Cold Jet IceTech R1000H User Manual page 91

9
9
8
3
7
PROPRIETARY AND CONFIDENTIAL: THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF ICETECH A/S. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF ICETECH A/S IS PROHIBITED.
5
1
4
REV. DESCRIPTION
A
2
ITEM NO.
1
2
3
4
5
6
7
8
9
IceTech A/S
Industrivej 62
DK-6740 Bramming
REVISIONS
TLF. +45 76561500
DATE IN ITIALS
FAX. +45 76561509
www.icetechworld.com
PART NUMBER Description
514072 PLATE, SHUTTLE, R1000H
514363 SUSPENSION, SHUTTLE, R1000
BEARING, LINEAR GUIDE, SHUTTLE,
514089
R1000
CUP, LARGE RADIUS POCKET, SHUTTLE,
514073
R1000
514078 PLATE, SHUTTLE, R1000
SCREW, FLAT HEAD SOCKET CAP, M6 X
502643
12 MM LONG, STAINLESS STEEL
91322 SCREW, SOCKET HEAD CAP, M5 X 25, A2
515520 PLATE, FRONT, SHUTTLE, R1000H
515519 PLATE, REAR, SHUTTLE, R1000H
Material:
Description:
SHUTTLE, R1000H
Article nr.: Scale:
Weight:
514364 1:6
19.56 kg
QTY.
1
1
6
1
1
16
12
1
1
Sheet no:
1
Projection:
Format:
A3
Copy from:
Creator:
jm
Date:
29-06-17
Drawing no.: Rev:
P322-1-18875 B
