Network Select Dip Switch Settings - 3Com CoreBuilder 5000 User Manual

Table 3-2 and Table 3-3
Table 3-2 describes the switches used for selecting a default network
connection. Switches 1 through 4 enable users to configure all ports
for one of the backplane segments (token_ring_1 through
token_ring_10) or as a module-level ring (isolated).
Table 3-3 describes the remaining DIP settings.
A complete definition of each DIP switch function appears
in Chapter 4.
Table 3-2

Network Select DIP Switch Settings

Network Selection
1 (default)
2
3
4
5
6
7
8
9
10
*
isolated
* Any combination of settings that does not match a specific backplane network causes the
module to be isolated.
Setting the DIP Switches
describe the DIP switch settings as follows:
*
Switch Settings
Switch 1 Switch 2
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
OFF OFF
3-7
Switch 3 Switch 4
OFF OFF
OFF OFF
OFF OFF
ON OFF
ON OFF
ON OFF
ON OFF
OFF ON
OFF ON
OFF ON
OFF OFF
