- Page 1 EE310 Electromechanical Level Measuring System Operation Manual FineTek Co.,Ltd. No.16, Tzuchiang St., Tucheng Industrial Park, New Taipei City 23678 Tel：886-2-22696789 Fax：886-2-22686682 Website：http://www.fine-tek.com E-mail：info@fine-tek.com 08-EE310-B2-EK,05/17/2021...
- Page 2 Warning Be sure to power off before wiring. Do not touch any wire terminal during power on to avoid electrical shock and always keep the screws secured. Connect the wires to the terminal in the correct order on the wiring diagram. ...
-
Page 3: Table Of Contents
Contents 1. Instruction ......................1 2. Guarantee ......................1 2.1. New product warranty ................... 1 2.2. Maintenance warranty ................... 1 2.3. Service Network .................... 2 3. Introduction ......................3 3.1. Product Features ................... 3 3.2. Principle ......................3 3.3. Sketch & Drawing ..................4 3.4. -
Page 4: Instruction
1. Instruction Thank you for purchasing FineTek product. This user manual will introduce the product features, operations, maintenance and troubleshooting to help the user get familiar with the product, and avoid possible hazardous situations. Before operating this device, please carefully study the product details. Additional support can be found at www.fine-tek.com or contact your local representative by telephone and facsimile. -
Page 5: Service Network
Fine automation No. 451, Duhui Road, Zhuanqiao Township, Co., Ltd. +86 021-64907260 +86 021-6490-7276 Minhang District, Shanghai City 201109 (China) FineTek Pte Ltd. 37 Kaki Bukit Place, Level 4 Singapore +65 6452-6340 +65 6734-1878 (Singapore Branch) 416215 Bei den Kämpen 26... -
Page 6: Introduction
III. Intelligent (smart) operation: The EE310 will vary its detection frequency to shorten the measuring time while the detected material level is more far away from EE310. This function is especially useful while customer’s storage or reservoir is subjected fast change in level (Ex: Pour in / Pour out), this smart function will decrease the possibility of weight head be buried or malfunction. -
Page 7: Sketch & Drawing
3.3. Sketch & Drawing Front View: Electric Board & Motor Rear View: Wiring Mechanism 3.4. Applications Measurements are independent of environment variation (sound waves, dust, capacitance, humidity and temperature, and is suitable for various industrial applications. Typical applications like metallurgical industry, mining, cement industry, power plant, ship manufacturing industry, chemical industry, feed industry, food industry etc. -
Page 8: Specifications
4. Specifications 4.1. Technical Parameters Category Specification 100~240Vac, ±10% 50/60 Hz (Standard) Power Supply 24Vdc ±10% (By order) Transistor output NPN / PNP ±5pulse(10mm/pulse) Measuring Resolution Relay output ±1pulse(100mm/pulse) Measuring Speed Avg. 0.23m/s Analog Output 0/4-20mA ±1% NPN/PNP output：max. 60Vdc, max. 400mA ※... -
Page 9: Product Specifications
(RS485) Intelligent Start Measuring interval is inverse proportional to medium level. Reset Output Cable Wire ø1.2mm 4.2. Product Specifications Power supply (Options) : AC type: 100~240Vac, ±10% 50/60Hz DC type: 24Vdc ±10% Power Consumption at Stand-by: 6VA Display : LCM Graphic 128x64 Dots ... -
Page 10: Product Dimension
5.1.3. Please contact us and provide claim with photos within 7-days after acceptance. FineTek guarantees after service and maintenance according to the purchase order. Over 7-days, it is regarded as acceptance of well delivery. -
Page 11: Installation
5.2.2. Don’t pull and drag the cable wire or hammer the weight head as it will damage the product. 5.2.3. When installing the product at 3 m above ground or higher, it is suggested to operate with hoist. 6. Installation 6.1. -
Page 12: Installation Instruction
6.2.2. On demand, user may connect an extending tube to connect the flange. If you do that, keep it in mind that minimum diameter should not be less than 4”. 6.2.3. For leakage, FineTek suggests customer should use O-ring seal or washer between the flange connections and secure it if indeed. - Page 13 It is recommended to install the material outlet protection and connect it in parallel with the fill-up protection 6.4.2. FineTek suggests 0.75mm non-twist multiple-cores isolated electric wire to connect with the terminal block.
