G.T.Power C6D Pro Manual

Intelligent balance charger/dischager
Hide thumbs
Table of Contents

Advertisement

Quick Links

INTELLIGENT BALANCE CHARGER/DISCHAGER
Newly added FB-DCHG mode
FB-DCHG
With built-in tire warmer mechanism/servo
test/Motor-run function
Battery repairing function
Thank you for purchasing the balance charger.
This is a rapid charger/discharger with built-in
balancer, computerised with microprocessor and
can support scan QR code charging and phone
APP control. Please read the entire operating
manual completely and attentively before using.
300
DC 300W/AC 100W
Count battery
using times
Support AGM/PB
AGM/PB
battery
Battery warmer
function
Download on the
App Store
GET IT ON
Google Play

Advertisement

Table of Contents
loading

Related Manuals for G.T.Power C6D Pro

Summary of Contents for G.T.Power C6D Pro

  • Page 1 INTELLIGENT BALANCE CHARGER/DISCHAGER DC 300W/AC 100W Count battery Newly added FB-DCHG mode FB-DCHG using times Support AGM/PB With built-in tire warmer mechanism/servo AGM/PB battery test/Motor-run function Battery warmer Battery repairing function function Thank you for purchasing the balance charger. This is a rapid charger/discharger with built-in balancer, computerised with microprocessor and can support scan QR code charging and phone APP control.

  • Page 2: Table Of Contents

    Contents 1. Speci cations ...................... 02 2. Features........................ 03 3. The exterior appearance of the unit ..............05 4. Warnings and safety notes................. 06 5. Program ow chart..................... 08 6. Charging current setting..................09 7. Lithium battery (Lilon/LiPo/LiFe/LiHv) program..........09 8.

  • Page 3: Speci Cations

    1. Speci cations Input voltage AC.100-240V， DC.11-26V Charge current 0.1-12A Discharge Current 0.1-3A， 12A in FB-DIS mode Charge Power AC.Max.100W， DC Max 300W Discharge Power max.5W， 300W in FB-DIS mode Balance Current max.1A Balance Tolerance ±0.01V Charging Capability LiXX:1-6cells NiXX:1-15cells Pb Battery Voltage Pb:2-20V Weight...

  • Page 4: Features

    2.Features 【Optimized operating software】 This unit can automatically adjust current according to the change of the charging time and battery voltage when charging or discharging. It can avoid battery explosion due to user’s inappropriate operation especially when charging LiXX batteries.This charger provide balance port for lithium batteries suit for 2-6 cells.
  • Page 5 Temperature limit: The inner temperature will rise when charging.When set a maximum temperature, the charging program will be forced to end when charging temperature exceed the setting value.This function need to connect exterior temperature sensor. Charge time limit: You can through restrain the charge time to prevent any possible over charge/discharge.

  • Page 6: The Exterior Appearance Of The Unit

    3、 The exterior appearance of the unit Air vent Display screen ENTER/START key BATT.TYPE/STOP key INC key DEC key Battery main connector DC input port Temperature sensor /servo connector Balance port AC input:100-240V...

  • Page 7: Warnings And Safety Notes

    4. Warnings and Safety notes • Never leave the charger unsupervised when it is connected to power.If any malfunction happens, terminate the program immediately and refer to the operation manual for the right operation. • Keep the unit away from dust, damp, rain, heat, direct sunshine and vibration. Do not drop it.
  • Page 8 • The Lithium battery prefers a partial rather than a full discharge. Frequent full discharges should be avoided if possible. Instead, charge the battery more often or retain normal voltage. • The brand-new NiCd battery pack is partially useful with its capacity until it has been subjected to 10 or more charge cycles in any case.

  • Page 9: Program Ow Chart

    5. Program ow chart Start Lithium LiPo CHARGE LiPo FB-DIS LiPo STORE LiPo REPAIR LiPo BALANCE LiPo DISCHG Enter Battery Mode 12.0A 7.4V(2S) 2.0A 7.4V(2S) 2.0A 7.4V(2S) 2.0A 7.4V(2S) 2.0A 7.4V(2S) 2.0A 7.4V(2S) Stop LiIo CHARGE LiIo FB-DIS LiIo STORE LiIo REPAIR LiIo BALANCE LiIo DISCHG...

  • Page 10: Charging Current Setting

    6. Charging current setting You have to know the battery allowable maximum charging current before charging.Charging current exceeds the allowable maximum charging current may cause damage to battery and it is possible to lead a re and explosion of battery when charging. We usually use C value to mark battery charging/discharging capability.The battery allowable maximum charging current is calculated by multiply C value by battery capacity .
  • Page 11 7.1 Lithium battery balance charge mode This is for balancing the voltages of Lithium batteries of the battery pack to be fully charged. Inner system will monitor each cell’s voltage and restraint each cell’s current to ful ll balance charging. You need to connect the battery to the charger’s output plug as well as the balance port when charging.
  • Page 12 The second line left side to set dicharge current value, right LiIo DISCHG side to set the battery pack voltage value. After done, press 2.0A 0.0V(0S) and hold Start/Enter for 3 seconds to start the program. （dicharge current： 0.1～3.0A,cell voltage： 1～6cells） 3S 0.4A 11.84V It shows the current discharging status.
  • Page 13 7.5 LiPo FB-DIS mode You have to use this mode under DC working status and input port connected to battery, otherwise will report an error. FB-DIS working principle is transmit the standby discharging battery capacity to input battery through the charger and acheived the discharge e ect. For your safety, the screen shows discharge current should not exceed the battery manufacturer allowed maximum discharge current value, rated voltage should not exceed the battery manufacturer allowed lowest voltage value, in case deep discharge.

