HP ProLiant DL170h G6 Server
Maintenance and Service Guide
Part number 531483-001
First edition July 2009

Advertisement

Table of Contents
loading

Related Manuals for HP ProLiant DL170h G6

Summary of Contents for HP ProLiant DL170h G6

  • Page 1 All manuals and user guides at all-guides.com HP ProLiant DL170h G6 Server Maintenance and Service Guide Part number 531483-001 First edition July 2009...
  • Page 2 © Copyright 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

  • Page 3: Table Of Contents

    Illustrated parts catalog ......................... 16 Mechanical components ......................... 16 System components of an 8HDD server..................... 20 HP Contact Information........................... 24 Before You Contact HP ........................... 24 Removal and Replacement Procedures ....................25 Hardware Configuration Tools......................... 25 Hardware Configuration Information ......................25 Electrostatic Discharge Information ......................
  • Page 4 All manuals and user guides at all-guides.com BIOS Update............................78 Clear CMOS............................79 Power-on Self-Test (POST)........................79 POST Error Indicators ........................79 POST Errors Message Definition......................80 POST Related Troubleshooting ......................82 Physical and Operating Specifications ....................83 System Unit ............................83 Index ..............................

  • Page 5: Customer Self Repair

    If during the diagnosis period HP (or HP service providers or service partners) identifies that the repair can be accomplished by the use of a CSR part, HP will ship that part directly to you for replacement. There are two categories of CSR parts: •...
  • Page 6 Centre d'assistance technique HP. Dans les documents envoyés avec la pièce de rechange CSR, HP précise s'il est nécessaire de lui retourner la pièce défectueuse. Si c'est le cas, vous devez le faire dans le délai indiqué, généralement cinq (5) jours ouvrés. La pièce et sa documentation doivent être retournées dans l'emballage fourni.
  • Page 7 In caso di necessità si può richiedere l'assistenza telefonica di un addetto del centro di supporto tecnico HP. Nel materiale fornito con una parte di ricambio CSR, HP specifica se il cliente deve restituire dei componenti. Qualora sia richiesta la resa ad HP del componente difettoso, lo si deve spedire ad HP entro un determinato periodo di tempo, generalmente cinque (5) giorni lavorativi.
  • Page 8 Flexibilität beim Austausch defekter Bauteile zu ermöglichen. Wenn HP (oder ein HP Servicepartner) bei der Diagnose feststellt, dass das Produkt mithilfe eines CSR-Teils repariert werden kann, sendet Ihnen HP dieses Bauteil zum Austausch direkt zu. CSR-Teile werden in zwei Kategorien unterteilt: •...
  • Page 9 HP podrá cobrarle por el de sustitución. En el caso de todas sustituciones que lleve a cabo el cliente, HP se hará cargo de todos los gastos de envío y devolución de componentes y escogerá la empresa de transporte que se utilice para dicho servicio.
  • Page 10 Optioneel: Onderdelen waarvoor reparatie door de klant optioneel is. Ook deze onderdelen zijn ontworpen voor reparatie door de klant. Als u echter HP verzoekt deze onderdelen voor u te vervangen, kunnen daarvoor extra kosten in rekening worden gebracht, afhankelijk van het type garantieservice voor het product.
  • Page 11 CSR de reposição se a peça com defeito deve ser devolvida à HP. Nos casos em que isso for necessário, é preciso enviar a peça com defeito à HP dentro do período determinado, normalmente cinco (5) dias úteis. A peça com defeito deve ser enviada com a documentação correspondente no material de transporte fornecido.
  • Page 12 All manuals and user guides at all-guides.com Customer self repair 12...
  • Page 13 All manuals and user guides at all-guides.com Customer self repair 13...
  • Page 14 All manuals and user guides at all-guides.com Customer self repair 14...
  • Page 15 All manuals and user guides at all-guides.com Customer self repair 15...

