Hanover back panel

88 5532 14

Hanover Back Panel

IMPORTANT NOTE

Carefully remove all the parts from the carton and put

them individually on a soft cloth to prevent scratches

or other damages occuring to the wood parts.

We have taken great care in the design of this

product and request that you carefully and strictly

follow our assembly instructions to ensure a

completed product as it was designed.

THIS BACK PANEL IS FOR DECORATIVE PURPOSES ONLY

Do not attach a television or anything else to the back panel.

Part List

Back Panel

1 pc.

Hex Wrench

1 pc.

Tools required for assembly : Phillips screwdriver

Casual Attire For Today's Home

Spring Washer

Head Cap Bolt

4 pcs.(+1 extra)

Batten

2 pcs.

Wood Screw

Flat Washer

8 pcs.(+1 extra)

4 pcs.(+1 extra)

Table of Contents

Do you have a question about the 88 5532 14 and is the answer not in the manual?

Page 1 88 5532 14 Hanover Back Panel IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this...
Page 2 Assembly Instructions IMPORTANT Do not tighten up all the screws until each part is properly assembled. STEP 1 Attach the Battens (B) at the pre-drilled holes fo Back Panel (A) with Flat Washers, Spring Washers and Head Cap Bolts. (see figure 1) (Figure 1) Place the assembled unit onto the center console.
