Steps
1. Connect the E2800 controller to the E5700SG controller, using two optical cables and four of the eight
SFP+ transceivers.
Connect this port...
Interconnect port 1 on the E2800 controller
Interconnect port 2 on the E2800 controller
2. If you plan to use SANtricity System Manager, connect management port 1 (P1) on the E2800 controller
(the RJ-45 port on the left) to the management network for SANtricity System Manager, using an Ethernet
cable.
Do not use management port 2 (P2) on the E2800 controller (the RJ-45 port on the right). This port is
reserved for technical support.
3. If you plan to use the Admin Network for StorageGRID, connect management port 1 on the E5700SG
Port
Management port 2 on
the E5700SG controller
10/25-GbE ports 1-4 on
the E5700SG controller
Type of port
1-GbE (RJ-45)
10-GbE or 25-GbE
Note: The SFP+
transceivers included with
the appliance support 10-
GbE link speeds. If you
want to use 25-GbE link
speeds for the four
network ports, you must
provide SFP28
transceivers.
To this port...
Interconnect port 1 on the E5700SG controller
Interconnect port 2 on the E5700SG controller
Function
• Can be bonded with
management port 1 if
you want a redundant
connection to the
Admin Network.
• Can be left unwired
and available for
temporary local
access (IP
169.254.0.1).
• During installation,
can be used to
connect the E5700SG
controller to a service
laptop if DHCP-
assigned IP
addresses are not
available.
Connect to the Grid
Network and the Client
Network for StorageGRID.
See "10/25-GbE port
connections for the
E5700SG controller."
5
