Figure 1-2
illustrates the CoreBuilder 5000 Token Ring Active
Per-Module Switching Media Module.
Actively-retimed
lobe ports
Figure 1-2
CoreBuilder 5000 Active Per-Module Switching Media Module
CoreBuilder 5000 Token Ring Modules
1
4
LED panel
7
10
13
16
Ports 17 and 18
configurable as
Ring-In/Ring-Out ports
1-9
