Page 1: Channel Digital Video Recorder
User Manual Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without Notice 8 Channel Digital Video Recorder User’s Manual EVD-08/050A1MJN www.eurovideo-cctv.com... -
Page 2: Safety Precautions
ON-OFF switch is the ON position. The power cord is the main power disconnect for all unites. There are no serviceable parts for this unit, call for your agent for Warranty details. and Service EVD-08/050A1MJN www.eurovideo-cctv.com... -
Page 3: About This Document
3. Put the DVR unit at well-ventilated place and do not put heat-generating objects on the unit. When it is installed inside 19 inch mounting rack together with other devices, please check built-in ventilation fan of the rack is properly running. EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 4 - Consult the dealer or an experienced radio/TV technician for help. * You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. EVD-08/050A1MJN www.eurovideo-cctv.com...
-
Page 5: Front Panel
17. T-SRH : Press this button to playback time search 18. PLAY BUTTON : Press this button to playback 19. + BUTTON : Increase + values change. 20. REC BUTTON : Press this button to start recording image EVD-08/050A1MJN www.eurovideo-cctv.com... -
Page 6: Rear Panel
Power code in 12V/5A, power switcher (ON / OFF) Camera 1 ~ 8 input BNC type Monitor out VGA out (Optional) Audio channel input x 1 and output x 1 Alarm / Relay / RS 485 connector RJ-45 (Network connector) EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 7 DVR Initialing or detect a new hard disk **Notice** Please set HDD to Master if only one installed. Live screen Recording icon Overwrite Motion Alarm Event (Motion / Alarm) Video loss Keypad lock * 111111 is the default password EVD-08/050A1MJN www.eurovideo-cctv.com...
-
Page 8: Mouse Control
2. One-click on the value of item 3. One-click on the Exit to quit and save menu 4. From right-up to left-below and the set motion ○, detect area ○, ○, Operate: MENU BUTTON : Press MENU button to enter menu setup or exit EVD-08/050A1MJN www.eurovideo-cctv.com... -
Page 9: Enter Button
: Press this button to playback time search PLAY : Press this button to playback REC BUTTON : Press this button to start recording image + BUTTON : Increase + values change - BUTTON : Reduce - values change EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 10 Right adjustment of each element will increase picture quarterly displayed. We recommend you to adjust each element of cameras and monitor to be connected to the DVR unit. Main MENU – Camera Set – Display (Channel mask, but it still do recording.) EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 11 User Manual Main MENU – Camera Set – Title Camera title setup function allows 5 characters for each channel. Select Shift to next page and then Enter to confirm camera title. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 12 High / Normal / Low 5 / 10 / 15 / 20 / 25 / 30 Record Set – Auto Record Record Set - Data Retention Set After 1 ~ 8 minutes, auto start to record 1 ~ 15 days EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 13 2. In 24 hours, user can adjust each channel frame rate of different record mode. Such as schedule, motion detection, and alarm record more. 3. Press button to change different of record modes. 1. Schedule record mode 2. Motion record mode EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 14 20 K x 30 (frame rate) x 60 (mins) x 60 (secs) = 2160000 K = 2160 M / hr 2160 M / hr x 24 = 51840000 K = 51840 M = 51.84 G / (1 Day) Please format hard disk before starting recording after all the HDD installation EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 15 Alarm Signal type depends on Alarm Sensor polarity define on NO (N/Open) or NC (N/Close) mode. Alarm POP UP: Event channel jump to full screen when alarm triggered. 9 Split screen with the alarm symbol if there is more than two cameras triggered. Door closed Door open EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 16 NO + COM: Normally, motion relay is NO + COM connector. Relay action: Relay: NO (Normal open) Alarm trigger Relay: NC (Normal Close) Main Menu – Motion Detection Main Menu – Motion Detection – Motion Area cursor Detected area EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 17 One-click of the mouse left button to cancel detect area. Select start (right-up corner) point and end (left-below corner) point of detect area. Main Menu – Screen – Border: Quad border On / Off display Main Menu – Screen – Video Adjustment: Video screen position movement EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 18 - If microphone, audio line in or any how, user please set the audio record mode to on and also adjust volume input or output to right sound effects. - Mute means live audio is turn on or quiet. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 19 HDD was formatted successful. - Before hard disk format, user needs to put the right password. The password is same as unlock which is default 111111. - Please set HDD to Master if only one installed. Second one to Slave. EVD-08/050A1MJN www.eurovideo-cctv.com...
