- Page 1 User’s Manual (4 CH DVR) S TA N D A L O N E D V R U S E R’S M A N U A L 4 CHANNEL EVD-04-025A1MJU www.eurovideo-cctv.com...
-
Page 2: Table Of Contents
10- DVR Viewer User Guide ..........11 Warning !! Please use the certified hard driver below to avoid the compatibility problem. HDD Compatibility: Brand Name Capacity Samsung 80GB / 160GB Seagate 80GB / 160GB Maxtor 80GB / 160GB EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 3: 1- Feature
8- Search by Time / Date. 9-Watch dog feature. 10-HDD Volume Indicator. 11-Can use USB to link PC, Player can search Time to Play saving and take photos functions. 12-Internal motion detect feature. 13-Remote Control. 14-Support Audio Recording. EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 4: 2-Specifications
System a monitor Power recover auto restore record mode Power supply DC 12V / 4A(AC110V-240V 50/60HZ) Dimension 220mm x 288mm x 48mm (W x D x H) Weight 1.5KG Audio Input/Output Real Line Recording Audio Function And Playing EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 5: 3-Installation
(2) (3) (1) Audio Input. (2) Audio Output. (3) Video Output : Corresponding to Video Input. (4) Video IN : Cameras to Video Input. (5) Power Input : Please use the power supply attached Adaptor : DC-12V / 4A EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 6: 4-Front Panel
(7) Move Right / Camera 4 Display / Select (8) Menu / Show Percentage of the hard Drive recorded (9) Play / Pause (10) Record / Stop (11) Fast Reverse / Mute (12) Fast Forward / Sequence Switch EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 7: 5- Operating Manual
PASSWORD CHANGED (2) If the passw ord was not accepted, you will receive a message that inform you. NO PASSWORD CHANGED *Use the view control button on the front panel to input the number. EVD-04-025A1MJU www.eurovideo-cctv.com... - Page 8 QUAD MODE (quad recording). In this mode invalid. (2) Video Quality : video quality selection: High, Normal, Low (3) Record Frame Rate: QUAD MODE frame rate alternatives as follows: Enable Audio Record → 30-15-10-7-5-4 fps. Disable Audio Record → 30-15-10-7-5-4-3-2-1 fps. EVD-04-025A1MJU www.eurovideo-cctv.com...
-
Page 9: 6-View Control
(Ch3),return to Quad Mode by press again. Camera #4 (Ch4),return to Quad Mode by press again. (2)View Control is only valid while the RECORD MODE is in the EACH MODE. QUAD Display, Enable / Disable theAuto switching function. EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 10: 7-Playback Control
Continue to press and show X8 , playing. *Press to rewind the playback. *Press to pause. *Press to stop. 8-RECORD CONTROL (1)Press to start recording. (2) During recording, the mark * appears in status of overwriting EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 11: Channel Recording Hours
1,550 Ho urs EA CH MOD E Nor mal 90 Ho urs 180 Ho urs 360 Ho urs 2,250 Ho urs (Full Sc reen) Bas ic 118 Ho urs 236 Ho urs 472 Ho urs 2,950 Ho urs EVD-04-025A1MJU www.eurovideo-cctv.com... -
Page 12: 10-Dvr Viewer User Guide
PC directly, or via USB adaptor B. Software Installation Run Setup.exe in the CD-ROM and follow the instruction to finish the installation. [Make sure that the OS of your PC is Windows 2000 SP4/Windows XP SP2 or later. EVD-04-025A1MJU www.eurovideo-cctv.com... - Page 13 Click “Play” icon on the control panel of the PC Viewer to start viewing the video files. DVR PC Viewer A. User Interface The default page of the application is DVR Storage Device PC Viewer. The user interface is shown in Fig.2. EVD-04-025A1MJU www.eurovideo-cctv.com...
- Page 14 When there are more than one DVR storage devices, this button will be activated. Press this button when you want to see video/audio stream stored in other DVR storage device. Fig.3 shows DVR storage device selection window. Fig.3. DVR Storage Device Selection Window EVD-04-025A1MJU www.eurovideo-cctv.com...
- Page 15 (or [->] Key) to start normal playback. *Press button (or [->] Key) to start fast forward playback. By pressing this button several times, you can adjust the speed. The maximum speed is 8 times faster than normal playback. EVD-04-025A1MJU www.eurovideo-cctv.com...
- Page 16 Once sound is enabled, the button icon will be changed to . Press it to disable sound again. Using the slider bar, you can adjust the volume. MYS Player A. User Interface Fig. 9 shows the user interface of the MYS player. EVD-04-025A1MJU www.eurovideo-cctv.com...
- Page 17 When an MYS file selected and being played, the file name and the file size will be displayed in the MYS file information box. IV. MYS file Playback Control Buttons Use MYS file playback buttons to control the playback. Fig.10. MYS file playback control Buttons EVD-04-025A1MJU www.eurovideo-cctv.com...
-
Page 18: Application Setting
Fig.12. Application Setting Dialog B. Functions I. Capture Directory You can specify Capture Directory. To change the path, press Change Button, select directory you want, and press OK again. II. Message Box You can enable/disable the application close confirm message box. EVD-04-025A1MJU www.eurovideo-cctv.com... - Page 19 User’s Manual (4 CH DVR) EVD-04-025A1MJU www.eurovideo-cctv.com...
