P01-DO07 P1 standby
P01-DO08 P1 reset
P01-DO09 P2 run
P01-DO10 P2 standby
P01-DO11 P2 reset
P01-DO12 P4 run*
P01-DO13 P4 reset*
-P01-SO01 E-stop pelletizer
-P01-SO02 E-stop flow wrapper
*) Signals for P4 flow wrapper is located on Murr-box on in-feed conveyor.
Original
IceTech R1000H
Operator Manual for Reformer
=0 Pelletizer 1 stop
=1 Pelletizer 1 Standby
=0 Pelletizer 1 resume production
=1 Pelletizer 1 reset alarm
=1 Pelletizer 2 start
=0 Pelletizer 2 stop
=1 Pelletizer 2 Standby
=0 Pelletizer 2 resume production
=1 Pelletizer 2 reset alarm
=1 Flow wrapper start
=0 Flow wrapper stop
=1 flow wrapper reset
=1 E-stop sub group 1 OK
=0 E-stop sub group 1 not OK
=1 E-stop sub group 2 OK
=0 E-stop sub group 2 not OK
Version: 1.0
21 from
Page:
23
Date: 30.08.17
Init.: JM