-
Page 20: Menu Protection
Main Menu – System Set – Time Set Select time zone and auto time synchronization with NTP server. Network is required on NTP server. NTP server does not work under network DHCP mode. After time set or daylight mode EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 21 Main Menu – System Set – Network Settings Network Settings – Local IP Network Settings – Local IP – STATIC Network Settings – Local IP – DHCP Select static IP address / Gateway / Net Mask Auto IP detected under IP sharing or router EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 22 Main Menu – System Set – Network – PPPOE – ID If the DVR is under a network system, suggest enable Main Menu – System Set – Time Set NTP server to get a network request automatically. Main Menu – System Set – Network – PPPOE – Password EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 23 User type the IP to Net viewer or IE browser to view image via network. Main Menu – System Set – Network – D/DNS set Ex: Enter in www.dyndns.com to apply a free account and host name. Click Create Account to make a new ID name. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 24 Fill in all the personal information, password, email requested; please go to user’s email account to active your new account. Return to DynDNS website; click Account to long in page. cv1000 123456 Type your applied Username and Password Logged In page Click “My Services” icon EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 25 User Manual Click Add Host Services: Click “Add Host Service” Add static DNS Host: Select Static DNS: add Static DNS Host EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 26 User Manual Type a Hostname user decided. No useful df6020 Add Host Ex: Create a new df6020 host name, after add a new host name; DynDNS page shows a confirm message page. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 27 Advice user apply network speed Upload 512K / Download 512K or more, to avoid image data too big influence the remote quality. DNS only works under DDNS mode. Main Menu – System Set – RS-485 It follows the camera baud rate Don’t care Don’t care Don’t care EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 28 PTZ dome. It is normal if no any action after press AUTO. Main Menu – System Set – F/W Upgrade Stop all hard disk working before update, select F/W upgrade and then press ENTER to search firmware. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 29 User Manual Press PLAY to start version update. DVR auto reboot after version update. HDD needs to be installed before update. Main Menu – System Set – BUZZER SETUP EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 30 Steps: CD disk ActiveX USB pan drive DVR (with hard disk) USB Menu - System Set – Load Active-X Control ENTER button 2. Also install ActiveX to your personal computer. Net viewer is packaged with ActiveX.exe. Main Menu – Search Main Menu – Search – TIME LIST EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 31 Press ENTER to select date and time. Direction left and right button to move value item. ENTER or + / - button to change value. Main Menu – Search – Time Search: after date and time select, go to Search and then press ENTER to start playback. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 32 Reverse speed: x 8 / x 16 / x 32 (Direction left button) Press STOP to search list, press ESC to live mode. Backup mode: Before backup, USB pan driver is required. Back up file size can not exceed EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 33 After select backup time, apply to count data size. After size appears, press backup button to USB page. DVR is reading pan driver After a while, all backup information display on screen, user now can press backup button to start file backup. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 34 Press + and – to select backup time. User only can increase seconds in this backup way. Press backup button to USB page which is same as mode 1. Mode 3: On mode 2, user can press T-SRH button to the page like mode 1, and then to mode 3. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 35 Mode 4: On event list, choose an event record data, and then press backup button. Pages go to USB page, after data size appears, press backup button to the page which is same as mode 1 USB compatible(Max. 4G) ADATA / Transcend / San Disk / Kingston EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 36 : Press Enter button to confirm set or value change(+) / Shift mode DIRECTION BUTTON : MENU item select + BUTTON : Increase + values change - BUTTON : Reduce - values change BACKUP : To backup mode EVD-08/050A1MJN www.eurovideo-cctv.com...
-
Page 37: Viewer Function
6. DVR direction button: Up (Item select, Play Stop) / Down (Item select, Play Pause) Left (Item select, Play Reverse) / Right (Item select, Play Forward) ENT (ENTER): Item confirm/select, values change) 7. DVR menu pop-up 8. Audio volume (PC site) EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 38 Viewer function setup Always on Top: Player or viewer always on top even other data folders open Auto Reconnection: Reconnection if non artificial network disconnect. Path for local recording: Please select a path of your PC. About Viewer Viewer version EVD-08/050A1MJN www.eurovideo-cctv.com...
-
Page 39: Player Button
User Manual Exit Close viewer File Player: Click browser to open file which you saved Player button Open \ Fast Backward \ Play Reverse \ Previous Frame \ Pause \ Next Frame \ Play EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 40 Show the backup beginning time Always on Top Player always on top even other data folders opened Playback Play back mode and speed select. Same as Player button Audio Audio volume adjust (PC site) Full screen Player screen to full size EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 41 Exit Player and viewer exit Options User creates or selects a record path Always on top: Player always on top even other data folders opened Show time: Show the PC time of when user start recording backup file EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 42 VVF file export to AVI Click audio on if the image includes audio. Browse the file source Browse a path for file output File preview Select a compression codec Percentage of the export AVI progress Users please wait until file export completed. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 43 Zoom -- / + : Lens, Near / Far Menu: Call PTZ OSD Enter: OSD value confirm Channel: Select PTZ channel Preset: Preset setup Select preset 1 ~ 8, and then click SET to save. Click CALL to run preset. EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 44 3. Before DVR IE connection, please download the ActiveX to DVR hard disk from CD-ROM, and then you can view DVR image via internet any PC. Steps: CD disk ActiveX USB pan drive DVR (with hard disk) USB Menu - System Set – Load Active-X Control ENTER button EVD-08/050A1MJN www.eurovideo-cctv.com...
-
Page 45: Specification
Time list / event list / Date & Time search Other Function Operation Mode Record / Play / Network Motion Detect 16 x16 grids camera for all channel Alarm Alarm in x 8 / Relay out x 1 Back-Up USB 1.1/2.0 memory and network remote backup EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 46 Client Application Display / playback / PTZ / DVR control Power Supply DC 12V / 5A Weight N.W./G.W. 3.06kg/3.68kg Dimension 426(W) x 328.5(D) x 65(H) mm Operating Temperature 41 ºF~104 ºF (5 ºC~+40 ºC) Operating Humidity Less than 90% EVD-08/050A1MJN www.eurovideo-cctv.com...
-
Page 47: Sata Installation
SATA INSTALLATION Accessories: SATA converter board 1. Power jack 2. SATA interface port Accessories: 1. SATA type Hard disk 2. SATA converter board 1. SATA converter board 2. SATA type Hard disk EVD-08/050A1MJN www.eurovideo-cctv.com... - Page 48 DVR main board and SATA converter board power cables connection Also make IDE connected. After all cables connected, put hard disk back to screws position base. Make all screws fixed Move back the DVR front case and done EVD-08/050A1MJN www.eurovideo-cctv.com...
- Page 49 User Manual SATA type Hard disk compatible Hitachi series 80 ~ 750 GB OK WD(AAJB) series 80 ~ 750 GB OK EVD-08/050A1MJN www.eurovideo-cctv.com...
