Only) - when user select “audio” key, available audio will be switched. (14) ARROW KEY - Curse shifting on the menu - Shows the divided screen (15) SELECT - Menu selection 2-3-2 Rear Panel (1) Video Input (BNC) - 16 Camera input (1.0 v p-p, 75 ) (2) Video Out (BNC / S-VIDEO / VGA)
  • Page 11 MPEG4 – 4/8/16 CH DVR (5) RS232 - 1 Serial Communication (6) Network Port (RJ-45) - Available to monitor live screen and recorded data on the HDD through Internet or LAN (7) DIP switch (NTSC/PAL Video Selection) -Selectable either NTSC or PAL (08) RS422 / 485 - 1 Serial Communication for Pan / Tilt Camera (09) Alarm/Sensor...

  • Page 12: Connection Diagram

    MPEG4 – 4/8/16 CH DVR Web Client User ID “admin” (not case sensitive). Admin ID cannot be changed this is full administrator ID. Password “00000000” i.e. 8x Zero’s 2-3-3 System Connection Diagram EVD-xx-100AxRN -12- www.eurovideo-cctv.com...
  • Page 13 MPEG4 – 4/8/16 CH DVR 2-3-4. Remote Controller 1.Power : 2. Rec : Start & Stop Recording 3. ~ :Key for figure and character 4. PTZ: Controlling PTZ camera 5. OSD : Operating OSD ON/OFF 6. SEQ : Key for SEQ operation 7.

  • Page 14: Osd Description

    MPEG4 – 4/8/16 CH DVR 2-3-5. OSD Description Recording on NORMAL: It shown the recording Mode. It shows “Alarm recording * 16/8channel doesn’t show recording icon as 4channel. mode / Motion recording If the user programmed “schedule recording” and current mode/ Power loss”/ Video time is out of range, “STANDBY”...

  • Page 15: Menu

    MPEG4 – 4/8/16 CH DVR 3-1. Menu tree Monitor Adjustment (4CH Only) Main Menu Camera Covert Camera Name Display Set OSD On/Off Set Display Sequence Event Clear Audio Camera Control Repeat Recording Watermark Record Resolution Save and exit Global Parameter Recording Set Frame Rate Normal Recording...
  • Page 16 MPEG4 – 4/8/16 CH DVR Network Set DDNS DDNS SET DDNS User ID DDNS Password HOST Name DDNSStatus Check Save and Exit Use Dynamic IP IP address Gate Way Net Mask DNS Server IP SET XDSL User ID XDSL Password DVR Port Web Server Port Event Notification...

  • Page 17: Main Menu

    MPEG4 – 4/8/16 CH DVR 3-2 Main Menu NOTE Before using, be sure to setup the unit properly. Below menu shows when you press the menu button on the front while the system is on. MAIN MENU DISPLAY SET RECORDING SET SYSTEM SET NETWORK SET EVENT NOTIFICATION...

  • Page 18: Camera Control

    MPEG4 – 4/8/16 CH DVR OSD On/Off OSD on/ off : Selecting whether the OSD displaying is on/off Set Display Sequence SET DISPLAY SEQUENCE FULL DISPLAY SEQUENCE QUAD DISPLAY SEQUENCE START FULL DISPLAY SEQUENCE START QUAD DISPLAY SEQUENCE Sequence dwell time can be selected among 5,10,15,30,45,60 sec. When you select “ Start Full or Quad Display Sequence”, monitor switch will be started(Or, user can select “...
  • Page 19 MPEG4 – 4/8/16 CH DVR Alarm recording It executes the recording when sensor is taken. Motion recording It executes the recording when motion is captured. Schedule recording It executes the recording as per the programmed time table. Recording priority It specify the priority among 4 kinds of recording methods. NOTE “Instant playback”...
  • Page 20 MPEG4 – 4/8/16 CH DVR Audio Recording(8/16CH) 8/16CH: 4 Audio are available. (Audio 1,2,3,4 are fixed to Video 1,2,3,4). Repeat recording It sets the recording mode when the HDD capacity is exceeding. It can be selected between “On” (overwrite) / “Off” (stop). Watermark Can select either Watermark On or OFF.
  • Page 21 MPEG4 – 4/8/16 CH DVR max. frame rate each channel is 30 fps- for exam, Ch.1 30 fps, Ch2. 30 fps, Ch3. 0fps, Ch4 0fps. ~ ) Frame rate will be changed pushing the “←, → ” button NORMAL RECORDING (8/16channel Only) PAGE : 1 (8/16CH Only) FRAME RATE : 8FPS...
  • Page 22 MPEG4 – 4/8/16 CH DVR Frame Rate (fps) :4channel The above shows available frame rate each channel. In 360x240 mode, 0~30fps is available each channel (4 channel totally 120fps) and 720x 240 is 1~15fps each (4 channel totally 60fps, available max.
  • Page 23 MPEG4 – 4/8/16 CH DVR Post Alarm Duration After alarm activates, it sets how long the recording continues. The value is selectable among 5/ 30/ 60/ 90/ 120/ 150/ 180/ 210/ 240 sec. Save and Exit All the set-up value will be stored and move to higher menu. Motion Recording MOTION RECORDING (4channel Only) CH1 FRAME RATE...
  • Page 24 MPEG4 – 4/8/16 CH DVR Frame Rate (fps) :8/16 channel The above shows available frame rate each channel. In 360x240 mode, 7.5 fps is available each channel (16/8 channel totally 120fps) and 720x 240 is 3 fps each (16/8 channel totally 60fps). Individual frame rate control is available as 4channel.

