1-6 I
NTRODUCTION
Figure 1-1 illustrates the CoreBuilder 5000 Token Ring Active Per-Port
Switching Media Module.
Actively-retimed
lobe ports
Figure 1-1

CoreBuilder 5000 Active Per-Port Switching Media Module

1
4
LED panel
7
10
13
16
Ports 17 and 18
configurable as
Ring-In/Ring-Out ports
