Euro Video EVD-16-400AxxHN User Manual

Standalone dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Standalone DVR User's Manual
EVD-16/400AxxHN
-1-
www.eurovideo-cctv.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVD-16-400AxxHN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Euro Video EVD-16-400AxxHN

Summary of Contents for Euro Video EVD-16-400AxxHN

  • Page 1 User’s Manual Standalone DVR User’s Manual EVD-16/400AxxHN www.eurovideo-cctv.com...

  • Page 2: Table Of Contents

    User’s Manual Table of Contents 1 1 1 1 FEATURES AND SPECIFI FEATURES AND SPECIFICATIONS CATIONS ..............11 FEATURES AND SPECIFI FEATURES AND SPECIFI CATIONS CATIONS Features Features Features Features ..............................11 Specifications Specifications ............................11 Specifications Specifications 2 2 2 2 OVERVIEW AND CONTROL OVERVIEW AND CONTROLS S S S .................
  • Page 3 User’s Manual Desktop and Rack Mounting Desktop and Rack Mounting Desktop and Rack Mounting Desktop and Rack Mounting ......................26 3.4.1 Desktop Mounting ........................... 26 3.4.2 Rack Mounting ..........................26 Connecting Power Supply Connecting Power Supply Connecting Power Supply Connecting Power Supply ........................26 Connecting Video Input and Output Devices Connecting Video Input and Output Devices Connecting Video Input and Output Devices...
  • Page 4 User’s Manual 4.2.2 Manual record..........................37 Search & Playback Search & Playback Search & Playback Search & Playback ..........................39 4.3.1 Search Menu ........................... 39 4.3.2 Basic Operation ..........................40 4.3.3 Calendar ............................42 Record Setup (Schedule) Record Setup (Schedule) Record Setup (Schedule) Record Setup (Schedule) ........................
  • Page 5 User’s Manual 4 4 4 4 .10 Flip Flip Flip Flip ................................. 58 5 5 5 5 UNDERSTANDING OF MEN UNDERSTANDING OF MENU OPERATIONS AND CON U OPERATIONS AND CONTROLS TROLS ....59 UNDERSTANDING OF MEN UNDERSTANDING OF MEN U OPERATIONS AND CON U OPERATIONS AND CON TROLS TROLS...
  • Page 6 User’s Manual Exit Exit Exit Exit ................................. 88 6 6 6 6 ABOUT AUXILIARY MENU ABOUT AUXILIARY MENU ................89 ABOUT AUXILIARY MENU ABOUT AUXILIARY MENU Go to Pan/Tilt/Zoom Menu Go to Pan/Tilt/Zoom Menu Go to Pan/Tilt/Zoom Menu Go to Pan/Tilt/Zoom Menu ......................... 89 6.1.1 3D Intelligent Positioning Key .......................
  • Page 7 User’s Manual About About About About ..............................127 Log out Log out Log out Log out ..............................128 Un- - - - install Web Control install Web Control install Web Control ........................128 install Web Control 8 8 8 8 ENTERPRISE PROFESSIO ENTERPRISE PROFESSIO ENTERPRISE PROFESSIO...
  • Page 8 User’s Manual Welcome Thank you for purchasing our DVR! This operating manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.

  • Page 9: Important Safeguards And Warnings

    User’s Manual Important Safeguards and Warnings 1． ． ． ． Electrical safety All installation and operation here should conform to local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．...
  • Page 10 User’s Manual A package of installation fittings Contact your local retailer ASAP if something is missing in your package. Note: Any changes of this manual made to the actual product are subject to no further notification. EVD-16/400AxxHN -10- www.eurovideo-cctv.com...

  • Page 11: Features

    User’s Manual 1 1 1 1 F F F F EATURES AND SPECIFICATIONS EATURES AND SPECIFICATIONS EATURES AND SPECIFICATIONS EATURES AND SPECIFICATIONS 1.1 Features Features Features Features This series DVR has the following features: H.264 compression algorithm ideal for standalone DVR Real-time live display up to 16 cameras, 400/480 fps recording for CIF, 2CIF&...
  • Page 12 User’s Manual version, on-line user and etc. Video Video Input 16 Channel, BNC, 1.0Vp-p, 75Ω, looping(optional), Video Output 2-channel TV output BNC, 1.0Vp- p, 75 ,1 VGA output, matrix output(optional) Video Standards PAL（625Line，50f/s） Video Compression H.264 Video Resolution Format D1(4CIF) 704 * 576 2CIF 704 * 288...
  • Page 13 User’s Manual Hard Disk 8 SATA ports, 8 HDDs supported. Audio ：14.4MB/H Video ：56～700MB/H Space Occupation HDD Management Hard disk hibernation technology, HDD faulty alarm & Raid (Redundancy) Record, Playback & Backup Recording Mode Manual, continuous, video detection (including motion detection, camera masking, video loss), Alarm Recording Priority Manual >Alarm >Video Detection >Continuous.
  • Page 14 User’s Manual Note: Comparisons Model Audio Input Loop Output Matrix Output Bidirectional Talk Input EVD-16/400A04HN 4 channel 16 channel 1 channel 1 channel EVD-16/400A16HN 16 channel 1 channel EVD-16/400AxxHN -14- www.eurovideo-cctv.com...

