MERLIN STEALTH
Document Revision History
DOCUMENT REVISION HISTORY
Revision 1.0
19 September 2005
Revision 1.1
24 November 2005
Warning about safety switch added
Default energy reduced in HV mode for safety reasons during manufacturing.
Alarm threshold voltage made adjustable in HV mode.
Revision 1.2
29 November 2005
Wiring schematics added.
Revision 1.3
3 October 2006
Installation notes 18 and 19 added.
Revision 1.4
5 February 2007
Table of contents updated
High and Low Power typical readings added
Magnetic switch function added
Distance between wires of different fences changed to 2.5m
Revision 1.5
23 February 2007
Warning Head contact with fence added
Lid Alarm function added
Remote On/Off absolute or transition sensitive added
High Power Fence Voltage default changed to 0 (auto)
End of document