  • Page 25: Recording

    MPEG4 – 4/8/16 CH DVR When you record the camera image with the motion recording mode, the data file will be saved depending on the motion sensitivity. So, higher caution is required to apply the sensitivity to the actual recording. Schedule Recording SCHEDULE RECORDING (4channel Only) CH1 FRAME RATE...
  • Page 26 MPEG4 – 4/8/16 CH DVR Recording Quality It selects among High, Mid, Low . Setup Schedule SCHEDULE SETUP SAVE AND EXIT “SEL” button is used for selecting relevant time and day. Arrow Key will be used for movement. NOTE When you change the items regarding recording ( resolution, mode, frame rate, etc), “Recording” should be “off”...

  • Page 27: System Set

    MPEG4 – 4/8/16 CH DVR System Set SYSTEM SET BASIC DISK FORMAT PASSWORD CHANGE PROGRAM UPDATE CLIENT ACCOUNT PROGRAM UPDATE SENSOR AUTO DELETE MODE Basic BASIC LANGUAGE : ENGLISH INITIALIZATION DATE FORMAT : mm-dd- yyyy DATE/TIME/DST SET INFORMATION SAVE AND EXIT Language The default is English Initialization...
  • Page 28 MPEG4 – 4/8/16 CH DVR NOTE PLAYBACK FOLLOWING TIME CHANGE The DVR uses the time and date to index video on the hard disk drive so you can find it later. Changing the time can cause the DVR to work improperly when you try to play back video. If you set the hour ahead, this is not a problem.
  • Page 29 MPEG4 – 4/8/16 CH DVR memory stick connects USB port, will be shown on the right corner of monitor. Then, enter “menu”-> “System Set”-> “Program Update”. If the system recognize “new program”, “New program found” will be displayed on the screen. Then, please buttons “Select” Key. Processing percentage will be displayed.

  • Page 30: Network Set

    MPEG4 – 4/8/16 CH DVR PTZ CONTROLLER : OFF/000 MODEL : TB-CN SERIES BAUD RATE : 2400/4800/9600BPS SAVE AND EXIT PTZ Controller Model is available TB-CN 3R1 / Baud Rate can be selected among 2400, 4800, 9600BPS. 3. Network Set DDNS SET DDNS : YES...

  • Page 31: Evnt Notification

    MPEG4 – 4/8/16 CH DVR For user in XDSL environment, the input for XDSL user ID/ XDSL password is required. In fixed IP environment, no need to change DVR & Web Server Port. Event Notification EVENT NOTIFICATION ►E-MAIL REGISTRATION E-MAIL REPORT NOTIFICATION OUT SAVE AND EXIT E-MAIL REGISTRATION...

  • Page 32: Search

    MPEG4 – 4/8/16 CH DVR Alarm/ Motion/Power Loss” will be sent to E-Mail address or Beep or Alarm according to setup value. 4. Search SEARCH DATE/TIME SEARCH CALENDAR SEARCH BACKUP Date / Time Search If you select date/time search, the following will be shown. DATE/TIME SEARCH EVENT : ALL : INTERNAL...

