Indirect measurement
Pythagorean measurement is used in the condition that the objective needing to be measured is covered or has no effective relecting
surface and can't be measured directly.
Make sure you adhere to the prescribed sequence of measurement:
• All target points must be in a horizontal or vertical plane.
• The best results are achieved when the instrument is rotated about a ixed point (e.g. with the positioning bracket fully folded out and
the instrument placed on a wall) or the instrument is mounted on a tripod.
• The minimum / maximum function can be used. The minimum value must be used for measurements at right angles to the target; the
maximum distance for all other measurements.
Indirect measurement – determing a distance using 2 auxilary measurements. E.g. When height and distance can't be measured
directly.
Press button () 3 times. The symbol
Press button (2) to take distance measuring
Press button () to take distance measuring
After pressing button (2) the result is displayed in the irst line. The result of the function
Indirect measurement – measuring of right-angle edge length (using hypotenuse and right-angle edge length). E.g. When height
and distance can't be measured directly.
Press button () 4 times. The symbol
Press button (2) to take distance measuring
Press button (2) to take distance measuring
The result of the measurement
is displayed. The distance to be measured is blinking in the symbol triangle.
. The result is displayed in the irst line.
.
is displayed. The distance to be measured is blinking in the symbol triangle.
( hypotenuse). The result of the function is displayed in the irst line.
(height of the triangle) . The result of the measurement is displayed in the irst line.
is displayed in the second line.
is displayed in the second line.