  • Page 15: Overview And Controls S S S

    User’s Manual 2 2 2 2 Overview and Controls Overview and Controls Overview and Controls Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel Front Panel Front Panel...
  • Page 16 User’s Manual Go to default button Go to main menu Manually stop/start recording, working with direction keys ● Record or numeral keys, Slow play Multiple slow play speeds or normal playback One-window monitor mode, click this button to display assistant function: PTZ control and image color.
  • Page 17 User’s Manual Function indication light Window switch MULT Switch between one-window and multiple-window display modes. confirm current operation Enter ENTER go to default button Go to main menu Cancel Close upper interface or controls. In real-time monitor mode it works as left/right direction key. Shuttle(outer ring) Playback mode, counter clockwise to forward and clock wise to backward.
  • Page 18 User’s Manual In textbox, click this button to switch between numeral, English(Small/Capitalized),donation, Chinese and etc. Open/close tour numeral keys 0-9 Input password, switch channel and input numeral. When you need to input numeral more than 9. You can follow the steps below: click the first key number and then the next.

  • Page 19: Rear Panel

    User’s Manual One-window monitor mode, click this button to display assistant function: PTZ control and image color. In PTZ menu, shift PTZ control menu. Backspace function: in numeral control or text control, it can delete the previous character before the cursor. In motion detection setup, working with Fn and direction keys to realize setup.

  • Page 20: Connection Sample

    User’s Manual Figure 2-3 2.2.2 Connection Sample Here is a connection sample for your reference. See Figure 2-4. 312H EVD-16/400AxxHN -20- www.eurovideo-cctv.com...

  • Page 21: Remote Control

    User’s Manual Figure 2-4 2.3 Remote Control Remote Control Remote Control Remote Control The remote control interface is shown as in Figure 2-5. 313H Figure 2-5 Serial Number Function remote switch Multiple-window switch 0-9 number key Record Auxiliary key Confirm /menu key Cancel Direction key forward...
  • Page 22 User’s Manual In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character.

  • Page 23: Virtual Keyboard & Front Panel

    User’s Manual Exit current menu without saving the modification. Press In numeral input box: Increase or decrease numeral value. middle Switch the items in the check box. button Page up or page down Move Select current control or move control mouse Drag mouse Select motion detection zone...

  • Page 24: Installation And Con Installation And Connections Installation And Con Nections

    User’s Manual 3 3 3 3 Installation and Connections Installation and Connections Installation and Connections Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR Check Unpacked DVR Check Unpacked DVR Check Unpacked DVR When you receive the DVR from the shipping agency, please check whether there is...

  • Page 25: Cd/Dvd Burner Installati Cd/Dvd Burner Installation Cd/Dvd Burner Installati On

    User’s Manual 3. Dismantle the upper HDD bracket. 4. Install the HDD. Note the HDD is placed upside down. Please make sure bracket is in correct position. If the HDD amount is less than four, you do not need to install the HDD bracket. Screw the two bracket parts together.

  • Page 26: Desktop And Rack Mounting

    User’s Manual This series DVR is compatible with various burner brands popular in today’s market. You can consult our local technical support or visit our website for more information. 3.4 D D D D esktop and Rack esktop and Rack M M M M ounting ounting esktop and Rack esktop and Rack...

  • Page 27: Connecting Video Output

    User’s Manual Figure 3-1 3.6.2 Connecting Video Output This section provides information about physically connecting video display devices to the DVR. See Figure 3-2. 315H If you connect the DVR with a TV monitor or VGA monitor, the DVR can automatically detects the monitor type.

  • Page 28: Connecting Audio Input & Output, Bidirectional Audio, Looping Video, Matrix

    User’s Manual 3.7 C C C C onnecting onnecting Audio Input Audio Input & & & & Output Output, Bidirectional Audio, Looping , Bidirectional Audio, Looping onnecting onnecting Audio Input Audio Input Output Output , Bidirectional Audio, Looping , Bidirectional Audio, Looping Video, Matrix Video, Matrix Video, Matrix...

  • Page 29: Looping Video

    User’s Manual 3.7.2 Looping video The DVR supports looping video. It passes the video input to a monitor or other analog video device. To use looping video: 1. Connect a coaxial cable to the video out connector on 37-pin interface Please note you need to use a BNC installation tool to connect coaxial cables to the rear panel.

  • Page 30: Alarm Output

    User’s Manual Figure 3-6 3.7.6 Alarm Output Do not connect alarm output port directly with high power load (no more than 1 A) in case of heavy current. You can use the co-contactor to realize the connection between the alarm output port and the load.

  • Page 31: Relay Output Description

    User’s Manual 485 communication port. They are used to control devices 485 A、B such as PTZ. This should input an external power input. +12（C） 4/8/16-ch grounding alarm inputs. (Normal open or Normal close type) Please parallel connect COM end and GND end of the alarm detector (Provide external power to the alarm detector).
  • Page 32 User’s Manual Figure 3-9 Please refer to Figure 3-10 for alarm output module information. 322H Figure 3-10 Relay Specification JRC-27F Model: Silver Material of the touch Rating Rated switch capacity 30VDC 2A, 125VAC 1A （resistance Maximum switch power 125VA 160W Maximum switch voltage 250VAC, 220VDC load）...

  • Page 33: Rs232

    User’s Manual 1000VAC 1minute 50/60Hz between touches with different polarity between touch and winding 1000VAC 1minute 50/60Hz Surge between touches with 1500V (10×160us) voltage same polarity 3ms max Length of open time 3ms max Length of close time Longevity Mechanical 50×106 times (3Hz) Electrical 200×103 times (0.5Hz)
  • Page 34 User’s Manual Figure 3-11 EVD-16/400AxxHN -34- www.eurovideo-cctv.com...

