Korg EASYSTART D12 Easy Start Manual

Korg EASYSTART D12 Easy Start Manual

Digital recording studio
Hide thumbs Also See for EASYSTART D12:
1
2
3
4
5

Advertisement

Quick Links

Download this manual See also: Owner's Manual
EasyStart
A quick overview of D12 modes
Navigating the D12
Getting started: Listening to the demo songs / Creating a new song
Assigning inputs and recording audio tracks
Listening to recorded tracks
Working with EQ
Using the Insert and Master effects
Using the Final effects
Working with Scenes
Selecting Virtual tracks and Editing tracks
Writing/Burning to CDR/CDRW
Important D12 Guide and Owner's Manual references
EasyStart CONTENTS
D12 Main Features
No Audio Compression
12 channel, 4 buss digital mixer
12 track recorder, with a total of
96 virtual tracks
Hi, Lo and adjustable mid
frequency EQ for every channel
Up to 11 simultaneous effects
per song: 8 inserts, 2 masters
and a final effect. Includes
REMS mic, amp and cabinet
effects plus 98 effect chains
and hundreds of programs
Internal/External Mix
Automation with 100 Scenes
per song
Extensive digital editing of
songs and tracks
Up to 99 levels of UNDO
Built-in tuner, metronome and
hundreds of PCM rhythm
patterns
Internal 6 GB hard disk
Optional internal CDRW 1x8
CD burner for mastering and
backup
2
2
3
3
3
4
4
4
4
5
5
5

Advertisement

loading

Related Manuals for Korg EASYSTART D12

Summary of Contents for Korg EASYSTART D12

  • Page 1 EasyStart A quick overview of D12 modes Navigating the D12 Getting started: Listening to the demo songs / Creating a new song Assigning inputs and recording audio tracks Listening to recorded tracks Working with EQ Using the Insert and Master effects Using the Final effects Working with Scenes Selecting Virtual tracks and Editing tracks...
  • Page 2 D12 EasyStart A quick overview of D12 modes SONG/CD – This mode allows you to select songs, create a new song, rename a song, perform song editing functions (copy song, move song, protect song, etc.), use the Program Play function, listen to audio CD’s and burn a CDR/RW of your final mix. RECORD –...
  • Page 3 Navigating the D12 To select the display “tabs” in each mode, repeatedly press a mode key: [INPUT/TUNER], [EQ/PHASE] etc. To move to different locations in the display, use the four-position CURSOR. To confirm a highlighted selection in the display, press the [ENTER] key. To change a highlighted value, rotate the DIAL.
  • Page 4 Working with EQ on playback: Press the [EQ/PHASE] key. Use the four way CURSOR and DIAL to select the “knob” in the display, and edit the value for the EQ parameter for a specific track. The upper left hand side of the display will show the parameter and track you will be working with. (To change EQ settings for tracks 5-8 and 9-12 press the [EQ/PHASE] key again) Using the Insert Effects: Press the [INSERT EFFECT] key, and then select the “...
  • Page 5 Important D1600 Guide and Owner’s Manual references: You can download a more in-depth “D12 Guided Tour” and additional “tips and tricks” from www.korg.com. There are also many important references to modes and applications in the D12 Owner’s Manual. Some of these references are listed below:...
