HunterDouglas Sonnette Installation Operation Care
Cellular roller shades, literise operating system
Hide thumbs
Also See for Sonnette:
- Installation operation and care (32 pages) ,
- Installation operation care (24 pages) ,
- Installation manual (33 pages)
Subscribe to Our Youtube Channel
Related Manuals for HunterDouglas Sonnette
Summary of Contents for HunterDouglas Sonnette
- Page 1 Installation Operation Care • • Sonnette ™ Cellular Roller Shades LiteRise Operating System ®...
-
Page 2: Table Of Contents
CONTENTS GETTING STARTED: Product View ................... 1 Tools and Fasteners Needed ..............2 INSTALLATION: Installation Overview ................3 Mount the Installation Brackets — Inside Mount ......... 4 Mount the Installation Brackets — Outside Mount ......6 Install the Shade ..................8 OPERATION: Operate the Shade ................ -
Page 3: Getting Started
GETTING STARTED Product View Installation Brackets Headrail Bottom Rail Bottom Rail End Cap... -
Page 4: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing Hunter Douglas Sonnette cellular roller shades. With proper ™ installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 5: Installation
INSTALLATION Installation Overview Your order will include the correct number of installation brackets for your shade width, as ■ shown in the table below. Shade orders may also include spacer blocks or extension brackets, if they were specified ■ for added clearance. Installation Bracket For Added Clearance Shade Width... -
Page 6: Mount The Installation Brackets - Inside Mount
INSTALLATION Mount the Installation Brackets — Inside Mount Prepare the Installation Brackets Use pliers or heavy duty scissors to remove the top ■ tabs on the installation brackets. NOTE: Save these tabs once removed. They may be Bracket Lever used as shims, if necessary. Remove Tab Mount the Installation Brackets Mark 2"... - Page 7 INSTALLATION Center the brackets on your marks and mark the location of the screw holes. ■ The minimum casement depth required for ➤ installation brackets is 1". The minimum casement depth required for a fully ➤ recessed mount is 3 ⁄...
-
Page 8: Mount The Installation Brackets - Outside Mount
INSTALLATION Mount the Installation Brackets — Outside Mount Prepare the Installation Brackets Use pliers or heavy duty scissors to remove the top ■ tabs on the installation brackets. Bracket Lever NOTE: Save these tabs once removed. They may be used as shims, if necessary. Remove Tab Mount the Installation Brackets Center the headrail over the window opening at the desired height. - Page 9 INSTALLATION Drill the screw holes using a ⁄ " drill bit. ■ CAUTION: Use drywall anchors when mounting into drywall. Attach the installation or extension ■ brackets using the screws provided. IMPORTANT: The top of the installation brackets or extension brackets must be level with their front edges aligned.
-
Page 10: Install The Shade
INSTALLATION Install the Shade Lever Headrail Ensure that each ■ lever is pushed to the left side of the Slide the Headrail Installation bracket before Between the Lever Bracket and the Bracket. installing the shade. Position the shade ■ so that the front faces you. - Page 11 INSTALLATION Attach the Magnetic Hold-Down Brackets (Optional) Lower the shade. ■ Place the magnetic hold-down bracket onto the bottom rail just ■ inside the end cap, oriented as shown. Mark the screw location using the mounting options shown below. ■ The screw should be placed in the middle of the channel.
-
Page 12: Operation
OPERATION Operate the Shade For better support and smoother operation, hold the bottom rail at the center when raising and lowering the shade. To Lower the Shade Slowly and steadily pull down on the ■ bottom rail or optional handle. To Raise the Shade Slowly and steadily push up on the ■... -
Page 13: Troubleshooting
OPERATION Troubleshooting Problem The shade will not fit into the installation brackets. Solution Check that the installation brackets are aligned and level. Adjust and/or shim to level, if necessary. Be sure the heads of the mounting screws are flush against the installation bracket. - Page 14 OPERATION Problem The shade will drift up once stopped. Solution Removing Spring Tension Locate the adjustment behind the left end cap cover. ■ The cover is removed by placing your thumb in the center and releasing ➤ the snap on the top back corner. Raise the shade completely and hold ■...
- Page 15 OPERATION Problem The shade raises or lowers unevenly, the bottom rail is not level when fully raised, or the fabric winds unevenly or starts to rub against one end of the headrail. Solution Keep the bottom rail level while raising the shade. Side-to-side movement while raising the shade may cause fabric to skew.
-
Page 16: Care
Carefully pull the shade away from ■ the brackets to remove it. Cleaning Procedures Sonnette cellular roller shades are made from anti-static, dust-resistant materials which ™ repel dirt and dust. The following options are available if your shade needs cleaning. - Page 17 A Note About Sonnette Fabrics ™ As with all textiles, Sonnette fabric is subject to some variation. Slight wrinkling, puckering, ™ or bowing is inherent to this textile product and should be considered normal, acceptable quality.
- Page 18 Notes...
- Page 20 If you are not thoroughly satisfied, simply contact Hunter Douglas at (888) 501-8364 or visit hunterdouglas.com. In support of this policy of consumer satisfaction, we offer our Lifetime Limited Warranty as described below.