  • Page 14: Nimh/Nicd Battery Program

    It shows the current charging status, press Batt type/Stop to L3Bo 1.0A 12.16V stop charge. CHG 000:08 00002 4.15 4.15 4.15 V It shows each battery pack single cell voltage. 0.00 0.00 0.00 V 8. NiMH/NiCd battery program It is designed for charging and discharging NiMH or NiCd battery that commonly used for R/C model .
  • Page 15 8.3 NiMH /NiCd battery charge and discharge cycling mode Set the sequence on the left and the number of cycle (1-5) on the right. You can use this function to balance and refresh or cut o battery.To avoid battery temperature rising, there will be a brief cooling process after each charge and discharge cycle.

  • Page 16: Pb Battery Program

    discharge. For your safety, the discharge current value displayed on the screen should not exceed the maximum discharge current speci ed by the battery manufacturer, and the rated voltage should not be lower than the voltage level recommended by the battery manufacturer to avoid deep discharge.
  • Page 17 9.2 Discharging Pb battery DICHG Set discharge current on the left side and nominal voltage on 3.4A 12.0V(6P) the right. Press Start /Enter for 3 seconds to start the discharging process. （current： 0.1～3.0A, battery voltage： 1-10P） 0.1A 7.76V DSC 000:02 00000 9.3 Pb battery FB-DIS FB-DIS can only be operated when the battery is connected to the input interface under DC mode, otherwise will report error.

  • Page 18: Dji Phantom Series Battery Charge Program

    10、 DJI Phantom series battery charge program C6DPRO Charger is the intelligent multi-functional charger. It DJI Phantom can charge many di erent battery types and can also charge Battery Mode DJI batteries. 10.1 DJI Phantom 3 battery charge program The battery’s capacity of Phantom 3 professional and DJI Phantom 3 Phantom 3 is 4480mAh and the standard voltage is 15.2V.

  • Page 19: Ir Test

    4.16 4.18 4.17 V Press STATUS key to show the highest/lowest voltage of the 4.18 4.16 4.17 V single cell and the total voltage of the battery pack. MAIN 25.01V H4.178V L4.155V 12、 IR Test Lithium battery internal resistance is one of the important index of battery discharge capability and e ciency.

  • Page 20: Special Function Introduction

    13、 Special function introduction We’ve added some extra functions for C6dpro, such as motor-run, digital power, tire warmer, PWM test etc. 13.1 Motor-run introduction This program aims to test the quality of DC two-phase motor and check the quality of motor. Set the motor’s input power, check its output current and power, assisted with certain test equipment to judge the motor using status and quality.
  • Page 21 Short press Start/Enter to start the program, through press Warmer 68℃ INC/DEC to set heating temperature, heating time, heating 012:00 power. Heating temperature 30°-100°, heating time 1-120 minutes, heating power 10-100W. After nished, long press ENTER to test interface. If need re-set parameters, short press STOP back to set interface.

  • Page 22: Memory Mode

    14、 Memory Mode This charger can save setting data of each program, it can save 5 groups data for each kind of battery, including the cells of the battery, setting charge current and so on. Users do not need to set the data again when they use the batteries which have been memory. It is easier and more convenient to use.

  • Page 23: User Settings

    16、 User settings Lipo cut o voltage range is 4.15-4.25V, we‘d suggest user set LiPo CutOff Volt cut o voltage to 4.2V, to avoid exceed battery maximum 4.200V charging voltage causing damage to battery and your property. LiHv cut o voltage range is 4.30-4.4V, we’d suggest user set LiHv CutOff Volt cut o voltage to 4.35V, to avoid exceed battery maximum 4.350V...
  • Page 24 charging after the fast charging is over to avoid battery overheating. If you turn on safety timer when charging, safety timer will Safety Timer start timing too.If system fault or system can’t identify battery 240min capacity already full, this safety time set can stop battery being over charged.The safety time should not shorter than the battery fully charged time.

  • Page 25: App Instruction

    17、 APP instruction This unit with built-in high speed bluetooth module,you can connect app through bluetooth and set charge/discharge parameters on app, such as safety time, temperature protection, alarm sound on/o , capacity protection, low voltage protection and rm ware upgrade etc. It also support scan QR code to charge.

  • Page 26: Warning And Error Messages

    18、 Warning and error messages It combines a variety of protection functions and monitoring systems to identify its electronic functions and status. Screen will automatically display the error reason with a prompt tone if any error happens. 1.{" REVERSE POLARITY "} 6.{"...

  • Page 27: Warranty And Service

    This warranty does not cover the damage due to wear, overloading, incompetent handling or using of incorrect accessories. CONFORMITY DECLARATION G.T.POWER C6Dpro satisfies all relevant and mandatory CE directives and FCC Part 15 Subpart B. The product has been tested to meet the following technical standards: Test Standards...