  • Page 16: Illustrated Parts Catalog

    All manuals and user guides at all-guides.com Illustrated parts catalog Mechanical components Item Description Spare part number Customer self repair Top cover 516572-001 Mandatory Rail kit – left 496804-001 Mandatory Rail kit – right 496804-001 Mandatory Hard drive cage for 8 HDD model 515989-B21 Mandatory Hard drive dummy (fixed)
  • Page 17 Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product.
  • Page 18 No: No—Algunos componentes no están diseñados para que puedan ser reparados por el usuario. Para que el usuario haga valer su garantía, HP pone como condición que un proveedor de servicios autorizado realice la sustitución de estos componentes. Dichos componentes se identifican con la palabra “No”...
  • Page 19 All manuals and user guides at all-guides.com Illustrated parts catalog 19...

  • Page 20: System Components Of An 8Hdd Server

    536664-001 Mandatory 1200-W Power Supply 498152-001 Mandatory Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be charged for the travel and labor costs of this service. Illustrated parts catalog 20...
  • Page 21 Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product.
  • Page 22 No: No—Algunos componentes no están diseñados para que puedan ser reparados por el usuario. Para que el usuario haga valer su garantía, HP pone como condición que un proveedor de servicios autorizado realice la sustitución de estos componentes. Dichos componentes se identifican con la palabra “No”...
  • Page 23 All manuals and user guides at all-guides.com Illustrated parts catalog 23...

  • Page 24: Hp Contact Information

    • In North America: ○ Call 1-800-HP-INVENT (1-800-474-6836). This service is available 24 hours a day, 7 days a week. For continuous quality improvement, calls may be recorded or monitored. ○ If you have purchased a Care Pack (service upgrade), call 1-800-633-3600. For more information about Care Packs, refer to the HP website at http://www.hp.com/.

  • Page 25: Removal And Replacement Procedures

    All manuals and user guides at all-guides.com Removal and Replacement Procedures This chapter provides subassembly/module-level removal and replacement procedures for the HP ProLiant DL170h Generation 6 server. NOTE: This chapter mainly illustrates the removal and replacement procedures on the basis of the server with 8 HDD, because most of the procedures between servers of 8 HDD and 12 HDD are the same.

  • Page 26: Pre-Installation Procedure

    Press the power button on the front panel to turn on the server. NOTE: The HP ProLiant DL170h Generation 6 server supports up to 2 1200-W power supply units, but 1 power supply only supports 2 Nodes of the sever and 2 power supply supports 4 Nodes of the sever.

  • Page 27: Symbols On Equipment

    All manuals and user guides at all-guides.com WARNING: To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature. • Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times. •...

  • Page 28: Powering Down The Server

    All manuals and user guides at all-guides.com This symbol on an RJ-45 receptacle indicates a network interface connection. WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do not plug telephone or telecommunications connectors into this receptacle. This symbol indicates the presence of a hot surface or hot component.
  • Page 29 All manuals and user guides at all-guides.com Unlock the button on the top cover using the T10/T15 wrench on the rear panel. Pull up the latch in the open (up) position. Slide the cover approximately 1.25 cm (0.5 in) toward the rear of the unit and then lift the cover to detach it from the chassis.

  • Page 30: Drives

    All manuals and user guides at all-guides.com Figure 2 Reinstalling the top cover Drives The server supports 8 drive bays for 3.5-inch hard disk drives. Cable Management Always follow good cable management practices when working inside the computer. • Keep cables away from major heat sources like the heat sink. •...

  • Page 31: Cable Connections

    All manuals and user guides at all-guides.com Figure 3 Unplugging power cables Cable Connections The following table provides information about switching power supply cable connector labels. Table 1 Power BP Cable connections Cable Cable Designator Main power cable Node 12-pin power connector RPS cable System board Power Supply Management Interface connector...
  • Page 32 All manuals and user guides at all-guides.com Table 3 Power BP Cable connections Cable System Board Designator Right Front IO CABLE Power BP front IO connector IO_1 Left Front IO CABLE Power BP front IO connector IO_2 Fan connector 1 Fan 1 Fan connector 2 Fan 2...

