Thank you for purchasing this Neutronics Inc. product. Proper registration will enable us to send you periodic
notification of product updates and other important announcements. Registering your product will also allow us to
contact you in the unlikely event that it will need adjustment or modification. Please take the time to register your
new product at our web site:
http://www.neutronicsinc.com/productregistration
You will find the product serial number inside of the battery cover of the main unit and on the outside of the carton
box.
If you would like to register by phone, have any operational questions regarding your new purchase, find the
location of the distributor in your area, or for any other questions, please call 800-378-2287 (in PA: 610-524-8800).
Thank You.
456 Creamery Way, Exton, PA 19341
Phone: 610.524.8800 • Fax: 610.524.8807 • Email: info@neutronicsinc.com
www.neutronicsinc.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Neutronics UltimaID
Summary of Contents for Neutronics UltimaID
- Page 1 Thank you for purchasing this Neutronics Inc. product. Proper registration will enable us to send you periodic notification of product updates and other important announcements. Registering your product will also allow us to contact you in the unlikely event that it will need adjustment or modification. Please take the time to register your new product at our web site: http://www.neutronicsinc.com/productregistration...
- Page 3 ULTIMA ID™ REFRIGERANT IDENTIFIER OPERATION MANUAL Manual Part Number: 5-06-7000-65-0 Manual File MN-A-0117 Rev. D 456 Creamery Way, Exton, PA 19341 Phone: 610.524.8800 • Fax: 610.524.8807 • Email: info@neutronicsinc.com www.neutronicsinc.com...
-
Page 5: Table Of Contents
Table of Contents TABLE OF CONTENTS ...............................III FOR YOUR SAFETY: ..............................V IDENTIFIER WARNINGS.............................V GENERAL CAUTIONS ..............................VI WELCOME .................................VII INTRODUCTION AND OVERVIEW ...................... 1-9 ...............................1-9 ENERAL ..............................1-10 EATURES ID C ..........................1-11 LTIMA OMPONENTS 1.3.1 Ultima ID Base Unit........................ 1-11 1.3.2 R134a Sample Hose....................... 1-11 1.3.3 R12 Sample Hose........................ - Page 6 ........................3-8 LEANING THE AMPLE OSES ........................3-8 HANGING THE RINTER APER ..........................3-9 ATTERY ARNING ............................3-9 RROR ESSAGES APPENDICES .............................4-10 ............................4-10 PARE ARTS B - S ........................4-10 PPENDIX PECIFICATIONS APPENDIX E – W .........................4-11 ARRANTY Manual Part Number: Manual File: Revision Date: August 24, 2006 Page iv 5-06-7000-65-0 MN-A-0117 Rev.
-
Page 7: For Your Safety
For Your Safety: PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE ATTEMPTING INSTALLATION OR OPERATION! Attempting to operate the Ultima ID without fully understanding its features and functions may result in unsafe conditions • Always use protective eye wear and observe proper safety procedures when working with pressurized gases. -
Page 8: General Cautions
General Cautions • Always inspect the sample hose before each use. Replace the hose if it appears cracked, frayed, obstructed or fouled with oil. • ALWAYS turn the compressor or automobile engine off before connecting the instrument to an air conditioning system. •... -
Page 9: Welcome
Copyright ©2004 Neutronics Inc. This work is protected under Title 17 of the US Code and is the sole property of Neutronics Inc. No part of this document may be copied or otherwise reproduced, or stored in any electronic information retrieval system, except as specifically permitted under US copyright law, without the prior written consent of Neutronics Inc. - Page 10 Manual Part Number: Manual File: Revision Date: August 24, 2006 Page viii 5-06-7000-65-0 MN-A-0117 Rev. D...
