Chapter 3: System Setup
7. Plug in the HDD SATA cable** and SATA power cable*, lock the screw
into the system.
Note: HDD SATA cable should be installed at CN7 of the
mainboard. SATA power cable should be installed at CN9 of
the mainboard.
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
8. Plug in the SSD SATA cable** and SATA power cable*.
Note: 2.5" SSD/HDD SATA cable should be installed at CN1
of the mainboard. 2.5" SSD/HDD SATA power cable should
be installed at CN2 of the mainboard.
36
NViS 14162 Series User Manual