  • Page 33: Hard Drives

    All manuals and user guides at all-guides.com Table 5 8LFF HDD BP Cable connection Cable System Board Designator SGPIO cable SGPIO connector SGPIO cable SGPIO connector Table 6 8SFF HDD BP cable connection Cable System Board Designator X4 Mini SAS cable Mini SAS connector X4 Mini SAS cable Mini SAS connector...
  • Page 34 All manuals and user guides at all-guides.com Item Description B2 SAS/SATA Hard Drive D1 SAS/SATA Hard Drive D2 SAS/SATA Hard Drive To install a hard drive: Pull the hard drive shield out of the chassis. Figure 5 Removing the hard drive blank IMPORTANT: Do not discard the hard drive blank.
  • Page 35 All manuals and user guides at all-guides.com Figure 6 Installing the hard drive assembly To remove hard drive: Press the hard disk carrier button to release the ejector lever. Use the HDD carrier latch to pull the drive out of the cage. Make sure to support the drive when pulling it out of the cage.

  • Page 36: Sas/Sata Hdd Backplane

    All manuals and user guides at all-guides.com Figure 7 Removing the hard drive assembly SAS/SATA HDD Backplane Figure 8 Backplane connectors of server with 8 HDD (component side) Item Description Hard drive connectors Screw holes LED indicators Removal and Replacement Procedures 36...
  • Page 37 All manuals and user guides at all-guides.com Figure 9 Backplane connectors of server with 8 HDD (solder side) Item Description SATA/SAS cable connector Power cable connector SGPIO cable connector I2C connector WARNING: Ensure that the system is powered off and all power sources have been disconnected from the server.
  • Page 38 All manuals and user guides at all-guides.com Figure 10 Removing the drives Remove the top cover. Remove the backplane. Remove all cables. Remove the two screws that secure the backplane to the hard drive cage. Pull the backplane out to release it from the hard drive cage. Figure 11 Removing the backplane To install the backplane: Orient the backplane so that the three notches on the board align with the three hooks on the...

  • Page 39: System Board Configuration

    System Board Configuration Processor HP ProLiant DL170h Generation 6 Server, with 4 Nodes, supports eight-processor operation. With two processors installed, each Node supports boot functions through the processor installed in processor socket 1. However, if processor 1 fails, the system automatically boots from processor 2 and provides a processor failure message.
  • Page 40 All manuals and user guides at all-guides.com Figure 13 Processor locations Item Description Processor 1 Processor 2 WARNING: To reduce the risk of personal injury from hot surfaces, allow the heat sink and the processor to cool before touching them. NOTE: Before installing the processor, remove the air baffle.
  • Page 41 All manuals and user guides at all-guides.com Figure 14 Removing the air baffle To remove the heat sink: CAUTION: To prevent the heat sink from tilting to one side during installation and removal procedures, use a diagonally opposite pattern (an “X” pattern) when loosening and tightening the two spring-loaded screws.
  • Page 42 Apply the thermal grease compound to the CPU contact surface. CAUTION: HP recommends using Shin-Etsu X-23-7783D thermal grease compound for your ProLiant server. Apply all the grease to the top of the processor in one of the following patterns to insure even distribution.
  • Page 43 All manuals and user guides at all-guides.com Figure 17 Processor bottom CAUTION: Never touch the bottom of the processor; any contaminant could prevent the mounting pads from making contact with the socket. CAUTION: Applying too much grease creates a gap between the contact surfaces, significantly reducing the ability of the heat sink to draw out heat.
  • Page 44 Figure 18 Installing the processor CAUTION: To prevent overheating or a possible system crash, use only a heat sink model specified for the HP ProLiant DL170h Generation 6 server. To install the heat sink: Put the heat sink frame on the CPU socket.

  • Page 45: Memory

    Gently place in the air baffle. Figure 20 Installing the air baffle Memory HP ProLiant DL170h Generation 6 server has sixty-four DIMM slots that support up to 512 GB maximum system memory. You must adhere to the following guidelines when adding or replacing memory modules: •...
  • Page 46 All manuals and user guides at all-guides.com Completely open the holding clips securing the module. Gently pull the memory module upward to remove it from the slot. Figure 22 Removing a memory module CAUTION: Place the memory module on a static-dissipating work surface or inside of an anti-static bag.