  • Page 35: Overview Of Navigation And Coverview Of Navigati Overview Of Navigati On And Con And Controls Ontrols

    User’s Manual 4 4 4 4 Overview of Navigation and Controls Overview of Navigation and Controls Overview of Navigation and Controls Overview of Navigation and Controls Before operation, please make sure you have properly installed HDDs and all the cable connections. 4.1 Login, Logout &...

  • Page 36: Logout

    User’s Manual Figure 4-2 4.1.3 Logout There are two ways for you to log out. One is from menu option: In the main menu, click shutdown button, you can see an interface is shown as below. See Figure 4-3. 326H Figure 4-3 There are several options for you.

  • Page 37: Recording Operation

    User’s Manual 4.2 Record Recording O ing Operation peration Record Record ing O ing O peration peration 4.2.1 Live Viewing When you login, the system is in live viewing mode. You can see system date, time and channel name. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->General).
  • Page 38 User’s Manual Please check current channel status: “○” means it is not in recording status, “●” means it is in recording status. You can use mouse or direction key to highlight channel number. See Figure 4-6. 329H Figure 4-6 4.2.2.4 Enable all channel recording Highlight ○...

  • Page 39: Search & Playback

    User’s Manual Figure 4-8 4.2.2.5 Stop all channel recording Please highlight “ALL” after “Stop”. See Figure 4-9. 332H System stops all channel recording no matter what mode you have set in the menu (Main menu->Setting->Schedule) Figure 4-9 4.3 Search Search Search Search &...

  • Page 40: Basic Operation

    User’s Manual Figure 4-10 Please refer to the following sheet for more information. Serial Number Function Play Backward Stop Slow play Fast play Previous frame Next frame Volume Previous file Next channel Next file Previous channel Search Backup These series DVRs support 2-channel simultaneous playback. 4.3.2 Basic Operation 4.3.2.1 Playback There are various search modes: video type, channel number or time.
  • Page 41 User’s Manual Select the file name and double click mouse (or click enter button), you can view file content. 4.3.2.2 Accurate playback Input time (h/m/s) in the time column and then click playback button, system can operate accurate playback. 4.3.2.3 Synchronized playback function when playback During playback process, click numeral key, system can switch to the corresponding channel video of the same time.

  • Page 42: Calendar

    User’s Manual Fast backward(outer When playback, turn the shuttle Frame rate may ring counter (outer ring) counter clock-wise one vary due to clockwise) round, you can view in backward different version. level 1. Turn it two rounds, you get backward level 2. You can continue turning to get different speed.

  • Page 43: Record Setup (Schedule)

    User’s Manual 4.4 Record Setup (Schedule) Record Setup (Schedule) Record Setup (Schedule) Record Setup (Schedule) When the system boots up, it is in default 24-hour regular mode. You can set record type and time in schedule interface. 4.4.1 Schedule Menu In the main menu, from setting to schedule, you can go to schedule menu.
  • Page 44 User’s Manual button. You can finish setting for one channel and then click save button or you can finish all setup and then click save button to memorize all the settings. 4.4.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. These files are created, packaged and closed simultaneously.

  • Page 45: Detect

    User’s Manual Dismantle the disk and play it in another PC. 4.5 Detect Detect Detect Detect 4.5.1 Go to Detect Menu In the main menu, from Setting to Detect, you can see motion detect interface. Figure 4-14. There are three detection types: motion detection, video loss, 342H camera masking.
  • Page 46 User’s Manual Figure 4-14 Figure 4-15 EVD-16/400AxxHN -46- www.eurovideo-cctv.com...

  • Page 47: Video Loss

    User’s Manual Figure 4-16 Figure 4-17 Figure 4-18 4.5.3 Video Loss Figure 4-14, select video loss from the type list. You can see the interface is 350H shown as in Figure 4-19.This function allows you to be informed when video loss 351H phenomenon occurred.

  • Page 48: Camera Masking

    User’s Manual Alarm output: activate peripheral alarm device when video loss occurred. Latch: when motion detection complete, system auto delays detecting for a specified time. The value ranges from 10-300(Unit: second) Show message: System can pop up a message to alarm you in the local host screen if you enabled this function.

  • Page 49: Alarm Setup And Alarm Activati Alarm Setup And Alarm Activation On

    User’s Manual Show message: System can pop up a message to alarm you in the local host screen if you enabled this function. Send email: System can send out email to alert you when alarm occurs. PTZ activation: Here you can set PTZ movement when alarm occurs. Such as go to preset, tour &pattern when there is an alarm.
  • Page 50 User’s Manual Event type: there are two types. One is local input and the other is network input. Type: normal open or normal close. PTZ activation: Here you can set PTZ movement when alarm occurs. Such as go to preset, tour& pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-25.

  • Page 51: Backup Backup

    User’s Manual Figure 4-22 Figure 4-23 Figure 4-24 4.7 Backup Backup Backup Backup DVR support various backup devices such as CD-RW,DVD driver, USB backup and network download. Here we introduce USB backup first. You can refer to Chapter 7 Web Client Operation for network download backup operation. 4.7.1 Detect Device EVD-16/400AxxHN -51-...

  • Page 52: Backup

    User’s Manual Click backup button, you can see an interface is shown as in Figure 4-25. Here is 367H for you to view devices information. Figure 4-25 4.7.1 Backup Select backup device and then channel, file start time and end time. Click add button, system begins search.

