MERLIN STEALTH
GATE 2 DELAY TIME
The time delay for the gate to stay open before the alarm is activated, can be changed by
pressing the 1 key, followed by the 2 key. Select the desired time delay from the table and
press the corresponding number from 0 to 9 followed by the # key. The keypad will beep twice
to indicate that the new setting was accepted.
Example: To change the Gate Delay Time to 4 minutes,
enter 1 2 8 #
HIGH POWER FENCE VOLTAGE
The open circuit fence voltage can be changed by pressing the 0 key, followed by the 5 key.
Select the desired voltage from the table and press the corresponding number from 0 to 9
followed by the # key. The keypad will beep once to indicate that the setting was accepted.
Example: To change open circuit Fence Voltage to 6kV6 on a M15, enter 0 5 2 #
V peak
open
circuit.
Volts
0 6000
1 6300
2 6600
3 7100
4 7500
5 7750
6 7900
7 8100
8 8300
9 8500
M15 & M25
Typical readings
V peak Energy
500 ohm (500 ohm
load load) J
3900 2.50
4150 2.80
4300 3.00
4500 3.20
4850 3.70
5050 4.00
5200 4.20
5300 4.40
5450 4.60
5600 4.80
Installer Options
M18 & M28
Typical readings
V peak V peak
open 500 ohm
circuit. load
Volts
0 8000 auto 7100
1 7000 4500
2 7700 4950
3 8200 5300
4 8500 5650
5 8900 5950
6 9200 6850
7 9300 7100
8 9300 7350
9 9300 7600
0 2 Sec
1 5 Sec
2 10 Sec
3 30 Sec
4 45 Sec
5 1 Min
6 2 Min
7 3 Min
8 4 Min
9 4 Min 30 Sec
Energy
(500 ohm
load) J
6.8
3.20
3.70
4.20
4.80
5.20
6.40
6.80
7.30
7.60
7