  • Page 47: Pci Expansion Cards

    All manuals and user guides at all-guides.com NOTE: The ProLiant DL170h Generation 6 server supports up to 64 memory modules. Install them in the DIMM slots starting from the DIMM 1 slot. PCI Expansion Cards System Board PCI Expansion Slots There is one X 24 PCIe G2 Riser slot on the system boards.
  • Page 48 All manuals and user guides at all-guides.com To remove the IPMI optional card from the top system board Loose the screws that secure the IPMI card to the chassis. Remove the screws that secure the tray to the chassis and slide the tray with system board back, up and out of the chassis.
  • Page 49 All manuals and user guides at all-guides.com Fasten the screws to secure the IPMI card to the chassis. Figure 28 Installing the IPMI card to the bottom system board To install the IPMI card to the top system board Align the IPMI card with the open expansion slot and press the IPMI card straight down into the expansion connector on the system board.
  • Page 50 All manuals and user guides at all-guides.com Figure 30 Removing the PCIe riser card To install the PCIe riser card: Align the riser card slot to the connector on the main board and then push the card into the connector. Install and tighten the two screws that secure the riser card to the chassis.

  • Page 51: System Battery

    All manuals and user guides at all-guides.com Figure 32 Removing the PCIe card To install the PCIe card: Open the PCIe latch. Remove PCIe card or blank. Push the PCIe card into riser card connector. Close PCIe latch. Install the screw. Figure 33 Installing the PCIe card System Battery The server uses nonvolatile memory that requires 4 batteries to retain system information when power...
  • Page 52 Figure 34 System battery location WARNING: Note the following reminders when replacing the system battery: • Replace the battery with the same type as the battery recommended by HP. Use of another battery may present a risk of fire or explosion. •...

  • Page 53: System Board Removal And Replacement Procedure

    All manuals and user guides at all-guides.com Figure 35 Replacing the battery System Board Removal and Replacement Procedure To remove the system board: Remove the top two Nodes first: Remove screws from the rear panel and side of the tray. Slide the tray with system board back, up and out of the chassis.
  • Page 54 All manuals and user guides at all-guides.com Figure 37 Removing the Node from the tray Remove the bottom two Nodes Remove the six screws that secure the system board to the tray. Slide the system board back, up and out of the chassis. Figure 38 Removing the bottom Nodes To replace the system board: To replace the bottom system board...
  • Page 55 All manuals and user guides at all-guides.com Figure 39 Installing the bottom system board To replace the top system board Put the system board in the tray. The six screw holes on the tray should align with the system board. Fasten the six screws on the system board to secure the system board to the tray.

  • Page 56: Power Supply Unit (Psu)

    All manuals and user guides at all-guides.com Figure 41 Installing the tray with system board into the chassis Power Supply Unit (PSU) Located on the rear panel of the server power supply is a standard auto ranging 1200 watt PSU with PFC (power factor correction) function.

  • Page 57: System Fan

    All manuals and user guides at all-guides.com Figure 43 Removing the Power supply To replace the power supply: Align the power supply cage connector with the open slot of power supply. Slide the power supply into the power supply bay until it snaps into place. Figure 44 Installing the power supply System Fan The server has four system fans located on the chassis’...
  • Page 58 All manuals and user guides at all-guides.com Figure 45 System fan connection Device number Connector System fan 1 J6 on the power supply backplane System fan 2 J8 on the power supply backplane System fan 5 J7 on the power supply backplane System fan 6 J9 on the power supply backplane A new system fan can be installed to allow the server to operate properly in case a default system fan...
  • Page 59 All manuals and user guides at all-guides.com Figure 46 Removing the system fan To replace the system fan: Squeeze the two release tabs together. Insert the system fan into the fan bracket. Lock the cable clip to secure the cable on the chassis’ partition wall. Connect the fan cable to its corresponding board connector.

  • Page 60: Connectors, Switches, And Leds

    This chapter contains illustrations and tables identifying and describing the connectors, switches, buttons, and LED indicators located on the front panel, rear panel, system board and hard drives of the HP ProLiant DL170h Generation 6. Connectors and Components Front Panel Components...
  • Page 61 All manuals and user guides at all-guides.com Figure 49 Front panel components of a four-Node system, 16 SFF HDD cage with two optional front power/LED Item Description Power button of Node 1 Chassis UID LED Button Power button of Node 2 Health LED of Node 1 Health LED of Node 2 Power button of Node 3...