  • Page 33: Backup

    MPEG4 – 4/8/16 CH DVR It shows where the recorded data is located at a sight . Using “→, ←”buttons, it is available to move specific time/date . To enter sub-menu(Time), please use “SEL” button. Day(11, eleven) will be changed ‘up and down( )’...
  • Page 34 MPEG4 – 4/8/16 CH DVR 1. INTERNAL BACKUP BACKUPDEVICE: CD/DVD-R DEVICE FORMAT FILE FORMAT: EXCLUSIVE/AVI FROM: 12-07-2004 12:46:30 :12-07-2004 12:47:30 CHANNEL : 1 CALCULATING BACKUP SIZE TRANSFER FREE/TOTAL SPACE 49M/245M REQUIRED SPACE 60M: Backup Device Internal CD-R or DVD-R is available. >...
  • Page 35 MPEG4 – 4/8/16 CH DVR Transfer Downloading the backup data to internal disk . Percentage during downloading will be shown. > Note : Network should be disconnected during downloading to internal DVD/CD-R disk. If network is connected, connection will be terminated during "making backup file" 2.
  • Page 36 MPEG4 – 4/8/16 CH DVR Channel You can select one channel among CH 1 ~ 16 in case of AVI file but , if you select exclusive, Even all channels can be downloaded at the same time. Transfer Downloading the backup data to stick . Percentage during downloading will be shown. * USB compatibility has been tested successfully for these recommended USB devices.

  • Page 37: Client Program

    MPEG4 – 4/8/16 CH DVR 5. CLIENT PROGRAM 5-1. Network Connection Minimum PC specification (4, 8/16CH) CPU : 4CH- Pentium III 750MHz over, 8/16CH- Pentium 1.7GHz over. Graphic Memory : 4CH- 32M over, 8/16CH – 64M over. IP Insertion Connection will be done just writing DVR IP address on the Internet Explorer window. If domain is kept to reach DVR by DDNS server, it is allowed to write domain name directly.
  • Page 38 MPEG4 – 4/8/16 CH DVR Termination of Live monitoring Live monitoring will be terminated when user pushes “Live Off” button. Live monitoring will be re-started when user pushes “Live On” button.. System & Local System means the DVR. Local means Remote PC as client Recording &...
  • Page 39 MPEG4 – 4/8/16 CH DVR System & Local recording To start the recording on the DVR via client PC, press the recording button, when the system icon is on green. 1) system recording Shadow bottom is shown as seen in blue circle. Please check system is on the recording mode.
  • Page 40 MPEG4 – 4/8/16 CH DVR When “Local” button is activated (green one), it will be operated . When push the Play ( ), the window besides is shown. On clicking the “OK” button then set the start & end time. Please check either ‘Download’ or ‘Live Backup’.
  • Page 41 MPEG4 – 4/8/16 CH DVR Select the number and push ‘start’ button. Then, local playback will be done as above. Remote playback It works when system button is in green. When push the Play button( ), the window is shown besides. After input “start” and “end”...
  • Page 42 MPEG4 – 4/8/16 CH DVR Then, list will be shown above. Select the number and push ‘start’ button. EVD-xx-100AxRN -42- www.eurovideo-cctv.com...
  • Page 43 MPEG4 – 4/8/16 CH DVR Then, remote playback will be done as above. Setup Setup menu is composed of 1) Remote Setup 2) Local Setup 3) Firmware Upgrade menu. Remote setup Note: When the main system is entering “ menu OSD”, remote setup doesn’t work.
  • Page 44 MPEG4 – 4/8/16 CH DVR Among ‘System Set’ menu, PTZ Camera & Schedule Backup menu are unavailable for 4channel DVR. If is designed for 8,16channel only. Others are the same as local system configuration. EVD-xx-100AxRN -44- www.eurovideo-cctv.com...
  • Page 45 MPEG4 – 4/8/16 CH DVR ‘Event Set’ menu has 1) E-Mail registration 2) E-Mail report 3) Notification out . The menu is same as local menu tree. The detail will be shown when you click the Local setup ‘Local Setup’ menu. 1) Draw Mode: User can select between YUV format using Direct X or RGB.
  • Page 46 MPEG4 – 4/8/16 CH DVR Firmware Upgrade When user select ‘Firmware Upgrade’ menu, if higher version exits in C:\KWClient\Upgrade fold, ‘New Program Found!’ message will be shown besides. If higher version in C:\KWClient\Upgrade fold, ‘New Program Not Found’ message will be displayed.
  • Page 47 MPEG4 – 4/8/16 CH DVR When firmware Upgrade is done successfully, ‘Firmware Upgrade success!’ message will be displayed. The local system should be re-booted . Download, Image Save, Two-Way audio, Stop, Connect Download EVD-xx-100AxRN -47- www.eurovideo-cctv.com...
  • Page 48 MPEG4 – 4/8/16 CH DVR It is for transmitting the recorded data on HDD to client PC. When ‘download’ button is pushed, User select ‘Download’ and push ‘OK’ button User select ‘Start time’ and ‘End time’ to download data and push ‘OK’ button. EVD-xx-100AxRN -48- www.eurovideo-cctv.com...
  • Page 49 MPEG4 – 4/8/16 CH DVR Select the number among list for ‘Start Time’ . Select the number among list for ‘End Time’. EVD-xx-100AxRN -49- www.eurovideo-cctv.com...
  • Page 50 MPEG4 – 4/8/16 CH DVR Processing bar will be shown above and wait till downloading is finished. Downloading is finished, push ‘Local’ button, which turns in green color and, push play( ) button. User select ‘Live Backup’ and click ‘OK’ button. User select ‘Start time’...
  • Page 51 MPEG4 – 4/8/16 CH DVR Then, the download list will be shown besides. Select the number which you want to play. Local Play (from downloaded files) will be done like above. Image Save It stands for saving format. Either JPEG or BMP . The file will be stored C:\KWClient\Save . EVD-xx-100AxRN -51- www.eurovideo-cctv.com...
  • Page 52 MPEG4 – 4/8/16 CH DVR Stop It is for stopping Downloading. Connect Re-connecting when access is failed Pan/Tile, Zoom/Focus, OSD 1) Pan / Tilt Using arrow key, controls the Pan/Tilt ( 4 channel doesn’t support P/T/Z control) 2) Zoom / Focus Using arrow key, controls Zoom, Focus (4channel doesn’t support P/T/Z control) 3) OSD Whether displays or not on OSD during live / playback...

