MSB Technology Select DAC User Manual page 14

Select Powerbases
Both powerbases contain isolation technology. The powerbases detect
the input voltage and switch to 120 volt or 240 volt operation. They are
also available in a fixed 100 volt configuration. All powerbases have
over-voltage protection.
Two fuses are provided in each powerbase:
- 5A 250V SLO BLO - 5 mm x 20 mm miniature fuse (This is the main fuse).
- 100mA 250V SLO BLO - 5 mm x 20 mm miniature fuse (This is for the
standby supply only).
AC Voltage 120/240V (Auto switching)
Power Consumption 100 Watts with fully configured Select DAC
Chassis Dimensions Width: 17.5 in (444 mm)
Shipping Dimen-
Included Accessories
(Per Unit)
Select Powerbase Setup
After plugging in the powerbase, connect both powerbases with the
supplied 3.5mm mini jack cable by plugging it into the 12 volt remote
trigger connections. Be sure to check that the primary powerbase
'function switch'
powerbase switch set to 'LINKED'. This allows the primary powerbase
to control the secondary one without them having to be turned on/off
seperatley.
Technical Specifications
Optional 100V fixed configuration
Less than 2W standby
Depth: 17.5 in (444 mm)
Height without feet: 3 in (79 mm)
Stack height: 3.625 in (92 mm)
Weight: 45.8 lbs (20 kg)
Width: 23 in (585 mm)
sions Depth: 23 in (585 mm)
Height: 7 in (178 mm)
Weight: 55 lbs (25 kg)
Hybrid Power Cable
Ground Cable
IEC Power Cord
3.5mm Mini Jack (Primary Unit only)
is set to the 'NORMAL' position. The secondary