  • Page 62: Rear Panel Components

    All manuals and user guides at all-guides.com Rear panel components Figure 50 Rear panel components of a two-Node system Item Description PCIe Gen2 Full-height, full-length expansion card slot PCIe Gen2 Full-height, half-length expansion card slot PCIe Gen2 Low-profile expansion card slot Server UID LED button Shared 1Gb NIC2/Management Port (IPMI) (top) 1Gb NIC1 port (bottom)
  • Page 63 All manuals and user guides at all-guides.com Figure 51 Rear panel components of a four-Node system Item Description PCIe Gen2 Low-profile expansion card slot Server UID LED button Shared 1Gb NIC2/Management Port (IPMI) (top) 1Gb NIC1 port (bottom) T-10/T-15 driver Dedicated Management Port (IPMI) (Optional)_ USB 2.0 ports Power button of Node 4...

  • Page 64: System Board Components

    All manuals and user guides at all-guides.com System board components Figure 52 System board components Item Designator Description Top: Serial Port Bottom: VGA Port Top: Serial port A Bottom: VGA port UID LED/SW Health LED Power LED/SW Top: GbE LAN Port Bottom: GbE LAN Port Top: USB 2.0 Port Bottom: USB 2.0 Port...

  • Page 65: Jumpers -Password And Chassis Id

    If you suspect a TPM board failure, leave the TPM installed and remove the system board. Contact an HP authorized service provider for a replacement system board and TPM board. Jumpers –Password and Chassis ID Password (J50) and chassis ID (J45) jumpers.
  • Page 66 All manuals and user guides at all-guides.com Power LED Indicator The power status of the server is indicated by the bicolor LED on the front panel. Figure 53 Power LED indicator location Power/system health LED indicator status Table 8 Component Status Description Power/system health LED...
  • Page 67 All manuals and user guides at all-guides.com Power/system health LED indicator status Table 8 Component Status Description Power/system health LED Steady green The server is operating normally. indicator for Node 4 Steady Amber The server is system off or in hibernation with A/C power.

  • Page 68: Rear Panel Led Indicators

    All manuals and user guides at all-guides.com Table 9 Hard drive activity LED indicator status Item LED indicator Status Description Solid green • The drive is a member of a RAID volume. • The drive is not an inactive spare drive. •...
  • Page 69 All manuals and user guides at all-guides.com Figure 55 LAN/LED indicator location Table 10 LAN/LED indicator states Item Component Status Description LAN activity status LED indicator Flashing green Ongoing network data activity. No network data activity or no connection. LAN network speed LED Steady green The LAN connection is using a GbE link.

  • Page 70: Diagnostic Tools And Setup Utilities

    If the server is already turned on, save your data and exit all open applications, then restart the server. When the HP logo is displayed during POST, press F10 into BIOS Setup Utility. If you fail to press F10 before POST is completed, you will need to restart the server.

  • Page 71: Navigating Through The Setup Utility

    All manuals and user guides at all-guides.com Navigating through the Setup Utility Use the keys listed in the legend bar on the right of the Setup screen to navigate through the various menu and submenu screens of the Setup Utility. Table 11 lists these legend keys and their respective functions.

  • Page 72: Setup Utility Menu Bar

    All manuals and user guides at all-guides.com Figure 56 Setup utility general help screen Press F1 to get the general help message box. Setup Utility Menu Bar The BIOS Setup Utility provides a menu bar with the menu selections. The menu bar choices are described in the topics below.
  • Page 73 All manuals and user guides at all-guides.com Main Menu Figure 57 Main menu of BIOS setup utility 1 Figure 58 Main menu of BIOS setup utility Use this menu to set the system time and date, and configure of the following items: •...
  • Page 74 All manuals and user guides at all-guides.com • Set boot features: ○ Enable or Disable POST Speed up. ○ Enable or Disable Bootup Num-Lock. ○ Set restore on AC power loss options, such as last state, power off, and power on. ○...
  • Page 75 All manuals and user guides at all-guides.com Figure 60 IPMI configuration menu of the BIOS setup utility • SEL Configuration – Configuration of the BMC System Event Log. • Serial Port Configuration – Select to configure system serial ports. • LAN Configuration –...
  • Page 76 All manuals and user guides at all-guides.com Figure 62 Security menu of the BIOS setup utility 2 Use this menu to configure the following items: • Administrator Password --- Display if an administrator password is Set or Not. • Change Admin Password --- Allows you to access and change all settings in the Setup Utility. The administrator password allows you to configure access for system users.
  • Page 77 All manuals and user guides at all-guides.com Boot Menu Figure 63 Boot menu of the BIOS setup utility Use this menu to configure the boot settings. • Boot Device Priority – Use this screen to specify the order in which the system checks for a boot device.

