[90] Display setting
Set display setting in measuring mode. Display is divided,
indicating item can be set for each upper and lower. Press-
ing Set button once is setting for upper, pressing again for
lower, pressing once more for setting determined.
Upper
SETTING VALUE
DESCRIPTION
INPUT
Input engineering unit value*
INPUT (Scaling)*
Input scaling
1
Percent value*
PERCENT
OUTPUT
Output engineering unit value
OUTPUT (Scaling)*
Output scaling
2
*1. Display at measuring mode is INP (Scaling).
*2. Display at measuring mode is OUT (Scaling).
*3. Display the value which is converted by 0 – 10000 as total
resistance is 10000.
*4. Display the value converted as 0.00 to 100.00 % based on
input setting value.
Lower
SETTING VALUE
DESCRIPTION
INPUT
Input engineering unit value*
INPUT (Scaling)*
Input scaling
1
PERCENT
Percent value*
OUTPUT
Output engineering unit value
OUTPUT (Scaling)*
Output scaling
2
None
No display
*1. Display at measuring mode is INP (Scaling).
*2. Display at measuring mode is OUT (Scaling).
*3. Display the value which is converted by 0 – 10000 as total
resistance is 10000.
*4. Display the value converted as 0.00 to 100.00 % based on
input setting value.
[91] Brightness
Adjust brightness of display. It is available to set the range
between 1 (darkest) – 4 (brightest).
Initial value: 4
[92] Display timeout
Set the time to off the display when there is no operation
within a certain time.
It is available to set the range between 0 – 60 minutes.
Set '0' to display 'always on'.
When error is occurred at display off, the display returns
from off.
Initial value: 10
INITIAL
VALUE
3
INPUT
(engineer-
4
ing value)
INITIAL
VALUE
3
PERCENT
4
(percent
value)*
4
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
[93] Reset all settings
Return settings to initial value.
SETTING VALUE
OFF
RESET
*1. When setting value is initialized, each parameters cur-
rently set are over written by initial value. 'COMPLETE'
is indicated when initializing setting value is completed.
Notice that it does not return to the setting value, which is
specified by the option Ex-factory setting (/SET). Configure
initialized value again with DIP switch with power off for
output setting.
[94] Version indication
Indicate firmware version.
[01] Lockout setting
Set Lock / Unlock of lockout setting.
SETTING VALUE DESCRIPTION
Lock
Lockout setting enable
Unlock
Lockout setting disable
Even when setting is 'Lock', it is available to move on to
each setting mode and confirm the setting value of each set-
ting parameter. In each setting parameter display, when
'Lock', 'DATA (Locked)' is indicated, when 'Unlock', 'DATA'
is indicated.
M2EXM
DESCRIPTION
Not initialized
Initialize all settings*
1
INITIAL VALUE
Lock
EM-5135-B Rev.5 P. 15 / 19
