Neutronics QUICK DETECT Operation Manual page 13

4
A
PPENDICES
4.1 Appendix A - Spare Parts List
PART NUMB ER
7-08-1000-51-0
7-08-1000-52-0
7-08-1000-53-0
4 .2 App endix B -
REFRIGERANT TYPES:
PRESSURE:
TEMPERATURE:
SEALANT TYPES:
4.3 Appendix C - Troubleshooting
4.3.1 Low Flow Readings
Low flow rea dings can be caused by several factors including low refrigerant charge, inoperable
service port, reusing a sensing plug or clo
attempting to conduct the test with a new sensing plug and the compressor and engine running,
add a small charge of refrigerant to the system and retest.
4.3.2 No High Side Service Port
A limited number of vehicles are produced without
Detect cannot be used on these vehicles.
4.4 Appendix D – Intended Use
This product is designed for use on Mobile A/C Systems for the express purpose of detecting the
presence of active, Type II sealants at the High Side (Liquid) port of the A/C system.
Manual Part Number:
5-06-7000-62-0
Quick Detect Kit
Quick Detect Spare Sensing Plugs (25)
Quick Detect Spare Parts Kit Items 1.2 thru 1.5
Specificatio ns
R12, R134a
250 PSIG Max.
200° F
Type II
gged tubes. If you encounter low flow readings after
Manual File:
MN-A-0001 Rev. E
Appendix C – Factory Configuration Settings
DESCRIPTION
a traditional High Side Service Port. The Quick
Revision Date: June 5, 2006 Page 4-7
