Using the Insert, Master and Final Effects Working with Scenes Selecting Virtual tracks and Editing tracks Creating a Mixdown and burning and audio CD on the D1200mkII Important D1200mkII Owner’s Manual references D1200mkII Main Features • 100 Scenes, 100 Mark points, 4 Locate points per song •...
There are 106 effects types, and 128 preset / 128 user Insert effect programs available. - In this mode you can change the EQ setting for each of the D1200mkII’s tracks. The EQ type is 3-band: Lo, Mid and Hi with a center mid frequency control.
-This function allows you to go back and UNDO/REDO any previous recording or editing procedure in the current song. The D1200mkII lets you set the desired number of undo levels: 99, 8 or 1 level. Note: A setting of “8” or “1” UNDO levels allows you to conserve hard disk space.
Navigating the D1200mkII Display • To select the display “tabs” in each mode, use the [<-TAB->] keys or repeatedly press a mode key: [INPUT/OUTPUT/SOLO], [INSERT EFFECT] etc. The [<-TAB->] keys also function as [NO/CANCEL] and [YES/OK] keys. • To move to different locations in the display, use any of the four CURSOR keys. To confirm a highlighted selection in the display, press the [ENTER] key.
Press the [INPUT/OUTPUT/SOLO] key. Connect your audio source (mic, keyboard L/R outputs, etc.) to the analog inputs on the top of the D1200mkII. If you are connecting a guitar to the D1200mkII directly, use the GUITAR IN jack on the front panel.
Working with EQ on playback Press the [EQ] key, and use the [<-TAB->] keys to move to the desired group of tracks to EQ. Use the CURSOR keys and DIAL to select the “knob” in the display, and edit the value for the EQ parameter for a specific track.
”radio button” to the left of the function you wish to perform and then select “OK” using the CURSOR and [ENTER] keys. To execute the function, select Exec. in the display. For more information on editing tracks, refer to the D1200mkII Owner’s Manual pages 57-63 & 108-113.
Important D1200mkII Owner’s Manual references Installing the CDRW-1x8 drive CD Mastering D1200mkII MIDI sync procedures Controlling the D1200mkII from an external sequencer Using MIDI for mixer control MIDI Machine Control (MMC) Working with WAV files and the Import/Export function via USB or CD...
