- Page 1 Installation Operation Care • • ® ™ Vignette Traversed ™ with Vertiglide Modern Roman Shades...
-
Page 2: Table Of Contents
CONTENTS Getting Started: Product View — Side Stack ........... 1 Product View — Split Stack ........... 2 Tools and Fasteners Needed .......... 3 Installation: Installation Overview ............. 4 Unpack the Shade ............4 Mount the Installation Brackets ........5 Install the Headrail ............8 Install the Fabric Into the Headrail ........ -
Page 3: Getting Started
GETTING STARTED Product View — Side Stack Installation Brackets Stationary Roller Rail Headrail Hanger Stationary Side Close-Up Trike Moving Side Close-Up Moving Rail Return (Optional) Handle Stationary Rail Vertical Rail End Cap and Cords Rail Stabilizer... -
Page 4: Product View - Split Stack
GETTING STARTED Product View — Split Stack Installation Brackets Stationary Rail Hanger Roller Headrail Trikes Stationary Rail Hanger Trike Stationary Side Close-Up Moving Side Close-Up Stationary Rail Handles Stationary Return Rail (Optional) Return (Optional) Vertical Rail End Cap Cords Rail Stabilizer Moving Rails... -
Page 5: Tools And Fasteners Needed
GETTING STARTED ® ™ ™ Thank you for purchasing Hunter Douglas Vignette Traversed with Vertglide Modern Roman Shades. With proper installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 6: Installation: Installation Overview
INSTALLATION Installation Overview ■ The number of installation brackets required varies with headrail width, as shown below. ® ™ ™ IMPORTANT: All Vignette Traversed with Vertiglide Modern Roman Shades must be mounted outside the window casement. Shade Side Split Width Stack Stack Installation... -
Page 7: Mount The Installation Brackets
INSTALLATION ■ Unpack the top of the shade. ➤ Peel back the plastic tape from the packing rail at the top of the shade. ➤ Peel away the colored tape securing the cords Packing to the packing rail. Rail ➤ Leave the remaining colored tape which secures the cords in place. - Page 8 INSTALLATION ■ Mark 2" in from each end of the headrail. ➤ If more than two installation brackets came with your order — space additional bracket(s) evenly (or at least every 36") and mark their location. Side Stack Headrail End Marks 2"...
- Page 9 INSTALLATION ■ Fasten the installation brackets to the mounting surface using the screws provided. ➤ If using spacer blocks, insert the legs of the installation " bracket into the tabs on the Spacer Block (Optional) spacer block. ➤ Then rotate the installation "...
-
Page 10: Install The Headrail
INSTALLATION Install the Headrail Tabs Angled Down Toward ■ Wide headrails may arrive in two separate pieces. Headrail Joining Plate Connect the two pieces with a joining plate. ➤ Insert the joining plate into the top back channel of one of the headrail pieces. The tabs on the joining plate are slightly angled. -
Page 11: Install The Fabric Into The Headrail
INSTALLATION Install the Fabric Into the Headrail Side Stack Trike Cords in the ■ With the fabric colored side facing you, correct position. align the trike with the middle channel in the headrail on the moving rail side. IMPORTANT: Be sure the cords are routed to the outside of the trike before sliding the trike into the channel. -
Page 12: Secure The Stationary Rail Hanger
INSTALLATION Secure the Stationary Rail Hanger ■ Angle the stationary rail toward you and then into the back channel on the Side Draw: End Cap headrail. This will enable you to place the Removed for Clarity lip of the hanger onto the middle lip of the headrail. -
Page 13: Install The Stationary Rail Stabilizer
INSTALLATION Install the Stationary Rail Stabilizer A side stack shade has only one stationary rail. A split stack shade has two stationary rails. Follow the instructions below to install the stabilizer for each stationary rail. ■ Use a level to ensure the stationary rail is vertical. Mark the edge Then mark the edge of the stationary rail near the of the rail on... -
Page 14: Secure The Cords - Side Stack
INSTALLATION Secure the Cords — Side Stack ■ Close the shade completely. ■ Attach the end cap. ➤ Loosen the screw on the end cap until it is fl ush with the top of the end cap. ➤ Holding the cords below the end cap, push the end cap into place on the end of the headrail. - Page 15 INSTALLATION ■ Third, fi nd the two marks on the front channel of the headrail. Hook the cord anchor in between the two Marks marks. IMPORTANT: The three cords attached to the cord anchor may have slack. The slack in the cords will be addressed later in these instructions.
-
Page 16: Operation
OPERATION Operate the Shade For better support and smoother operation, use the handle when opening and closing the shade. To Open the Shade ■ Slide the handle toward the stationary rail to open the shade. Allow the shade to stack evenly. To Close the Shade ■... -
Page 17: Troubleshooting
OPERATION Troubleshooting Problem Solution ■ The shade If the shade does not slide easily, you may need to adjust the cord binds or moves anchor. Close the shade, then slide the cord anchor toward the with diffi culty. moving rail in ¼" increments to decrease the tension. ■... - Page 18 OPERATION Problem Solution ■ The moving rail To adjust the vertical is not vertically alignment of the moving rail, aligned. turn the set screw on the trike located in the headrail. Use the Allen wrench provided. Turn to adjust moving rail ■...
-
Page 19: Care
CARE Removing the Shade Remove the Fabric Panel(s) (If Neccessary) ■ Unscrew the end cap and slide the panel and rollers out of the headrail. Remove the Headrail ■ Open the shade if the fabric is still installed. ■ While holding the headrail, push back Bracket on the bottom tab of each installation Back of... - Page 20 If you are not thoroughly satisfied, simply contact Hunter Douglas at (888) 501-8364 or visit hunterdouglas.com. In support of this policy of consumer satisfaction, we offer our Lifetime Limited Warranty as described below.
