For Your Safety - Neutronics QUICK DETECT Operation Manual

For Your Safety:

PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE ATTEMPTING
INSTALLATION OR OPERATION! Attempting to operate the Ultima ID without
fully understanding its features and functions may result in unsafe conditions
TEST RIGS MAY CONTAIN LIQUID REFRIGERANT UNDER PRESSURE.
refrigerant may cause injury. Wear protective equipment, including safety goggles. Disconnect
test rig from A/C system with extreme caution.
CAUTION: RISK OF INJURY. THIS EQUIPMENT SHOULD BE OPERATED ONLY BY CERTIFIED
PERSONNEL. Operator must be familiar with A/C systems and refrigerant and dangers of
pressurized components.
Avoid breathing A/C refrigerant and lubrication vapor or mist. Exposure may irritate eyes,
nose and throat. Additional health and safety information may be obtained from refrigerant
and lubrication manufacturers.
Use this equipment in locations with mechanical ventilation that provides at least four air changes per
hour.
DO NOT OPERATE EQUIPMENT UNATTENDED. Equipment requires constant observation of
flow rate for the time period specified in procedure. Unattended operation may result in
excessive refrigerant discharge to the environment.
VERIFY SENSING PLUG CONNECTION INTO TEST RIG PRIOR TO TESTING. Incomplete
connection of sensing plug into coupler of test rig will result in sudden ejection from test rig
when connected to A/C system.
USE ONLY ORDINARY CLEAN TAP WATER IN THE WETTING OF SENSING PLUGS. Dirty
water or other fluid types may cause false indications of sealant presence.
DO NOT REMOVE SENSING PLUGS FROM SHIPPING BAGS UNTIL READY FOR USE. The
sensing plugs are sensitive to fouling from dirt, liquid, etc.
USE ONLY REPLACEMENT PARTS SUPPLIED BY NEUTRONICS INC. Use of non-authorized
replacement parts will void all warranties and may result in false or erroneous test results.
DO NOT UTILIZE QUICK DETECT SYSTEM WITHOUT SAFETY SHIELD. Use of system without
safety shield may result in accidental release of refrigerant charges.
DO NOT POSITION FLOWMETER BELOW LEVEL OF TEST PORT. Positioning of the flowmeter
below the level of the A/C test port may result in flowmeter flooding with liquid refrigerant, oil,
dye and sealant.
Manual Part Number:
5-06-7000-62-0
Manual File:
MN-A-0001 Rev. E
Revision Date: June 5, 2006
