Customer Menu - Reflex Fillcontrol Auto Operating Manual

Indication on the Meaning
display
• YES: FQIRA+ contact water meter is installed, see
With water meter.
chapter 4.6 "Optional equipment and accessories"
YES
on page 5 .
This is the prerequisite for the make-up volume
monitoring and the operation of a softening
system.
• NO: A contact water meter is not installed
(standard model).
Make-up volume Only displayed if "YES" has been set in the "With water
meter" menu option.
000020 l
• Press "OK" to delete the counter.
• Press "YES" to reset the value displayed to "0".
• Press "NO" to retain the displayed value.
Max. make-up This value is only displayed if "YES" has been set in the
volume "With water meter" menu option.
000100 l • When the set volume is exceeded, the system
interrupts the make-up process and returns the
error message "Max. make-up volume exceeded".
With softening This value is only displayed if "YES" has been set in the
"With water meter" menu option.
YES
• YES: Further queries follow about softening.
• NO: The system does not offer more queries
regarding the softening process.
Disable make-up? This value is only displayed if "YES" has been set in the
"With softening" menu option.
YES
• YES: The system stops the make-up process when
the set soft water capacity is exceeded.
• NO: The system does not stop the make-up
process. The system displays the "Softening"
message.
This value is only displayed if "YES" has been set in the
Hardness reduction
"With softening" menu option.
10 °dH
• Hardness reduction is calculated from the
difference of the overall water hardness GH
and the target water hardness GH
Hardness reduction = GH
Enter the value in the controller. Consult the
manufacturer information for third-party products.
Cap. soft water This value is only displayed if "YES" has been set in the
"With softening" menu option.
05000 l
The attainable soft water capacity is calculated from the
type of softening used and the specified hardness
reduction.
• Fillsoft I, soft water capacity ≤ 6000/hardness red. l
• Fillsoft II, soft water capacity ≤ 12000/hardness
red. l
Enter the value in the controller. Consult the
manufacturer information for the values of third-party
products.
Remaining cap. soft This value is only displayed if "YES" has been set in the
w. "With softening" menu option.
000020 l • Available soft water capacity.
This value is only displayed if "YES" has been set in the
Replacement
"With softening" menu option.
18 months
• Manufacturer specification for the replacement
interval of the softening cartridges, regardless of
the calculated soft water capacity. The system
displays the "Softening" message.
Next maintenance Recommended maintenance messages.
012 months • Off: Without maintenance recommendation.
• 001 – 060: Maintenance recommendation in
months.
Floating fault For the output of messages to the floating contact, see
contact chapter 9.3 "Messages" on page 14 .
YES • YES: Output of all messages.
• NO: Output of all messages identified with "xxx"
("01", for example).
actual
.
target
-GH l °dH
actual target
Fillcontrol Auto — 22.09.2020 - Rev. C
Indication on the Meaning
display
Fault memory˃ Switch to the "Fault memory" sub-menu.
• Press "OK" to open the menu.
• Use the "▼▲" buttons to open the sub-menu.
ER 01...xx The last 20 alarms are stored with fault type, date, time,
and fault code.
See the chapter "Messages" for more information about
the ER... messages.
Parameter Switch to the "Parameter memory" sub-menu.
memory˃
• Press "OK" to open the menu.
• Use the "▼▲" buttons to open the sub-menu.
P0 = xx.x bar The last 10 entries of the minimum working pressure are
stored with date and time.
Date | Time
V0.60 Information about the software version
9.2.1

Customer menu

The device controller is shipped with the following default settings. Use the
Customer menu to adjust these values to local conditions. In special cases, it is
possible to further adjust the values in the Service menu.
Parameter Setting
Language EN
Fillcontrol XX Magcontrol
Minimum operating 1.5 bar
pressure P
0
Safety valve, pressure 3.0 bar
Next maintenance 12 months
Volt-free contact NO
Make-up
Maximum make-up volume 5000 litres
Maximum make-up time 20 minutes
Maximum make-up cycles 3 cycles
within 2
hours
Softening (Only if "With softening yes")
Shut off make-up NO
Hardness reduction 8°dH
Maximum make-up volume 0 litres
Soft water capacity 0 litres
Cartridge replacement 18 months
Controller
Comment
Display language
For systems with diaphragm-type
expansion vessel
Only Magcontrol
see chapter 7.2 "Determining the P
0
minimum operating pressure for
the controller" on page 9
Tripping pressure for the safety
valve at the heat generator in the
system
Time left to the next due
maintenance
Only the messages marked in the
"Messages" list
Only if controller with "With water
meter yes"
Magcontrol
Magcontrol
In the event of soft water residual
capacity = 0
= Setpoint – Actual
Attainable make-up quantity
Attainable water capacity
Replace cartridge
English — 13
