MERLIN STEALTH
FENCE VOLTAGE CONTROL
The energizer can be configured to change between High and Low voltage modes depending on
the Gate2 input. The fence voltage control can be altered by pressing the 1 key, followed by the
3 key. Select the desired function from the table and press the corresponding number from 0 or
1 followed by the # key. The keypad will beep three to indicate that the new setting was
accepted.
Example: To enable the fence voltage control via
Gate 2 input, enter 1 3 0 #
BATTERY SERVICE LEVEL NORMAL OPERATION
During normal operation the battery level is monitored and may result in a service indication. The
sensitivity or level at which the service level indication is given may be adjusted by the installer.
The battery service level for the system can be changed by pressing the 1 key, followed by the 6
key. Select the desired level time from the table and press the corresponding number from 0 to
9 followed by the # key. The keypad will beep three times to indicate that the new setting was
accepted. Do not alter without understanding the ramifications!
Note. The unit will protect the battery by disconnecting it from the
Energizer as soon as the voltage drops below a factory set level. The
Installer has no control over this protection.
Installer Options
0
Fence Voltage Control
1
Gate Function
0
10.5 Volts
1
10.8 Volts
2
11.1 Volts
3
11.4Volts
4
11.7Volts
5
12.0Volts
6
12.3Volts
7
12.6Volts
8
12.9Volts
9
13.2Volts
10
