10. PROCEDURE FOR REPLACING DIVERTER CYLINDER
Before changing the diverter cylinder
pneumatic air is disconnected. Remove air hoses and disconnect reed sensors. Loosen the 6 screws on
the taper bush
[5]
and the 2 screws on the foot mount
cylinder assembly off and replace with new parts from stock. Slide the taper bush
plate shaft and install the foot mount
plate so there are a few millimeter gap between the hopper wall and the diverter plate. Check the
return position of the cylinder that there also is a few millimeter gap on the opposite side between the
hopper wall and the diverter plate. Tighten the taper bush. Connect reed sensors and check the
adjustment of the reed sensors.
1
2
After installing the new diverter cylinder check the operation in single mode:
Operating in single mode control
Original
IceTech R1000H
Procedures for Maintenance and Repair
[1]
make sure that R1000H is in E-stop state or shut down and that
[2]
on the bracket. Adjust the cylinder plus stroke and diverter
1 Select single mode
2 Enter Manual operation
controls
[2]
for the pneumatic cylinder [1]. Pull the entire
3
Revision:
2.0
10-30 of
Page:
32
Date:
24.08.18
Init:
JM
[5]
on the diverter
4
5