  • Page 53: Q & A

    MPEG4 – 4/8/16 CH DVR Reset for event button (event clear) Timer It shows the client PC timer when monitoring is working. On the other hand, it shows the time the recording data belongs to during playback. The timer format is according to date format specified on the “local Setup”. Exit Q &...
  • Page 54 MPEG4 – 4/8/16 CH DVR Can’t download the ActiveX Control. It does if “Windows XP Service Pack 2” is installed on the PC. Remove “service pack 2” on the menu , “program add & removal” on the control panel. Or, refer to Appendix 3. The client program is terminated with the message “Unsupported OS version !”...
  • Page 55 MPEG4 – 4/8/16 CH DVR A : Please check whether you have a Codec S/W or not. If you don’t have, you have to install it in your PC. Q : When I downloaded the image as AVI on to my memory stick, it plays back ok, but no date & time A : AVI (window media player) file is supplied by MS.
  • Page 56 MPEG4 – 4/8/16 CH DVR 2) Inner Configuration The inner configuration of DVR is as follows, 0.8“ Round Screw 0.6“ Round Screw Left Complementary Device for fixing the HDD 40 Pin Connector HDD Power Connector KERBEROS Main Board HDD Power Cable HDD Connector Cable 2.
  • Page 57 MPEG4 – 4/8/16 CH DVR Fix the Left Complementary Device with 0.6“ Round Screw to Main Body Fix the Right Part of HDD with 0.8“ Round Screw to Main Body Assemble the HDD Cable and HDD Power Cable each others Appendix 2 SENSOR INSTALLATION 1.
  • Page 58 MPEG4 – 4/8/16 CH DVR PC817 : Photo Coupler The Specification of PC817 Absolute Maximum Ratings Parameter Symbol Rating Unit Forward current *1Peak forward current I FM Input Reverse voltage Power dissipation Collector-emitter voltage V CEO Emitter-collector voltage V ECO Output Collector current Collector power dissipation...
  • Page 59 MPEG4 – 4/8/16 CH DVR *1 Pulse width<=100 s, Duty ratio : 0.001 *2 40 to 60% RH, AC for 1 minute *3 For 10 seconds Electro-optical Characteristics Parameter Symbol Conditions MIN. TYP. MAX. Unit Forward voltage IF = 20mA Peak forward V FM IFM = 0.5A...
  • Page 60 MPEG4 – 4/8/16 CH DVR SENSOR 12V DC ?? V DC 2.2k 3.3k Or 10k PC817 SENSOR IN Outlet Point Appendix 3 INSTALLING KERBEROS WEB CLIENT ON WINDOW XP SERVICE PACK 2. 1) Security Setup EVD-xx-100AxRN -60- www.eurovideo-cctv.com...
  • Page 61 MPEG4 – 4/8/16 CH DVR Tools-> Internet Options-> Security -> Select “Customer Level” Select “ Allow script-initiated windows without Size or position constraints”-> Enable. EVD-xx-100AxRN -61- www.eurovideo-cctv.com...
