MERLIN STEALTH
BATTERY AUTO-CHECK ENABLE AND LEVEL
The energizer may be configured to do an automatic battery check at regular intervals. The
mains is disabled for 20 minutes ( there is no visible indication of this unless the diagnostics port
is used) and the battery voltage monitored. Should the battery voltage fall below the acceptable
level a service indication will result. The auto-check voltage for the system can be changed by
pressing the 1 key, followed by the 7 key. Select the desired check voltage from the table and
press the corresponding number from 1 to 9 followed by the # key. The keypad will beep three
times to indicate that the new setting was accepted. Do not alter without understanding the
ramifications! Keying in a 0 disables this function.
BATTERY AUTO-CHECK REPEAT INTERVAL
The repeat interval for the battery auto-check can be changed by pressing the 1 key, followed
by the 8 key. Select the desired interval from the table and press the corresponding number
from 0 to 9 followed by the # key. The keypad will beep three times to
indicate that the new setting was accepted. Do not alter without
understanding the ramifications! Note that on loading factory default
values the battery will not be tested for the first week irrespective of the
interval that has been set.
Installer Options
0
No auto-check
1
10.5Volts
2
10.8Volts
3
11.1Volts
4
11.4Volts
5
11.7Volts
6
11.8Volts
7
11.9Volts
8
12.0Volts
9
12.1Volts
0
6 Hr
1
12 Hr
2
24 Hr
3
2 Days
4
3 Days
5
4 Days
6
5 Days
7
6 Days
8
7 Days
9
7.7 Days
11
