controller (the RJ-45 port on the left) to the Admin Network, using an Ethernet cable.
If you plan to use active-backup network bond mode for the Admin Network, connect management port 2
on the E5700SG controller (the RJ-45 port on the right) to the Admin Network, using an Ethernet cable.
4. Connect the 10/25-GbE ports on the E5700SG controller to the appropriate network switches, using optical
cables and SFP+ or SFP28 transceivers.
All ports must use the same link speed. Install SFP+ transceivers if you plan to use 10-GbE
link speeds. Install SFP28 transceivers if you plan to use 25-GbE link speeds.
◦ If you plan to use Fixed port bond mode (default), connect the ports to the StorageGRID Grid and
Client Networks, as shown in the table.
Port
Port 1
Port 2
Port 3
Port 4
◦ If you plan to use the Aggregate port bond mode, connect one or more of the network ports to one or
more switches. You should connect at least two of the four ports to avoid having a single point of
failure. If you use more than one switch for a single LACP bond, the switches must support MLAG or
equivalent.
Related information
Access StorageGRID Appliance Installer
Port bond modes for E5700SG controller ports

Connect power cords and apply power (SG5700)

When you apply power to the appliance, both controllers boot up.
What you'll need
Both appliance power switches must be off before connecting power.
Risk of electrical shock — Before connecting the power cords, make sure that the two power
switches on the appliance are off.
Steps
1. Confirm that the two power switches on the appliance are off.
2. Connect the two power cords to the appliance.
3. Connect the two power cords to different power distribution units (PDUs) in the cabinet or rack.
4. Turn on the two power switches on the appliance.
6
Connects to...
Client Network (optional)
Grid Network
Client Network (optional)
Grid Network
