PROGRAMMING

■ SETTING FLOWCHART

Hold down Mode Button for ≥ 2 seconds

POWER ON

Measuring Mode

Hold down Mode Button

for ≥ 2 seconds

Hold down Mode Button for ≥ 2 seconds

Hold down Mode Button for ≥ 4 seconds

Hold down Mode Button for ≥ 2 seconds

Hold down Mode Button for ≥ 6 seconds

Hold down Mode Button for ≥ 2 seconds

Hold down Mode Button for ≥ 8 seconds

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN

Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp

Basic Setting Mode

Option Mode

Advanced Mode

Linearization Mode

EM-5135-B Rev.5 P. 6 / 19