  • Page 53: Ptz Control And Color Setup

    User’s Manual Figure 4-27 Tips: During backup process, you can click ESC to exit current interface; but the system will not terminate backup process. Note: When you click stop button during the burning process, there are two conditions for different devices: For CD/DVD burner device, the stop function becomes activated immediately and there is no data in the burner.
  • Page 54 User’s Manual Channel: select the current camera channel. Protocol: select corresponding PTZ protocol(such as PELCOD) Address: default address is 1. Baud rate: select corresponding baud rate. Default value is 9600. Data bits: select corresponding data bits. Default value is 8. Stop bits: select corresponding stop bits.

  • Page 55: Intelligent Positioning Key

    User’s Manual Iris Click icon to adjust zoom, focus and iris. Figure 4-30 Figure 4-30, please click direction arrows (See Figure 4-31) to adjust PTZ 373H 374H position. There are total 8 direction arrows. Figure 4-31 4.8.3 3D Intelligent Positioning Key In the middle of the eight direction arrows, there is a 3D intelligent positioning key.

  • Page 56: 1Preset Setup

    User’s Manual Border Figure 4-33 Figure 4-30, click page switch button, the interface is shown as in Figure 4-34. 378H 379H Here you can activate the following functions: Preset Tour Pattern Auto scan Auto pan Flip Reset Page switch Figure 4-34 Note: The following setups are usually operated in the Figure 4-30, Figure 4-33 and...

  • Page 57: Activate Preset

    User’s Manual Figure 4-35 4.9.2 Activate Preset Figure 4-34, please input preset number in the No. blank, and click preset button. 386H 4.9.3 Patrol setup (Tour Setup) Figure 4-33, click patrol button. The interface is shown as in Figure 4-36.Input 387H 388H preset number and add this preset to a patrol (tour).

  • Page 58: Activate Pattern Function

    User’s Manual 4.9.6 Activate Pattern Function Figure 4-34, input mode value in the No. blank, and click pattern button. 394H 4.9.7 Auto Scan Setup Figure 4-33, click border button. The interface is shown as in Figure 4-28. 395H 396H Please go to Figure 4-30, use direction arrows to select camera left limit 397H Then please go to...

  • Page 59: Understanding Of Men Understanding Of Menu Operations And Con Understanding Of Menu Operations And Controlsu Operations And Con Trols

    User’s Manual 5 5 5 5 Understanding of Understanding of Understanding of Understanding of Menu Menu Menu Operations and Controls Menu Operations and Controls Operations and Controls Operations and Controls 5.1 Menu Menu T T T T ree Menu Menu This series DVR menu tree is shown as below.

  • Page 60: Setting

    User’s Manual Figure 5-1 5.3 S S S S etting etting etting etting In main menu, highlight setting icon and double click mouse. System setting interface is shown as below. See Figure 5-2. 404H Figure 5-2 5.3.1 General General setting includes the following items. See Figure 5-3.
  • Page 61 User’s Manual Language: system supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional. Slight difference maybe found in various series.) HDD full: Here is for you to select working mode when hard disk is full. There are two options: stop recording or rewrite.

  • Page 62: Encode

    User’s Manual Figure 5-5 5.3.2 Encode Encode setting includes the following items. See Figure 5-6. 409H Please note some series do not support extra stream. Channel: Select the channel you want. Compression: system supports H.264. Or you can select from the dropdown list. Resolution: System supports various resolutions, you can select from the dropdown list.
  • Page 63 User’s Manual Resolution: CIF/D1 Bit rate: CBR Quality: 4 Frame rate: 25f/s Please highlight icon to select the corresponding function. Figure 5-6 Figure 5-7 Figure 5-8 For it supports various settings for channel, resolution and frame: Resolution：pixel EVD-16/400AxxHN -63- www.eurovideo-cctv.com...

  • Page 64: Schedule

    User’s Manual PAL：QCIF=176×144; CIF＝352×288; HD1＝352×576; 2CIF=704×288; D1＝704×576; We take 16-channel DVR as an example. There are four groups：1~4, 5~8, 9~12, 13~16. Please refer to the formula：resolution× frame rate The resources for one group are: PAL: D1×50 D1×50(60)F/s=Half-D1×100(120)F/s=CIF×200(240)F/s You can arrange channel parameter within the specified limit. Please refer to the following list：...

  • Page 65: Rs232

    User’s Manual 5.3.4 RS232 RS232 interface is shown as below. Here are five items. See Figure 5-9. 412H Function: There are various devices for you to select. Console is for serial port or min-end platform to upgrade program. Keyboard is for you to use special keyboard to control current device.
  • Page 66 User’s Manual Figure 5-10 5.3.5.1 Advanced Setup Advanced setup interface is shown as in Figure 5-11. Please draw a circle to enable 414H corresponding function and then double click current item to go to setup interface. Figure 5-11 5.3.5.2 IP Filter IP filter interface is shown as in Figure 5-12.
  • Page 67 User’s Manual Figure 5-12 5.3.5.3 Multiple Cast Setup Multiple-cast setup interface is shown as in Figure 5-13. 416H Figure 5-13 Here you can set a multiple cast group. Please refer to the following sheet for detailed information. IP multiple cast group address -224.0.0.0-239.255.255.255 -“D”...
  • Page 68 User’s Manual -Private address space Like the single broadcast address of RFC1918 Can not be used in Internet transmission Used for multiple cast broadcast in limited space. Except the above mentioned addresses of special meaning, you can use other addresses. For example: Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666.
  • Page 69 User’s Manual Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7 American Central Time(C.T) GMT-6 American Eastern Time(E.T) GMT-5 Atlantic Time GMT-4 Brazil GMT-3 Middle Atlantic Time GMT-2 Figure 5-15 5.3.5.6 Email Setup Email setup interface is shown as in Figure 5-16.
  • Page 70 User’s Manual http：//(DDNS server IP)/(virtual directory name)/webtest.htm e.g.: http：//10.6.2.85/DVR _DDNS/webtest.htm.) Now you can open DDNSServer web search page. Figure 5-17 5.3.5.8 Alarm Server You can set alarm in accordance with different alarm protocols. System can inform the alarm server when alarm occurs. See Figure 5-18.
  • Page 71 User’s Manual Figure 5-19 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify 154H or delete folder or not. See Figure 5-20.
  • Page 72 User’s Manual Figure 5-21 Please highlight the icon in front of Enable to activate FTP function. Now FTP can upload alarm video and motion detection video. Please note, when you are using this function, please make sure current upload channel is in motion detection or alarm record status and there is video available.