-
Page 11: Introduction And Overview
The Neutronics Ultima ID Refrigerant Identifier will provide a fast, easy and accurate means to determine refrigerant purity in refrigerant storage cylinders or directly in vehicle air conditioning systems. -
Page 12: Features
The Neutronics Ultima ID Refrigerant Identifier will provide the refrigerant technician with absolute knowledge of refrigerant purity and protection against refrigerant contamination and potential flammability. Features The Ultima ID Refrigerant Identifier is the most advanced instrument ever manufactured for determining the purity of gaseous refrigerants for the automotive market. -
Page 13: Ultima Id Components
Ultima ID Components 1.3.1 Ultima ID Base Unit The Ultima Id base unit houses the Graphic Display, Infrared Bench, Electrical Connections, and Optional Printer Module. These components require no maintenance, therefore there are no serviceable components internal to the instrument, and disassembly will void the warranty. Sample Filter Control Panel Printer Door... -
Page 14: R12 Sample Hose
1.3.3 R12 Sample Hose The 6-foot (1.8 meter) R12 Sample Hose is constructed of a nylon inner tube and a polyurethane outer tube. The inner tube will handle all of the refrigerant transfer and will provide containment up to 300psig. The outer tube will provide protection of the inner tube from abrasion, nicking, cutting, etc. -
Page 15: Control Panel
1.3.6 Control Panel The Control Panel serves as the main user interface. The Control Panel features three soft key buttons that change their function as the instrument changes modes. The current function for each button is displayed by the soft key label at the bottom of the graphic display. Red and Green LED’s at the top of the Control Panel are used for visual Pass/Fail indications. -
Page 16: Hard Shell Storage/Carrying Case
1.3.8 Hard Shell Storage/Carrying Case The hard shell storage/carrying case is custom fit to the Ultima ID. It provides rugged protection for the instrument as well as convenient storage for all components. The enclosure is general purpose and is not watertight. Manual Part Number: Manual File: Revision Date: August 24, 2006... -
Page 17: Ultima Id Operation
Miscellaneous Refrigerant Equipment 12 VDC, 1A; Design Pressure: 300 psig Refrigerant Type: R-12, R-134a Design Pressure: 300 psig NEUTRONICS INC. MODEL No: UID 456 Creamery Way, Exton, PA, 19431 USA (610) 524-8800, www.NeutronicsInc.com WARNING-TO REDUCE THE RISK OF FIRE: DO NOT USE THIS EQUIPMENT IN THE VICINITY OF SPILLED OR OPENED CONTAINERS OF GASOLINE. -
Page 18: Turning On The Unit
To remove the battery, simply tug gently on the nylon strap, being sure to pull straight up, until the battery is dislodged. Turning On the Unit Connect the supplied vehicle power cable to the 12VDC power input jack on the back of the unit. Connect the battery clips to the vehicles 12VDC battery. -
Page 19: Viewing The Test Results
CALIBRATING - CALIBRATING - CALIBRATION TIME NOTE HAS EXPIRED THIS WILL ONLY REPLACE FILTER DISCONNECT HOSE TAKE 30 SECONDS WHEN WHITE FROM VEHICLE AND ELEMENT BEGINS PRESS CAL TO TO SHOW RED RECALIBRATE SPOTS ON OUTSIDE DIAMETER Figure 5 Figure 6 Figure 4 After calibrating, the unit will display the screen shown in Figure 7. - Page 20 RESULTS………PASS RESULTS………….FAIL R134 100.0% R134 95.0% 5.0% 2.8% EXIT PRINT EXIT PRINT Figure 11 Figure 12 Manual Part Number: Manual File: Revision Date: August 24, 2006 Page 2-4 5-06-7000-65-0 MN-A-0117 Rev. D...
-
Page 21: Blend Refrigerants
Blend Refrigerants The Ultima ID includes the “Blend ID” feature for determining the presence of EPA S.N.A.P approved blend refrigerants. In the event that the Ultima ID determines that the refrigerant in the system or cylinder is possibly a S.N.A.P. blend, the results will display as follows in Figures 13, 14, and 15. -
Page 22: Setting The Elevation
& T AINTENANCE ROUBLESHOOTING Setting the Elevation During the initial power-up, the Ultima ID will indicate that the elevation has not been set. To set the elevation, press the “Help” button on the “Ready to Air Cal” screen as shown in Section 2.2, Figure 3. -
Page 23: Changing The Sample Filter
TO CHANGE TO FEED IN A SETTINGS OR NEW PAPER ROLL REPLACE PAPER PRESS FEED ROLL PRESS SET PRESS SET TO FOR OTHER HELP ADJ LCD CONTRAST PRESS HELP OR ELEVATION HELP DONE FEED DONE Figure 24 Figure 25 Press the “SET” button shown in Figure 24 to display the screen options shown in Figure 25. Pressing the “SET”... - Page 24 Cleaning the Sample Hoses Inspect the inside diameter of the inner tube for signs of oil build up, dirt, obstructions, kinks, cuts, fraying, or any other signs of wear. Oil contamination can be cleaned out of sample hoses as directed below. Hoses that show signs of wear should be replaced immediately to avoid dangers of rupture or bursting.
-
Page 25: Error Messages
In the unlikely event that an “Error” message is displayed on the screen, power off the unit, take it to a location outside of the shop environment where fresh air is available and turn the unit back on. If the “Error” message reappears, contact our service department for assistance. Neutronics Inc. 456 Creamery Way Exton, PA 19341... -
Page 26: Spare Parts List
PPENDICES Spare Parts List PART NUMBER DESCRIPTION R134a Tank Adapter Fitting 4-03-5004-07-0 R134a Sample Hose 6-02-6000-09-0 R12 Sample Hose 6-02-6000-02-0 Vehicle Power Cable 6-01-6001-08-0 Sample Filter (5 Pack) 6-02-6000-08-1 Battery Kit (Optional) 6-02-6001-04-1 Spare Battery 6-02-6001-04-0 Printer Upgrade (Factory Installation Only) 6-01-6001-10-0 Printer Paper Roll (Sold in Quantities of 10 Only) 5-03-1000-08-0... - Page 27 Buyer, therefore, agrees to indemnify NEUTRONICS from and against all losses and claims to or by any person or property caused in any manner by the goods or the use of the goods, including any expenses and attorney’s fees in connection with all claims, demands, proceedings, or other expenses.