- Page 14 6.4.5. Wiring label should be clearly identified and wired correctly. The wiring diagram is below. 6.4.6. Connect Assignments Terminal number Description 2.3. Transistor Output (Pulse) NPN/PNP 5.6. Analog Output 0/4-20mA(AGND.AOUT) Relay 1：Pulse or High Alarm (NO1、COM1、NC1) 19.20.21. Relay 2：Reset or Low Alarm (NO2、COM2、NC2) 7.8.9.
-
Page 15: Operation
7. Operation 7.1. Panel AC type DC type ① Power switch: On-site operation, maintenance, and power off when needed. ② Power terminal: power input 100~240Vac, 50/60Hz or 24Vdc (please confirm the order specification) ③ Heater terminal: connected to the internal antifreeze heater. ④... -
Page 16: Operation Flowchart
7.2. Operation flowchart → Start the measuring ↓ ↓ ↓ ↓... - Page 17 ↓ ↓ ↓...
- Page 18 7.3. Communication Data Address(Dec) Unit Range Definition Authority Type ERROR_CODE 0=normal, 1=buried, 2=break, 4=lock, 8=knot, 16=over current, 4133 UINT16 32=over temprtature, 64=high alarm, 128=low alarm, 256=over tank height, 512=home sensor abort 4147 FLOAT32 0.01ft 0~9843 Measuring distance/Material height 4148 4149 FLOAT32 0.01ft 0~9843 Tank height 4150...
- Page 19 4208 FLOAT32 mm 0~30000 Blind distance 4209 4210 Material height mode:high alarm FLOAT32 mm 0~30000 Cable-drop distance mode:low alarm 4211 4212 Material height mode:low alarm FLOAT32 mm 0~30000 4213 Cable-drop distance mode:high alarm Relay level measurement output: 4217 UINT16 0:continuous output 1:high low alarm output Display unit: 0:mm...
- Page 20 7.5. Definition K→Tank Height：distance between connecting flange to tank outlet S→Blind Distance：distance from connecting flange to the tip of the weight Z→Safety Distance：To avoid obstacles and prevent weight sliding into the outlet. H→Measuring Height：Full measuring range from drop and return with full pulse signal record (Menu: 1.1 Silo range).
- Page 21 7.6. Description of Smart Mode Smart mode operates the measurement according to the capacity and level of reservoir. In smart mode, the next measuring time period is depend on the current level distance measured. It is roughly a step by step (0.1 hour for each step), in quasi-linear relation, as indicated below.
-
Page 22: Maintenance
8.1.2 Inspect the cable wire for any kinks, knots, fatigue, or breakage. Replace the cable wire according to EE310 original specification if necessary. 8.2. Cable Wire Replacement 8.2.1 Cut the appropriate cable wire length Φ1.2mm (total measuring length+500mm), and insert the cable... - Page 23 8.2.4 Insert the end of the cable wire through the hanging bolt of the sensing weight and the short steel pipe which is used for crimping, and then go through the steel pipe again in a circle. Use the pliers (2 mm for holes) to do the crimping firmly at the central steel pipe (Fig.3).
- Page 24 8.3.2 The operation of the U-shaped ring of the plastic Auto-Fall-Off sensing weight same as 8.3.1. The plastic sensing weight must be filled with the material at 0.9~1.0kg before use. When connecting, the head of the plastic weight is aligned with the socket and inserted to the end completely, try to pull the sensing weight to confirm that the installation is correct (Fig 6) Fig.5 Fig.6...
-
Page 25: Troubleshooting
15,16 Check the wire condition Replace motor wire or Motor wire broken with motor contact FineTek High pressure in Check the cover secure reservoir or storage, Observe if gas or dust and fix the screw, or... - Page 26 Indicator Message: position and keep or not receiving with no stop. Buried Steel wire and weight Relay switch for buried is Contact FineTek if same are normal in good malfunctioned problem after reboot. condition. Materials stuck on Remove all the materials...