  • Page 73: Alarm

    User’s Manual 5.3.6 Alarm Please refer to chapter 4.6 Alarm Setup and Activation. 5.3.7 Detect Please refer to chapter 4.5 Detect. 5.3.8 Pan/Tilt/Zoom The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 5-24. 427H Protocol: select corresponding PTZ protocol such as PELCOD. Address: input corresponding PTZ address.
  • Page 74 User’s Manual Enable tour: activate tour function. Interval: Input proper interval value here. The value ranges from 5-200 seconds. In tour process, you can use mouse or click Shift to turn on window switch function. Stands for opening switch function, stands for closing switch function.

  • Page 75: Default

    User’s Manual In tour mode, you can see the following interface. On the right corner, right click mouse or click shift button, you can control the tour. There are two icons: stands for enabling window switch and stands for enabling window function. See Figure 431H 5-27.

  • Page 76: Search

    User’s Manual Figure 5-28 5.4 Search Search Search Search Please refer to chapter 4.3 Search. 5.5 Advanced Advanced Advanced Advanced Double click advanced icon in the main window, the interface is shown as below. Figure 5-29. There are total seven function keys: HDD management, alarm 433H output, abnormity, manual record, account, auto maintain, and TV adjust.

  • Page 77: Abnormity

    User’s Manual After all the setups please click save button, system needs to reboot to get all the modification activated. Figure 5-30 Click alarm set button, the interface is shown as below. See Figure 5-31(This 435H interface is just like the abnormity setup). Please highlight icon to select the corresponding function.

  • Page 78: Alarm Output

    User’s Manual Alarm output: alarm activation output port (multiple choices), among which is controllable 12V output. Latch: here you can set corresponding delaying time. The value ranges from 10s- 300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.

  • Page 79: Auto Maintain

    User’s Manual Add new user Modify user Add group Modify group Modify password. For account management please note: System account adopts two-level management: group and user. No limit to group or user amount. For group or user management, there are two levels: admin and user. The user name and group name can consist of eight bytes.

  • Page 80: Tv Adjust

    User’s Manual Figure 5-35 5.5.7 TV Adjust Here is for you to adjust TV output setup. See Figure 5-36. 440H Please drag slide bar to adjust each item. After all the setups please click OK button, system goes back to the previous menu. Figure 5-36 5.5.8 Video Matrix Some series DVR have the matrix and loop outputs.
  • Page 81 User’s Manual Figure 5-37 5.5.8.4 37-pin cable introduction There are three colors cable. See Figure 5-38. 442H Black: for loop outputs, there are 16-ch loop outputs Blue: for matrix outputs, there are 4-ch matrix outputs White: for bi-direction talk, one is for audio in and the other is for audio out. Figure 5-38 5.5.8.5 Matrix setup 5.5.8.5.1 Enter Video Matrix Interface...
  • Page 82 User’s Manual 5-40. Figure 5-40 5.5.8.6 Video Matrix Interface and Application The video matrix interface is shown as in Figure 5-41. 445H You can set for each channel. The function consists of three types. The priority is: alarm>motion detection>schedule. 5.5.8.6.1 Scheduled Video Output (Scheduled Tour) Please enable corresponding video output item and input tour interval, and then set the tour output channel.
  • Page 83 User’s Manual Please go to alarm setup interface to set the alarm activate matrix function ((Main Menu->Setting->Alarm)). See Figure 5-42. You can follow the steps listed below: 446H Select local alarm The record channel function has been enabled and you have selected corresponding record channel.
  • Page 84 User’s Manual Highlighted here Select alarm input channel Corresponding to video out put in Figure 5-41. Highlighted here Figure 5-42 5.5.8.6.3 Motion Detection (including video loss and camera masking) Motion detection principle is the same as alarm. You can set in motion detection interface (Main menu->Setting->Detect).

  • Page 85: Information

    User’s Manual When system is in scheduled tout status, once the alarm occurs, system first check video matrix function has been enabled or not and there is effective matrix or not. System will continue implementing scheduled tour in the following two conditions: Video output function has not been enabled.

  • Page 86: Bps

    User’s Manual Once there is a hard disk confliction, please check hard disk time and system time is the same or not. Please go to setting then general to modify system time. At last, reboot the system to solve this problem. If disk is damaged, system shows as “?”...

  • Page 87: Version

    User’s Manual Figure 5-47 5.6.4 Version Here is for you to view some version information. See Figure 5-48. 452H Channel Alarm in Alarm out System version: Build Date Figure 5-48 5.6.5 Online Users Here is for you manage online users. See Figure 5-49.

  • Page 88: Exit

    User’s Manual Figure 5-49 5.7 Exit Exit Exit Exit Double click exit button, system pop up a dialogue box for you to select. See Figure 454H 5-50. Logout menu user: log out menu. You need to input password when you login the next time.