  • Page 62 MPEG4 – 4/8/16 CH DVR Select “ Download unsigned Active X controls”-> Prompt Select “ Automatic Prompting for Active X controls”-> Disable 2) Connection EVD-xx-100AxRN -62- www.eurovideo-cctv.com...
  • Page 63 MPEG4 – 4/8/16 CH DVR Click here as described Select “ Temporary Allow Pop-ups” Click “ To help protect security, Internet Explorer stopped this site from installing an Active X control on your computer. Click here for options…” EVD-xx-100AxRN -63- www.eurovideo-cctv.com...
  • Page 64 MPEG4 – 4/8/16 CH DVR Select “Install Active X Control “ Select “Install” and then ‘Log-In’ box will be shown. Appendix 4 DYNAMIC IP ( Supporting DDNS Server) 1. visit www.ddns-dvr.com to get the DDNS user ID & PW as well as Host name. EVD-xx-100AxRN -64- www.eurovideo-cctv.com...
  • Page 65 MPEG4 – 4/8/16 CH DVR 2. Click to create / set account of “Dynamic DNS”. 3. Select “Create Account” menu. EVD-xx-100AxRN -65- www.eurovideo-cctv.com...
  • Page 66 MPEG4 – 4/8/16 CH DVR 4. Create Account. EVD-xx-100AxRN -66- www.eurovideo-cctv.com...
  • Page 67 MPEG4 – 4/8/16 CH DVR > Please set up all blank in order to create new account. ID & Password will be emailed you when the account is created well. Appendix 5 SETUP FOR DVR PORT/ WEB SERVER PORT USING IP SHARING ROUTER IP SET USE DYNAMIC IP: NO IP ADDRESS...
  • Page 68 MPEG4 – 4/8/16 CH DVR 1) To use IP sharing Router, it should be “NO” at “Use Dynamic IP”. - DVR Port : It is possible to be input any numbers from 2000 to 65535. - Web Server Port : It is possible to be input any numbers without overlapping with DVR Port (2000~65535).
  • Page 69 MPEG4 – 4/8/16 CH DVR 2. Select “Computer Management” EVD-xx-100AxRN -69- www.eurovideo-cctv.com...
  • Page 70 MPEG4 – 4/8/16 CH DVR 3. Select “Disk Management”. 4. Click right mouse button and select “New Partition”. EVD-xx-100AxRN -70- www.eurovideo-cctv.com...
  • Page 71 MPEG4 – 4/8/16 CH DVR 5. Follow “New Partition Wizard” procedure as below. EVD-xx-100AxRN -71- www.eurovideo-cctv.com...
  • Page 72 MPEG4 – 4/8/16 CH DVR 7. Maximum is 30GB at FAT32 file format. EVD-xx-100AxRN -72- www.eurovideo-cctv.com...
  • Page 73 MPEG4 – 4/8/16 CH DVR 10. At this stage, New Partition has been made. EVD-xx-100AxRN -73- www.eurovideo-cctv.com...
  • Page 74 MPEG4 – 4/8/16 CH DVR 11.Check New partition was created correctly.(Format will be executed automatically) 12. Check New Partition was created correctly EVD-xx-100AxRN -74- www.eurovideo-cctv.com...
  • Page 75 MPEG4 – 4/8/16 CH DVR Appendix 7 SPECIFICATION EVD-xx-100AxRN -75- www.eurovideo-cctv.com...
  • Page 76 MPEG4 – 4/8/16 CH DVR *Design and product specifications subject to change without notice* EVD-xx-100AxRN -76- www.eurovideo-cctv.com...