  • Page 78: Bios Update

    All manuals and user guides at all-guides.com Exit Menu Figure 64 Exit menu of the BIOS setup utility Use this menu to save changes or discard changes. When you save and exit, the server reboots. • Save Changes and Exit --- Save the changes you have made and exit the BIOS Setup Utility. (You can also press F10 key.) •...

  • Page 79: Clear Cmos

    POST. The number of tests displayed depends on the configuration of the server. During POST you can: • Press ESC to skip the HP logo and go to POST boot progress display system summary screen. • Press F7 to display the Boot menu. •...

  • Page 80: Post Errors Message Definition

    012 --- CMOS Date/Time not set Table 12 lists the most common POST error messages with corresponding Post Error Messages troubleshooting recommendation. HP recommends that you correct the error, even if the server appears to boot successfully. Table 12 Post Error Messages...
  • Page 81 All manuals and user guides at all-guides.com Table 12 Post Error Messages Error-Code Error Message Description / Corrective Action S.M.A.R.T. Status BAD, 05Dh Hard Disk S.M.A.R.T feature test fail ,indicate a problem with hard disk Backup and Replace If user input incorrect password more than three times, then display this 05Eh Password check failed error information and continue to boot.

  • Page 82: Post Related Troubleshooting

    All manuals and user guides at all-guides.com POST Related Troubleshooting Perform the following procedures when POST fails to run, displays error messages, or emits beep codes. If the POST failure is during a routine boot up, check the following: • All external cables and power cables should be firmly plugged in.

  • Page 83: Physical And Operating Specifications

    All manuals and user guides at all-guides.com Physical and Operating Specifications This chapter provides physical and operating specifications for the HP ProLiant DL170h Generation 6 server. Specifications include: System Unit Table 13 Hardware Specifications Item Components Processor socket Intel 1366pin FCLGA...
  • Page 84 All manuals and user guides at all-guides.com Table 13 Hardware Specifications Item Components Status LED indicators • Power/system health status Front panel • UID status • NIC activity • LAN activity • LAN link status Rear Panel • Power/system health status •...
  • Page 85 All manuals and user guides at all-guides.com Table 15 Environmental Specifications Item Description Relative humidity (non-condensing) 10% to 95% relative humidity (Rh), 101.7°F (38.7°C) maximum wet bulb temperature, non-condensing. Non-operating Altitude 10,000 ft (3050 m). This value may be limited by the type and number of options installed.
  • Page 86 All manuals and user guides at all-guides.com NOTE: Power Specifications: To review typical system power ratings use the Power Calculator which is available via the online tool located at URL: http://h30099.www3.hp.com/configurator/calc/Power% 20Calculator%20Catalog.xls - Click on the system of interest. Example: xxxxxx - Follow the instructions of the next screens.

  • Page 87: Index

    All manuals and user guides at all-guides.com Index clear CMOS, 78 POST, 78 AC power dimensions power-down procedures, 28 server, 83 air baffle drives installing, 43 back plane, 35 removing, 39 cable management, 30 Air baffle left hard drives, 33 spare part number, 16 Drives Air baffle right...
  • Page 88 All manuals and user guides at all-guides.com processor socket, 82 processor support, 82 Memory module status LED indicators, 83 spare part number, 20 thermal solution, 83 memory controller, 82 Hardware Specifications memory modules chipset, 82 guidelines for installation, 44 default media storage, 82 installing, 45 Hardware monitoring device, 82 removing, 44...
  • Page 89 All manuals and user guides at all-guides.com spare part number, 20 System Board Configuration, 38 system covers removing, 55 top cover, 28 replacement warnings, 55 system fan replacing, 56 removing, 57 type, 83 replacing, 58 System fan spare part number, 20 Rail kit left system LEDs.
