Chapter 4: BIOS Setup
PCH-IO Configuration
This section is used to configure PCH-IO configuration.
Aptio Setup - AMI
Main
Advanced
Chipset
Security
PCH-IO Configuration
SATA Configuration
►
►
USB Configuration
State After G3
[S0 State]
Version 2.21.1278. Copyright (C) 2021 AMI
SATA Configuration
Configures SATA drives.
USB Configuration
Configures the USB.
State After G3
Configures the power state when power is re-applied after a power failure
(G3 state).
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
Boot
Save & Exit
SATA Device Options Settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA Configuration
This section is used to configure the SATA device option settings.
Aptio Setup - AMI
Main
Advanced
Chipset
SATA Configuration
SATA Controller(s)
SATA Mode Selection
SATA Ports Multiplier
SATA Test Mode
Serial ATA Port 0
Software Preserve
Port 0
Hot Plug
Serial ATA Port 1
Software Preserve
Port 1
Hot Plug
Version 2.21.1278. Copyright (C) 2021 AMI
SATA Controller(s)
Enables or disables the SATA controller.
SATA Mode Selection
Configures the SATA as AHCI mode.
AHCI
This option configures the Serial ATA drives to use AHCI
(Advanced Host Controller Interface). AHCI allows the storage
driver to enable the advanced Serial ATA features which will
increase storage performance.
56
Security
Boot
Save & Exit
Enable/Disable SATA Device.
[Enabled]
[AHCI]
[Disabled]
[Disabled]
Kingston 0M4PO (128.0...
SUPPORTED
[Enabled]
[Disabled]
WDC WD80PUZX-6 (8001....
→←: Select Screen
SUPPORTED
↑↓: Select Item
[Enabled]
Enter: Select
[Disabled]
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
