Precision Digital Corporation PD500 Quick Start Manual

PD500
SuperNova PID Process & Temperature Controllers
▍ Features
• 1/16, 1/8 (V), and 1/4 DIN Auto-Tuning PID
Process & Temperature Controllers
• Reverse Polarity Three-Color LCD: -1999 to 9999
• Thermocouple and RTD Inputs
• DC Voltage and Current Inputs (1-5 V, 0-5 V,
0-10 V, 0-50 mV, 0-100 mV; 4-20 mA with Resistor)
• 250 Ω Resistor(s) Included Standard
• High Accuracy Auto-Tuning PID
• High Durability IP65 Front with Hard Plastic
Pushbuttons
• Large Easy to Read 14-Segment PV Display
up to 1.1" (29 mm)
• Input Power 100-240 VAC
• Heating, Cooling, and Heating & Cooling Control
• Primary Control Output Options: 4-20 mA (SCR),
Voltage Pulse (SSR), or Relay
• Secondary Control Output Relay Standard
on All Models
PRECISION DIGITAL CORPORATION
PD530
This Quick Start Guide is intended to
provide basic information about the
SuperNova controllers. A complete
instruction manual is available for
download at www.predig.com.
PD520
• Easily Switch Between Auto and Manual
Control Modes
• Up to 2 Alarm Relays & 4-20 mA Retransmit
Outputs
• Remote Set Value 1-5 V Input Option
(4-20 mA with External Resistor)
• Digital Input Set Value Selection
• RS-485 Serial Communications Option
• Modbus RTU/ASCII Communications
®
• Mini-USB Port Standard
• FREE Programming and Monitoring Software
• Shallow Depth Case Extends Only 2.5" (63 mm)
Behind Panel
• UL & C-UL Recognized Process Control
Equipment, Electrical – Component
Quick Start Guide
PD510
www.predig.com
