MERLIN STEALTH
LOW POWER FENCE VOLTAGE
The open circuit low power fence voltage can be changed by pressing the 0 key, followed by the
6 key. Select the desired voltage from the table and press the corresponding number from 0 to
9 followed by the # key. The keypad will beep once to indicate that the new setting was
accepted.
Example: To change the open circuit Low Power Fence Voltage to 1450 Volts, enter 0 6 3#
Typical readings
V peak open
circuit Volts
0
1250
1
1350
2
1400
3
1450
4
1550
5
1650
6
1700
7
1750
8
1850
9
1900
FENCE ALARM VOLTAGE (HV Mode)
The fence alarm voltage (in HV mode) can be changed by pressing the 1 key, followed by the 4
key. Select the desired voltage from the table and press the corresponding number from 0 to 9
followed by the # key. The keypad will beep once to indicate that the new setting was accepted.
*M28 and M25 use different check voltages.
V peak 500
ohm
775
825
900
950
975
1000
1050
1100
1150
1200
Approx. Fence Alarm
Voltage (kV)
0
1
1
1.2
2
1.7
3
2.0
4
2.3
5
2.5
6
2.7
7
2.8
8
3.1
9
3.2
Energy (500
ohm load) J
0.11
0.12
0.14
0.16
0.17
0.18
0.21
0.22
0.24
0.26
Approx. Fence Check Voltage
Installer Options
(kV)*
2.3
2.7
3.0
3.2
3.7
4.3
4.8
5.4
5.8
6.0
8
