TECHNICAL DATA

Rated Output:
125 x 125 x 22,2 mm (5" x 5" x 0,875")
Up to 2000 slices/ hour
kg/h: 1140 kg/ hour
lbs/h: 2511 lbs/ hour
125 x 125 x 50,8 mm (5" x 5" x 2")
up to 1000 slices/ hour
kg/h: 1303 kg/ hour (Thickness: 50,8 mm)
lbs/h: 2870 lbs/ hour (Thickness: 2")
of high quality dry ice slices, depending on the size of slice chosen
Weight: 2545 kg /5610 lbs
CE: Power Supply
Main control:
3 x 400 V AC + PE, 50Hz
Imax: 63 A
System earthing: TN-S
Heater control:
3 x 400 V AC + PE, 50Hz
Imax: 63 A
System earthing: TN-S
Machine Dimensions (mm/inch):
Length: 1950 / 76,8
Width: 1500 / 59
Height: 2030 / 80
Noise level: below 75 dB(A)
Original
IceTech R1000H
Operator Manual for Reformer
UL: Power Supply
Main control:
3 x 480 V AC + PE, 60Hz
Imax: 63 A
25kA rms symmetrical,
480V max.
Heater control:
3 x 480 V AC + PE, 60Hz
Imax: 50 A
25kA rms symmetrical,
480V max.
