MSB Technology Select DAC User Manual page 10

The MSB Remote
Indicator LED While in use:
1
1
3
4 Action 1 Toggles phase invert
5 Action 2 Toggles video mode
6 DAC Menu Enter DAC menu
7
8
9
Backward
10 Play/Pause Play and pause
11 Track Forward Skip/scan forward
12
13
14 Track Repeat Track or album repeat
15 Charging Port Micro-USB to charge the remote battery
White - Command Sent
Red and White - Command Sent
and Low Battery
Red Flashing - Needs Charging
While charging:
Red - Charging
White - Fully Charged
Power Powerbase on and off. When the powerbase
is linked to an amplifier or MSB product, this
button will turn off the entire system
(See powerbase manual for details)
Input Toggles directly through DAC inputs
While in menu:
Up - Volume Up
Down - Volume Down
Enter - Mute
Return - DAC Menu
Volume The center scroll wheel controls DAC volume
Mute DAC mute
Track Skip/scan backward
(MSB Transport Only)
(MSB Transport Only)
(MSB Transport Only)
Eject Eject media disc
(MSB Transport Only)
Stop Stop media
(MSB Transport Only)
(MSB Transport Only)
