D12 specifications
Operating temperature +5 – +35 degrees C (do not allow con-
range: densation)
I Specifications
<Recorder section>
Number of tracks: 96 tracks (including virtual tracks)
12 tracks simultaneous playback, 4
tracks simultaneous recording @ 16
bits
6 tracks simultaneous playback, 4
tracks simultaneous recording @ 24
bits
Recording format: 24 bit/16 bit uncompressed, 44.1 kHz
Recording time: 16 bit recording: maximum 19.5 hours
24 bit recording: maximum 9.8 hours
*
When internal 6 Gbyte hard disk is used
Maximum storage internal + external 1,000 Gbytes 7
capacity: drives
Number of songs: 100 songs per drive
Locate points: four points per song
Mark points 100 points per song (marks can be
named)
Metronome patterns: 96
Rhythms: 215
MMC functions: Transmitted and received
Synchronization: MTC transmission, MIDI Clock trans-
mission
Tempo map (200 points per song)
Sync track (1 track per song)
Tempo rec
CD-R/RW functional- Create audio CD, backup/restore,
ity: import WAV file (ISO 9660)
SCSI functionality: Recording/playback/copy song
(playable), create audio CD, backup/
restore, import (FAT 16, ISO 9660)/
export (FAT 16) WAV file
Track editing: Copy, insert, erase, delete, swap,
reverse, time expansion/compres-
sion, fade, normalize, optimize (tracks
can be copied between songs)
Song editing: Copy, move, delete, rename, protect
Counter/locate format: Min/Sec/mSec, Meas/Beat/Tick,
Min/Sec/Frame (30NDF only)
<Mixer section>
Structure: 16 channel input, 4 BUS, 1 AUX, 1
MASTER
Signal processing: 32 bit 44.1 kHz
Equalizer: HIGH (f:10 kHz G: 15 dB)
MID (f:0.1 –20 kHz G: 15 dB)
LOW (f:100 Hz G: 15 dB)
Scene memory: 100 scenes per song
<Effect section>
Structure: insert 8 (maximum)
master 2 (maximum)
final 1
All usable simultaneously
Signal processing: 44 bit 44.1 kHz
Programs: insert (128 preset, 128 user)
master (32 preset, 32 user)
final (32 preset, 32 user)
Algorithms: 98
Effects: 106
<General>
Display: 240 64 pixel
LCD with backlight
136
Power supply: AC9V 3A AC/AC power supply
Power consumption: 19 W (AC 9V 2.2A max, D12 alone)
23 W (AC 9V 2.6A max, with CDRW-1
installed)
Dimensions: 357mm (W) 245mm (D) 81mm (H)
(Including protrusions)
Weight: 2.0 kg (main unit only)
2.4 kg (with CDRW-1 installed)
I Principal specifications
Frequency response: 10 Hz –20 kHz 1dB @+4 dBu, 10 k
load
S/N: 95 dB (typical) @IHF-A
Dynamic range: 95 dB (typical) @IHF-A
THD+N: 0.03 % (typical) 20 Hz –20 kHz @+16
dBu, 10 k load
A/D conversion: 20 bit, 64 times oversampling
D/A conversion: 20 bit, 128 times oversampling
Sampling frequency: 44.1 kHz
I Analog/digital input and output specifications
<INPUT1, 2>
Connectors: XLR-3-31 type, 1/4" TRS phone jack
(balanced)
Input impedance: 10 k
Nominal level: –60 dBu @TRIM=max.
+4 dBu @TRIM=min.
Maximum level: –48 dBu @TRIM=max.
+16 dBu @TRIM=min.
Source impedance: 600
<INPUT3, 4>
Connectors: 1/4" TRS phone jack (balanced)
Input impedance: 10 k
Nominal level: –60 dBu @TRIM=max.
+4 dBu @TRIM=min.
Maximum level: –48 dBu @TRIM=max.
+16 dBu @TRIM=min.
Source impedance: 600
<GUITAR INPUT>
Connector: 1/4" phone jack (unbalanced)
Input impedance: 1 M
Nominal level: –60 dBu @TRIM=max.
+4 dBu @TRIM=min.
Maximum level: –48 dBu @TRIM=max.
+16 dBu @TRIM=min.
Source impedance: 600
<MASTER OUTPUT L/R>
Connector: RCA phono jack
Output impedance: 150
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 k or more
<MONITOR OUTPUT L/R>
Connector: RCA phono jack
Output impedance: 150
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 k or more
<AUX OUTPUT>
Connector: 1/4" phone jack (unbalanced)
Output impedance: 150
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 k or more
<PHONES OUTPUT>
Connector: 1/4" stereo phone jack
or more
