M-system Mini-M M2EXM Operating Manual page 10

[01] Lockout setting
Set Lock / Unlock of lockout setting.
SETTING VALUE DESCRIPTION
Lock Lockout setting enable
Unlock Lockout setting disable
Even when setting is 'Lock', it is available to move on to
each setting mode and confirm the setting value of each set-
ting parameter. In each setting parameter display, when
'Lock', 'DATA (Locked)' is indicated, when 'Unlock', 'DATA'
is indicated.
[12] 0 % input setting
0 % input setting is performed by teach.
For setting, use the corresponding value that input ratio for
total resistance is 0 – 10000.
Set as [12] 0% input setting < [13] 100 % input setting and
span 500 min. When the span is less than 500, 'SETTING
ERROR' is displayed and the setting is not determined. In-
put setting value set become 0% of 'INPUT (Scaling)' and
'PERCENT'.
Initial value: 0
[13] 100 % input setting
100 % input setting is performed by teach.
For setting, use the corresponding value that input ratio for
total resistance is 0 – 10000.
Set as [12] 0% input setting < [13] 100 % input setting and
span 500 min. When the span is less than 500, 'SETTING
ERROR' is displayed and the setting is not determined. In-
put setting value set become 100% of 'INPUT (Scaling)' and
'PERCENT'.
Initial value: 10000
[14] 0 % input scaling
Set the display value of 0 % input setting.
SETTING RANGE
-99999 – 999999
[15] 100 % input scaling
Set the display value of 100 % input setting.
SETTING RANGE
-99999 – 999999
[16] Input decimal point
Set the decimal point position of [14] 0 % and [15] 100 %
input scaling.
SETTING VALUE DESCRIPTION
oooooo Decimal point: None
ooooo.o Number of decimal places: 1
oooo.oo Number of decimal places: 2
ooo.ooo Number of decimal places: 3
oo.oooo Number of decimal places: 4
o.ooooo Number of decimal places: 5
INITIAL VALUE
Lock
INITIAL VALUE
0.00
INITIAL VALUE
100.00
INITIAL VALUE
2 places of
decimals
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
[17] Output range
Set the range of output signal of the unit.
SETTING VALUE DESCRIPTION
0 – 20 mA Output: 0 – 20 mA DC
-5 – +5 V Output: -5 – +5 V DC
-10 – +10 V Output: -10 – +10 V DC
When output range is changed, turn the power off, and then
set the output setting DIP SW on the side of the unit. Set-
ting is as follows. Output setting value is changed to initial
value.
OUTPUT
RANGE
1 2
0 – 20 mA OFF ON OFF OFF OFF OFF ON OFF
-5 – +5 V OFF OFF ON OFF ON OFF OFF ON
-10 – +10 V OFF OFF ON OFF OFF ON OFF ON
[18] 0 % output setting
Set the 0 % output setting.
OUTPUT RANGE SETTING RANGE MIN. SPAN INITIAL VALUE
0 – 20 mA 0.000 – 19.000
-5 – +5 V -5.000 – 4.750
-10 – +10 V -10.000 – 9.000
Set as follows.
[18] 0 % output setting < [19] 100 % output setting
The value is indicated by 'OUTPUT' at measuring mode.
[19] 100 % output setting
Set the 100 % output setting.
OUTPUT RANGE SETTING RANGE MIN. SPAN INITIAL VALUE
0 – 20 mA 1.000 – 20.000
-5 – +5 V -4.750 – 5.000
-10 – +10 V -9.000 – 10.000
Set as follows.
[18] 0 % output setting < [19] 100 % output setting
The value is indicated by 'OUTPUT' at measuring mode.
[20] 0 % output scaling
Set the display value of [18] 0 % output setting.
SETTING RANGE
-99999 – 999999
[21] 100 % output scaling
Set the display value of [19] 100 % output setting.
SETTING RANGE
-99999 – 999999
[22] Output decimal point
Set decimal point position for [20] 0 % and [21] 100 % out-
put scaling.
SETTING VALUE DESCRIPTION
oooooo Decimal point: None
ooooo.o Number of decimal places: 1
oooo.oo Number of decimal places: 2
ooo.ooo Number of decimal places: 3
oo.oooo Number of decimal places: 4
o.ooooo Number of decimal places: 5
M2EXM
INITIAL VALUE
0 – 20 mA
SW1
3 4 5 6 7
1.000 4.000
0.250 -5.000
1.000 -10.000
1.000 20.000
0.250 5.000
1.000 10.000
INITIAL VALUE
0.00
INITIAL VALUE
100.00
INITIAL VALUE
2 places of
decimals
EM-5135-B Rev.5 P. 10 / 19
