User Interface

Menu The square button is single purpose. It will enter the setup
Button mode at the top of the menu tree. If in the setup, and it
doesn't matter where, this button will exit the setup and
return to the normal operational mode.
Input The right and left arrows switch inputs. The 'Auto' mode
Selection will be in the list of inputs. The right and left arrows switch
inputs. If 'Auto' is selected, the unit will automatically
switch inputs based on priority (Input slot B is higher than
Input slot A) with the analog input being lowest priority.
When a source with a higher priority becomes active, the
unit will automatically switch to the new higher priority
input. Toggling through the inputs manually will defeat
any auto switching. When in the setup menu the arrows
move right and left through the menu structure.
Mute The circle button can be used to quickly mute the audio
of the DAC.
Volume This knob adjusts the volume between 0 and 106.
Knob
Display The display shows the Input, sample rate, bit depth, and
volume.
