Assembling The Quick Detect; First Use; Step 1 - Preparing The Sensing Plug; Step 2 - Inserting The Sensing Plug - Neutronics QUICK DETECT Operation Manual

2
A
SSEMBLI
2.1

First Use

Prior to first use, identify each of the Quick Detect omponents as described in 1.1 – 1.6, locate the
High Side (liquid) service port on the vehicle, and select the pr
vehicle.
2.2 Step 1 – Preparing the Sensing Plug
Type II sealants react with moisture and air to form a solid substance designed to seal leaks within
the A/c system. The Quick Detect uses this same prin
Prepare the sensing plug by injecting tap wa
included syringe. (See Figure 1) After injecting the wate
excess water leaving only a few small droplets inside.
Figure 1
2.3 Step 2 – Inserting the Sensing Plug
Insert the non-ribbed end of the Sensing Plug into the appr
QD sleeve and inserting the Sensing plug. (See Figure 2) N
the sleeve must return to its original position. Tug on the plug to ensure it is properly seated.
2.4 Step 3 – Installing the Safety Cap
S lide the safety cap completely over the Sensing Plug. (See Figure 3) The safety cap prevents any
accidental release of the Sensing Plug from the QD coupler during installation of the Quick Detect
onto the vehicle.
Manual Part Number:
5-06-7000-62-0
Q D
NG THE UICK
Manual File:
MN-A-0001 Rev. E
Starting up and Commissioning the System
ETECT
c
oper coupler for an R12 or R134a
cipal to detect the presence of active sealant.
ter into both ends of the sensing plug using the
r, shake the sensing plug once to remove
opriate test rig by pulling back on the
ote, the Plug must be fully inserted and
Revision Date: June 5, 2006
Figure 2
Page 2-3
