7 REPAIRS AND ADJUSTMENT
7.8.1 Turning the machine.
90 (128)
WARNING!
The machine contains water that can run out onto
the floor.
WARNING!
Do not tip or lift the machine unless the bottom
place is properly screwed in place.
First remove the door and the side plates, then carefully lower the
machine down on the left side when viewed from the front. Now the
bottom plate can be removed.
Figure 24. Turn the machine around
Figure 25. Machine lying down
TECHNICAL MANUAL GETINGE WD15 CLARO