  • Page 89: About Auxiliary Menu About Auxiliary Menu

    User’s Manual 6 6 6 6 About About About About A A A A uxiliary uxiliary uxiliary M M M M enu uxiliary Go to Pan to Pan/Tilt/Zoom Menu /Tilt/Zoom Menu to Pan to Pan /Tilt/Zoom Menu /Tilt/Zoom Menu In the one-window surveillance mode, right click mouse (click “fn” Button in the front panel or click AUX key in the remote control).

  • Page 90: Preset /Patrol / Pattern /B Preset /Patrol / Pattern /Border Function Preset /Patrol / Pattern /B Order Function

    User’s Manual In the middle of the eight direction arrows, there is a 3D intelligent positioning key. Figure 6-4 . Click this button, system goes back to the single screen mode. 459H Drag the mouse in the screen to adjust section size. Figure 6-4 Here is a sheet for you reference.

  • Page 91: Preset Setup

    User’s Manual Figure 6-6 6.2.1 Preset Setup Note: The following setups are usually operated in the Figure 6-2, Figure 6-5 and 463H 464H Figure 6-6. 465H Figure 6-2, use eight direction arrows to adjust camera to the proper position. 466H Figure 6-5, click preset button and input preset number.

  • Page 92: Pattern Setup

    User’s Manual 6.2.5 Pattern Setup Figure 6-5, click pattern button and then click begin button. The interface shows 473H like Figure 6-9. 474H Please go to Figure 6-2 to modify zoom, focus, and iris. Go back to Figure 6-9 and 475H 476H click end button.
  • Page 93 User’s Manual Figure 6-11 EVD-16/400AxxHN -93- www.eurovideo-cctv.com...

  • Page 94: Web Client Operation Web Client Operation

    User’s Manual 7 7 7 7 W W W W EB CLIENT OPERATION EB CLIENT OPERATION EB CLIENT OPERATION EB CLIENT OPERATION Please note, all the operation here is taking 16-ch DVR as an example. There might be slightly difference in the interface due to different series. 7.1 Network Network Network C C C C onnection...
  • Page 95 User’s Manual If you can’t download the ActiveX file, please modify your settings as follows. See Figure 7-2. 487H Figure 7-2 After installation, the interface is shown as below. See Figure 7-3. 488H Please input your user name and password. Default factory name is admin and password is admin.
  • Page 96 User’s Manual After you logged in, you can see the main window. See 489H Figure 7-6. This main window can be divided into the following sections. Section 1: there are five function buttons: configuration (chapter 7.3), search (chapter 7.4), alarm (chapter 7.5), about (chapter 7.6), log out (chapter 7.7). Section 2: there are channel number and three function buttons: refresh, start dialog and local play.

  • Page 97: Real-Time Monitor

    User’s Manual Figure 7-6 7.2.1 Real-time Monitor In section 2, left click the channel name you want to view, you can see the corresponding video in current window. For detailed function key information, please refer to Figure 7-7. 492H 3 4 5 Figure 7-7 1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in.

  • Page 98: Ptz

    User’s Manual Click local play button, system pops up the following interface for you to select local play file. See Figure 7-9. 494H Figure 7-9 7.2.2 PTZ Before PTZ operation, please make sure you have properly set PTZ protocol. (Please refer to chapter 7.3.2 Setting-> Pan/Tilt/Zoom). Click PTZ button, the interface is shown as in Figure 7-10 .
  • Page 99 User’s Manual System supports eight-level speed. You can select from the dropdown list. Speed 2 is faster than speed 1. 7.2.2.3 Zoom/Focus/Iris Here is a sheet for you reference. Name Function Function Function Function Zoom Near Focus Near Iris close Open Then click triangle icon in Figure 7-10, you can see the following interface.
  • Page 100 User’s Manual Figure 7-12 7.2.2.4 Auto Scan Figure 7-12, move the camera to you desired location and then click left limit 501H button. Then move the camera again and then click right limit button to set a right limit. 7.2.2.5 Pattern Figure 7-12, you can input pattern value and then click start record button to begin 502H PTZ movement.

  • Page 101: Color

    User’s Manual Figure 7-13 7.2.3 Color Click color button in section 3, the interface is shown as Figure 7-14. 507H Here you can select one channel and then adjust its brightness, contrast, hue and saturation. (Current channel border becomes green). Or you can click default button to use system default setup.

  • Page 102: Menu Interface Switch

    User’s Manual Figure 7-16 Click record path button, you can see an interface is shown as in Figure 7-17. 511H Figure 7-17 7.2.5 Menu Interface Switch Put your mouse on the PTZ control bar until you see the following icon. See Figure 512H 7-18.

  • Page 103: Configure

    User’s Manual 7.3 Configure Configure Configure Configure In the main window, click config button, you can see an interface is shown as in Figure 7-20. 515H Figure 7-20 7.3.1 System Information Click device configuration button, you can see the following interface. See Figure 516H 7-21.
  • Page 104 User’s Manual Figure 7-21 Version Click version button, you can see corresponding HDD information for your reference. Figure 7-22. 517H Figure 7-22 HDD Information EVD-16/400AxxHN -104- www.eurovideo-cctv.com...
  • Page 105 User’s Manual Here you can view HDD amount, HDD status, total volume and free space. See Figure 7-23. 518H Figure 7-23 Click log button, you can see an interface is shown as in Figure 7-24. Here you can 519H view current device log information. Figure 7-24 EVD-16/400AxxHN -105-...

