Figure 1-4 illustrates the CoreBuilder 5000 Token Ring Dual Fiber
Repeater Module.
Actively-retimed
lobe ports
Figure 1-4

CoreBuilder 5000 Token Ring Dual Fiber Repeater Module

CoreBuilder 5000 Token Ring Modules
MODULE
STATUS
LED panel
1 2
4
3
5 6
8
7
9 10
RO1
RI1
RI2 RO2
JA2
JA1
Fiber Ring-In/Ring-Out
ports
1-13
