General boot-up codes
During boot-up or after a hard reset of the appliance, the following occurs:
1. The seven-segment display on the E5700SG controller shows a general sequence of codes that is not
specific to the controller. The general sequence ends with the codes AA and FF.
2. Boot-up codes that are specific to the E5700SG controller appear.
E5700SG controller boot-up codes
During a normal boot-up of the appliance, the seven-segment display on the E5700SG controller shows the
following codes in the order listed:
Code
HI
PP
HP
RB
FP
10
Display
Ethernet Link State LEDs
Ethernet Activity LEDs
Indicates
The master boot script has started.
The system is checking to see if the FPGA needs to
be updated.
The system is checking to see if the 10/25-GbE
controller firmware needs to be updated.
The system is rebooting after applying firmware
updates.
The hardware subsystem firmware update checks
have been completed. Inter-controller communication
services are starting.
Description
Green: A link is established.
Off: No link is established.
Green: The link between the
management port and the device to
which it is connected (such as an
Ethernet switch) is up.
Off: There is no link between the
controller and the connected
device.
Blinking Green: There is Ethernet
activity.
