Chapter 6 Specifications - THORLABS IO-F-2000 User Manual

2000 nm Fiber Isolator

Chapter 6 Specifications

Item #
Polarization
Fiber Type
Center Wavelength
Operating Range
Weight
Optical Specifications
Isolation @ 2000 nm
a
Max Power
Insertion Loss (Without Connectors)
Polarization Dependent Loss (PDL)
Return Loss
a) The maximum power specification represents the maximum power for the combined forward and
reverse directions. Therefore, the sum of the powers in the forward and reverse directions cannot
exceed the maximum power specification.
Page 6
Chapter 6: Specifications
IO-F-2000
Independent
Single Mode (SM), SMF-28e
2000 nm
1990 - 2010 nm
1.00 kg
28 dB (Min)
30 dB (Typ.)
3 W (CW)
0.9 dB (Typ.)
1.0 dB (Max)
≤ 0.20 dB
≥ 50 dB
21830-D02
