System Dimensions

In the following image, the dimensions are show in centimeters.
Physical Specifications
The following tables list the physical specifications of the instrument.
Physical Specifications
Item
Environment
Power
requirements
Dimensions
Rear clearance
Weight
Plate formats
Reading capability Plates
5090339 A
Description
Indoor use only
External 24V DC power supply compatible with 100-240V AC @50-60 Hz 160W
maximum consumption
32 cm W x 35 cm H x 40 cm D
(12.6 in. W x 13.8 in. H x 15.7 in. D)
20 cm to 30 cm (7.9 in. to 11.8 in.) between the rear of the instrument and the wall for
ventilation and cable disconnects
18 kg (≤40 lbs)
6, 12, 24, 48, 96, 384-well plates ANSI/SLAS conformant
Absorbance read mode: Maximum height 22 mm
Fluorescence read mode and luminescence read mode: Maximum height 20 mm
Cuvettes with SpectraCuvette Adapter part number 5301193 (see
on page
11) Note: Do not use any other SpectraCuvette Adapter.
Appendix A: Specifications
Supported Plates
43
