FUNKY MONKEY BARS Floating Flying Fox Assembly Instructions Manual page 6

ASSEMBLY TIPS (continued)
IT IS CRITICAL YOUR MAIN FRAME IS 100% SQUARE AND LEVEL
Check assembly is 100%
level, square & straight.
If your frame is not straight or level remove pegs, loosen
grub screws, re-adjust re-tighten and re-peg the frame.
If your frame is being installed on a slope ensure the monkey
ladder bar is level. Either install at different heights on the legs
FIXING TYPICAL ORIENTATION
Unless otherwise stated all grub
screws and fittings should face
downwards and outwards. This will
reduce weathering damage, help with
assembly and ease of maintenance.
Page 5
PLAN VIEW
SIDE VIEW
INSTALLATION ON A SLOPE
or dig down at one end until level.
