SPECIFICATIONS
Ethernet Connections
• 10/100 BaseT
• Auto Negotiation
• AutoCross
• Flow Control
• 1916 MTU
• Full Line-Rate Forwarding
AC Wall Adapter
100 to 240 ±10% VAC input, 5 VDC output, 2A max.
Operating Temperature
+14°F to +122°F (-10C° to +50°C)
Storage Temperature
-31°C to +167° F (-35C° to +75°C)
Humidity
5% to 95% (non-condensing), 0 – 10,000 ft. altitude
Input Power Consumption (Typical, varies with optical transceiver
type)
500 mA @ 5 VDC
Dimensions
0.83"H x 1.80"W x 3.35"D (2.11 x 4.57 x 8.51 cm)
NOTE
Use only the supplied B+B SmartWorx wall adapter or USB cable with
this product. Using a non-B+B SmartWorx power source will void the
warranty.
10