  • Page 106: Setting

    User’s Manual 7.3.2 Setting Setting includes the following items: General Encode setup Schedule RS232 Network MUL-DDNS Alarm setup Detect Pan/Tilt/Zoom Tool Please note: setups for different device series may vary. Please refer to the corresponding user’s manual. General General interface is shown as in Figure 7-25.
  • Page 107 User’s Manual Figure 7-25 Encode Encode setup includes the following items. See Figure 7-26. 521H Here you can select Channel: Here is for you to select a channel. Channel name: Modify channel name. Data stream: Regular and extra data stream. AV enable: Video/Audio.
  • Page 108 User’s Manual Figure 7-26 Schedule Schedule includes the following interface. See Figure 7-27. 522H When DVR boots up, it is in 24-hour continuous record. In this interface you can set record type, record time and period. Record type includes regular record(R), motion detection record (M) and alarm record (A).
  • Page 109 User’s Manual Figure 7-27 Figure 7-28 Tip: After you finished setup for one channel, you can click “save as” button, system pops up the following interface. See Figure 7-29.Now you can copy one channel setup to 524H other channels. EVD-16/400AxxHN -109- www.eurovideo-cctv.com...
  • Page 110 User’s Manual Figure 7-29 Network Network interface is shown as in Figure 7-30. 525H This interface includes the following items: Max: Here you can set max connection amount. The value ranges from 0 to 10. 0 means no network connection is allowed. TCP port: default setup is 37777.
  • Page 111 User’s Manual Enable DDNS You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server).see Figure 7-31. 527H Please enable DDNS function and then input PC IP. Click save button and then reboot device.
  • Page 112 User’s Manual Figure 7-32 Mul-DDNS Here you can select DDNS type. This operation needs DVR device supported. See Figure 7-33. 529H Figure 7-33 EVD-16/400AxxHN -112- www.eurovideo-cctv.com...
  • Page 113 User’s Manual After you completed setup here, system upload scheduled data to the specified FTP server regularly. Need device supported. Figure 7-34, you need to input FTP server address, port, log in user name and 530H password. Then you need to specify the destination directory to save files. File: here you can input uploaded file length (Unit: MB) if the file is smaller than the setup value here, system upload the whole file.
  • Page 114 User’s Manual Figure 7-35 Alarm Please note before alarm setup, you need to properly connect alarm input and output device, send address and receive address. Click save button confirm current setup. Alarm setup includes the following items. See Figure 7-36. 532H Event Type: you can select event type from the drop down list: Local alarm/Net alarm.
  • Page 115 User’s Manual Figure 7-36 Figure 7-37 Detect Detect interface is shown as in Figure 7-38. 534H Here includes the following items: Channel: Select channel name from the dropdown list. Type: There are three types: motion detection/Video loss/Camera mask detection. Record channel: Here you can select record channel (Multiple choices). Please make sure you have set MD record in encode interface(Main Menu->Setting- >Schedule) and schedule record in manual record interface(Main Menu- >Advanced->Manual Record)
  • Page 116 User’s Manual Period: Here is for you to set record period. Click set button, you can see an interface is shown as in Figure 7-39. In Figure 7-39, click time set button, you 535H 536H can see an interface is shown as in Figure 7-40.
  • Page 117 User’s Manual Figure 7-39 Figure 7-40 EVD-16/400AxxHN -117- www.eurovideo-cctv.com...
  • Page 118 User’s Manual Figure 7-41 Figure 7-42 Pan/Tilt/Zoom Pan/Tilt/Zoom interface is shown as in Figure 7-43. 541H Please note you have properly set dome address and all connections are right. Decoder: Select the dome connected channel. Protocol: select the corresponding dome protocol.(such as Pelco) Address: Set corresponding dome address.
  • Page 119 User’s Manual Tool Here you can export or import configuration information. See Figure 7-44. 542H Save configuration data: Click export config button to save current setup as a file. Extension name is CFG. See Figure 7-45. 543H Load configuration data: Click import config button, you can load a setup file. Figure 7-44 Figure 7-45 7.3.2.1 Advanced...
  • Page 120 User’s Manual Account interface is shown as in Figure 7-46. Here you can add/delete user, 545H add/delete group, modify user or group right, modify user password. Figure 7-46 Click add group button, you can see the following interface. See Figure 7-47. 546H Here you can add one new group, and then select corresponding rights for the whole group accounts.
  • Page 121 User’s Manual Figure 7-47 Click add user button, you can see the following interface. See Figure 7-48. 547H Here you can input a new user and then select corresponding rights. Please note one user must belong to one group and user right shall not exceed group rights limit.
  • Page 122 User’s Manual Figure 7-48 Record Control Record control interface is shown as in Figure 7-49. 548H Record control: Here you can enable record status for corresponding channel. Alarm output channel: Here you can select alarm output channel. DVR output channel can not support large overload. (It shall be less than 1A). Too heavy current may result in relay damage.
  • Page 123 User’s Manual Figure 7-50 Auto maintenance Auto maintenance interface is shown as in Figure 7-51. Here you can enable auto 550H reboot or auto delete old files function. (Need DVR supported) Figure 7-51 Video Matrix EVD-16/400AxxHN -123- www.eurovideo-cctv.com...
  • Page 124 User’s Manual Video matrix interface is shown as in Figure 7-52. Please note this function needs 551H DVR supported. Figure 7-52 Snap Picture Snapshoot interface is shown as in Figure 7-53. Please note this function needs 552H DVR supported. Figure 7-53 EVD-16/400AxxHN -124- www.eurovideo-cctv.com...

