Technical specifications

Supported Formats
(Input dependent)
Digital Inputs 4x Advanced isolated input module slots
XLR Analog Inputs 100K Ohm Balanced
XLR Analog
Outputs
Volume Control Purely passive constant impedance analog
Display Custom discrete LED audio clock synchronous
Controls Isolated RS-232
Chassis
Dimensions
Shipping
Dimensions
Included
Accessories
44.1kHz to 3,072kHz PCM up to 32 bits
1xDSD, 2xDSD, 4xDSD, 8xDSD
Supports DSD via DoP on all inputs
12Vrms Maximum
Isolated when not selected
3.57Vrms Maximum (Digital Input)
12Vrms Maximum (Analog Input)
75 Ohm Balanced
Galvanically isolated
attenuation
1dB steps
display
Adjustable brightness and auto-off feature
IR Remote
Knob + 4 Buttons
Width: 17.5 in (444 mm)
Depth: 17.5 in (444 mm)
Height without feet: 3 in (79 mm)
Stack height: 3.625 in (92 mm)
Weight: 25.5 lbs (11 kg)
Product Feet: M6X1 Thread
Width: 23 in (585 mm)
Depth: 23 in (585 mm)
Height: 7 in (178 mm)
Weight: 45 lbs (21 kg)
User Manual
MSB Remote
Micro USB Charging Cable