  • Page 125: Search

    User’s Manual 7.4 Search Search Search Search Here you can select video type, channel number and time to search the file you want. Click search button, the interface is shown as below. See Figure 7-54 553H Please use page up/down key to view the search results. Double click file name, you can view the file and system will automatically backup the image in you installation directory.

  • Page 126: Download

    User’s Manual Figure 7-55 7.4.1 Download You can select one or more files you want to download and then click down load button. System pops up a dialogue box asking you specify directory. See Figure 555H 7-56. Figure 7-56 Then you can input file name and click save to backup file in your local pc. During the download process, there is a process bar for you reference and you can see download button becomes stop button.

  • Page 127: Alarm

    User’s Manual Figure 7-57 7.5 Alarm Alarm Alarm Alarm Here you can set alarm type and alarm prompt audio file. See Figure 7-58. 557H Figure 7-58 7.6 About About About About Click about button, you can view current web client information. See Figure 7-59.

  • Page 128: Log Out

    User’s Manual Figure 7-59 7.7 Log out Log out Log out Log out Click log out button, system goes back to log in interface. See Figure 7-60. 559H Figure 7-60 7.8 Un Un- - - - install install install install W W W W eb eb C C C C ontrol ontrol ontrol...

  • Page 129: Enterprise Professio Enterprise Professional Surveillance Sys Nal Surveillance Sys Nal Surveillance System Tem

    User’s Manual 8 8 8 8 Enterprise Enterprise Enterprise Enterprise Pro Professional fessional fessional fessional Surveillance System Surveillance System Surveillance System Surveillance System In this chapter, we introduce how to add devices and how to enable monitor function. For detailed operation, please refer to enterprise professional enterprise surveillance system user’s manual.

  • Page 130: Enable Monitor

    User’s Manual Figure 8-2 8.2 Enable Enable M M M M onitor onitor Enable Enable onitor onitor After successfully logged in, please select the device and then click ）. connect/disconnect button（ ） again. Select the channel you wan to view, click connect/disconnect button（ Section 5 Section 1 Section 2...

  • Page 131: Add New Device

    User’s Manual Figure 8-3 There are totally six sections: Section 1: There are eight function keys: monitor, E-map, record, save, alarm, configuration, log and system. Section 2: Here is for you to view channel video. Section 3: Here is for you to select display mode. System supports various display modes.
  • Page 132 User’s Manual Add device Add organization structure Figure 8-5 EVD-16/400AxxHN -132- www.eurovideo-cctv.com...

  • Page 133: Rs232 Operation Rs232 Operation

    User’s Manual 9 9 9 9 RS232 RS232 RS232 RS232 O O O O peration peration peration peration 9.1 Network Network C C C C onnection onnection Network Network onnection onnection Before serial port operation, please connect matrix with DVR through RS232. Then set DVR serial port protocol to the corresponding matrix protocol.

  • Page 134: Faq

    User’s Manual 10 FAQ 1. DVR can not boot up properly. There are following possibilities: Input power is not correct. Power connection is not correct. Power switch button is damaged. Program upgrade is wrong. HDD malfunction or something wrong with HDD ribbon. Seagate DB35.1，DB35.2，SV35 or Maxtor 17-g has compatibility problem.
  • Page 135 User’s Manual DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities: HDD ribbon is damaged. HDD is broken. Upgraded program is not compatible. The recorded file has been overwritten. Record function has been disabled. 7.
  • Page 136 User’s Manual PTZ decoder and DVR protocol is not compatible. PTZ decoder and DVR address is not compatible. When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching.
  • Page 137 User’s Manual 16. Burn error /USB back error. There are following possibilities: Burner and DVR are in the same data cable. System uses too much CPU resources. Please stop record first and then begin backup. Data amount exceeds backup device capacity. It may result in burner error. Backup device is not compatible.
  • Page 138 User’s Manual HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: There is no media player. No DXB8.1 or higher graphic acceleration software. There is no DivX503Bundle.exe control when you play the file transformed to AVI via media player.
  • Page 139 User’s Manual EVD-16/400AxxHN -139- www.eurovideo-cctv.com...

  • Page 140: Appendix Aappendix A Hdd Capacity Calcula Appendix Ahdd Capacity Calcula Hdd Capacity Calculation Hdd Capacity Calcula Tion

    User’s Manual Appendix A Appendix A Appendix A Appendix A HDD Capacity Calculation HDD Capacity Calculation HDD Capacity Calculation HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity q that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 141: Appendix B Compatible Usb Drive Appendix Bcompatible Usb Drive List Compatible Usb Drive List

    User’s Manual Appendix B Appendix B Compatible USB Drive List Appendix B Appendix B Compatible USB Drive List Compatible USB Drive List Compatible USB Drive List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below.

  • Page 142: Appendix C Compatible Cd/Dvd Bu Appendix Ccompatible Cd/Dvd Burner List Compatible Cd/Dvd Bu Rner List

    User’s Manual Appendix C endix C endix C Compatible CD/DVD Burner List endix C Compatible CD/DVD Burner List Compatible CD/DVD Burner List Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below.
  • Page 143 User’s Manual EVD-16/400AxxHN -143- www.eurovideo-cctv.com...

  • Page 144: Appendix D Compatible Sat Appen Appen Dix D Compatible Sat Dix D Compatible Sata Hdd Lista Hdd Lista Hdd List

    User’s Manual Appendix D Appendix D Compatible SATA HDD List Appendix D Appendix D Compatible SATA HDD List Compatible SATA HDD List Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below.
